Built-in Hob / / 嵌入式燃气炉 Hob Binaan Dalaman
Instruction Manual / Buku Panduan说明指示书/
model / 型号
HB902G
Please read this manual carefully before operating this product. Keep this manual handy for future reference.
请在使用此产品前,详读此说明书。并将之收藏以作日后参考。
Sila baca buku panduan ini dengan teliti sebelum menggunakan produk ini. Simpanlah untuk rujukan masa depan.
Important / Mustahak重要/
P/N: 40-50499-01
This manual is also available online.
www.khind.com.my
Parts identification
2
Model
Double Burner Size
Gas Power Consumption
Total Heat Input
Ignition System
Product Category
Gas
Gas Pressure
Rubber Hose Diameter
Net Weight
Built in Dimension
Glass Top Dimension
: HB902G
: 120mm
: 2x3.8kW (2x277g/h)
: 7.6kW (554g/h)
: Battery D Type 1.5V
: I3B/P(30)
: LPG
: 28~30mbar
: 10mm
: 13kg
: 630 x 350mm (R50)
: 780 x 450 x 8mm
Specifications
*Specifications are subject to change without prior notice.
Wok Stand
(Cast iron)
Inner Burner Cap
Outer Burner Cap
Decorative Cover
Sparker
Safety Valve
Anti-spillage Tray
Tempered Glass Panel
Flame Adjustment Knob
2
9
8
1
4
6
Trivet Stand
(Cast iron)
7
3
5
11
Air Adjustment Plate (Air Vent)
12
Gas Inlet Pipe
13
14 Battery Compartment
Rubber Feet
10
1 5 63 4
9
7 82
10 11
Back View
12 1213 14
1. The battery lifespan is approximately 3 months when operating the appliance. Change the battery when
the ignition of the spark is weak.
2. Gas used is LPG.
3.
Use only approved Low Pressure Regulator.
4. Use only hose specially made for Liquefied Petroleum Gas supplies and the hose must not crack due to
aging. The hose must not come into contact with any part of the gas cooker body.
5. Before using, check to ensure that the burners, caps, wok stand and trivet stand are placed correctly.
6. Do not use this appliance for drying clothes, etc.
7. Always maintain proper ventilation in cooking area at all times.
8. If a gas leak is found, stop the gas supply by turning the regulator control lever upward. Open all windows
for ventilation. Do not light matches or use a lighter and refrain from turning electrical switches on and
off during this period. Contact a qualified technician immediately.
9. This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
10. Turn off the appliance whenever not in use. Do not leave the appliance unattended during operation.
11. Do not put flammable items on top of this appliance. Do not store flammable materials or corrosive
chemicals in drawers or cupboards below or near to this appliance.
12. Do not touch metal parts of the appliance and the middle area of the top surface during and after
cooking as these areas reach high temperature.
13. Do not spray aerosols in the vicinity of the hob while it is in operation. Some propellant gas may produce
corrosive vapor when heated.
14. This appliance is intended for household use only, not for outdoor or commercial use. Commercial use will
void warranty.
Low Pressure Regulator High Pressure Regulator
Caution
3
Installation guide
4
1. Allow glass hob to cool before cleaning. The glass plate is best cleaned with cloth and warm soapy water.
Use of abrasive powders and pastes should be avoided. When necessary, use only mild abrasive. To
remove hardened grease, please use very fine steel wool.
2. Caustics solutions, washing soda, aerosol spray cleaners, bleach and some biological cleaners are
detrimental to some finishing. Care must be taken not to apply them onto burners and caps.
3. Do not wash burner caps in a dishwasher. Do not attempt to clean burner surface when still hot.
4. For cleaning, remove spillage from the anti-spillage tray as soon as possible. Control knobs may be pulled
off for cleaning. But take care not to allow water to enter through the holes into the glass plate.
5. When re-assembling the anti-spillage tray, always ensure that it is correctly located over the spark
electrode. Care should be taken to keep the electrode clean and avoid damage to the porcelain insulator
when removing the tray during cleaning.
Cleaning & Maintenance
1. Insert the battery into the battery box. (The battery box is located at the left underside of the hob).
2. Turn on the gas supply.
3. Depress the knob and turn it anti-clockwise 90˚ to maximum flame position. A continuous clicking sound
will be heard to ignite the hob. Release the knob when the burner has been lit.
4. Turning the knob will produce 3 different level of flames.
5. When turning the knob clockwise to “OFF” position, a click sound will be heard. The gas supply is shut off
and the flame will extinguish.
Hob with electronic ignition
1. The underside if the hob must have a clearance of
minimum 40cm. Do not seal completely. The door of
the cabinet should have ventilation blinds with
ventilation area of not less than 0.02m 2.
2. Please use specified rubber hose.
3. Do not place gas cyclinder underneath the hob.
The rubber hose must not exceed 2m in length.
4. Observe minimum clearance surrounding the hob
(more than 150mm from the wall and more than
1000mm for vertical distance). (Refer above diagram)
General knowledge on installation
5
Hose
Installation guide
780mm
450mm
45mm
630-740mm ≤120mm
350-415mm
4-R50mm
1
5 6 7
Bottom Plate/Base
Please do not seal/block anything underneath the
bottom plate to allow proper heat ventilation.
150
above
1000 above
150
above
Cabinet
Hob
Battery
2
To Gas Regulator LPG inlet pipe
43
OK
Screw Hose Clip
NO
Hose Clip
NO
Hose Clip
• This appliance should be installed by a qualified
person to avoid hazards.
• Install the hob in the cut-out the glass top plate should
fit the top of bench properly. If fitting is not proper,
please use plaster to seal any gap.
• Make sure the hose does not
pass over or come in contact
with the body of the appliance.
• Insert regulator onto outlet
valve of LPG cylinder.
• Turn regulator control lever
downward to release LPG into
the appliance.
• After installation,test with
soapy water for gas leaks.
• Do not use connecting hose
that is longer than 2 metres.
• Use new hose and new hose clip (screw type) for
installation of your hob unit.
• After installation, test with soapy water to
unsure no gas leakage.
• Insert the battery to its compartment beneath
the hob.
* Note: Warranty void if hole measurement for installation of hob unit is not followed.
