Khind GC9122 Bruksanvisning

Khind Ugn GC9122

Läs nedan 📖 manual på svenska för Khind GC9122 (12 sidor) i kategorin Ugn. Denna guide var användbar för 10 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/12
model / 型号
GC9122
P/N: 40-50965-00
Gas Cooker / 燃气炉 / Dapur Gas
Instruction Manual / Buku Panduan说明指示书/
Please read this manual carefully before operating this product. Keep this manual handy for further reference.
请在使用此产品前 详读此说明书。并将之收藏以作日后参考。,
Sila baca buku panduan ini dengan teliti sebelum menggunakan produk ini. Simpanlah untuk rujukan masa depan.
Important / / 重要 Mustahak
This manual is also available online
www.khind.com.my
Safety Precaution
1
1. Gas used is LPG.
2. Use only approved Low Pressure Regulator.
3. Use only hose specially made for Liquefied Petroleum Gas supplies and the hose must not crack
due to aging. The hose must not come into contact with any part of the gas cooker body.
4. Before using, check to ensure that the trivet stand are placed correctly.
5. Do not use this appliance for drying clothes, etc.
6. Always maintain proper ventilation in cooking area at all times.
7. If a gas leak is found, stop the gas supply by turning the regulator control lever upward. Open all
windows for ventilation. Do not light matches or use a lighter and refrain from turning electrical
switches on and off during this period. Contact a qualified technician immediately.
8. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
9. Turn off the appliance whenever not in use.
10. Do not put flammable items on top of this appliance.
11. Do not touch metal parts of the appliance and the middle area of the top surface during and after
cooking as these areas reach high temperature.
Cleaning and Maintenance
Parts Identication
1. Always allow the appliance to cool before cleaning.
2. Use soft cloth with warm soap water for general cleaning.
3. Do not use caustic solutions, washing soda, aerosol spray cleaners, bleach and other abrasive
chemicals for cleaning.
4. DO NOT attempt to clean burner surface when still hot.
Low Pressure Regulator High Pressure Regulator
Specications
Installation
2
Model
Burner Size
Product Category
Gas Type
Gas Pressure
Total Heat Input
Gas Power Consumption
Net Weight
Product Dimension (LxWxH)
:
:
:
:
:
:
:
:
:
GC9122
Left: 130mm; Right: 130mm
I3B/P(30)
LPG
3000Pa / 30mBar
10.4kW
Left: 5.2kW; Right: 5.2kW
6.8kg
700 x 400 x 190mm
1. This appliance should be installed by a qualified person to avoid hazards.
2. Connect the hose to the gas regulator
and LPG inlet pipe .Tighten the hose with
the butterfly clip.
3. Make sure the hose does not pass over or come in contact
with the body of the appliance.
4. Insert regulator onto outlet valve of LPG cylinder.
5. Turn regulator control lever downward to release LPG into the
appliance.
6. After installation,test with soapy water for gas leaks.
7. Do not use connecting hose that is longer than 2 metres.
8. Ensure Minimum Clearance distance 150mm from the wall and 1 meter from the ceiling.
Hose
Screw Hose Clip
OK
To Gas Regulator LPG inlet pipe
*Specifications are subject to change
without prior notice.
Trivet Stand
Flame Adjustment Knob
Rubber Feet

Produktspecifikationer

Varumärke: Khind
Kategori: Ugn
Modell: GC9122
