Sida 1/12
model / 型号 IC1600
P/N: 40-50704-00
This manual is also available online.
Induction Cooker
/
电磁炉
/
Periuk Induksi
Instruction Manual
/ 说明书
/
Buku Panduan
Important / Mustahak重要/
Please read this manual carefully before operating this product. Keep this manual handy for future reference.
请在使用此产品前,详读此说明书。并将之收藏以作日后参考。
Sila baca buku panduan ini dengan teliti sebelum menggunakan produk ini. Simpanlah untuk rujukan masa depan.
www.khind.com.my
Specications
Model
Voltage
Power
:
:
:
IC1600
220-240V~ 50/60Hz
2000W
Parts Identication Cautions
*Specifications are subject to change without prior notice.
Black Crystal Plate
Air Outlet Vent
Cooking Zone
Power Cord
Air Inlet
Control
Panel
“Lock”
Touch
Sensor
“BBQ”
Mode
“Fry”
Mode
“Hotpot”
Mode
“Soup”
Mode
“Water”
Mode
“Milk”
Mode
“Timer”
Touch
Sensor
“-”
Touch
Sensor
“+”
Touch
Sensor
“Mode”
Touch
Sensor
“ON/OFF”
Touch
Sensor
Read this Instruction Manual before using appliance.
1. Please use high quality power socket (13A or above). It is advisable not to share the power outlet with
electrical appliances with high power, such as an air conditioner, electrical stoves, and etc to avoid fire
caused by overloading the socket.
2. Do Not MODIFY this appliance.
3. Do not leave appliance unattended when connected to AC mains.
4. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
5. Do not use this appliance in damp conditions. Do not place the induction cooker near a gas stove,
kerosene stove, gas cooker, in any space with an open fire, or in an environment with high temperature.
6. This appliance is intended for household use only. Not intended for outdoor, industrial or commercial use.
7. Always place this appliance on a flat and stable surface. Do not put the appliance on any metal platforms
(such as iron, stainless steel, aluminium).
8. To avoid hazards, do not insert any foreign objects, such as iron wire, nor block the air ventilation opening
or entry port during cooking operations.
9. Do not operate this appliance on carpets or table cloth as they may obstruct air flow to the inlets and
exhaust.
10. When using the induction cooker, place it horizontally and allow at least 10 cm of free space between the
sides and the back of the induction cooker and the wall. Do not use the induction cooker in narrow
spaces. Please keep the ventilation opening free, to release heat.
11. Do not place small metal articles like knives, spoons, forks, lids, aluminium foils etc on the surface of this
appliance because they can be heated up and may cause injuries. Do not place a non-metallic metal pad
likes paper, cloth, or other unsuitable articles onto the induction cooker heating plate to avoid hazards.
12. Do not heat-up or cook canned food in its original condition. Always open can before cooking or heating.
13. Cardiac pacemaker users must consult a doctor before using this appliance.
14. This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
15. The appliance is not intended to be operated by means of an external timer or separate remote-control
system.
16. Do not plug in the appliance or operate the control panel with wet hands.
17. Please turn off and unplug the appliance when not in use. Make sure the power is off before pulling out
the plug and do not pull the cord.
18. With any indication of damage or malfunction, please stop using the appliance immediately to avoid
hazards. Take it to the authorized service center for repair. Do not attempt to repair or change any parts by
yourself.
1 2
Please do not switch off the main power supply after each usage.
This unit is equipped with a cooling fan which automatically starts once the unit stops operating in order to
prevent damage on major components.
Cooking Vessles Requirement
Cooking vessels must be induction cooker ready. They must be made from ferrous (metal) materials a.
such as stainless steel or paint coated metal containers.
b. Non-ferrous cooking vessels such as ceramic, glass, aluminium or any other non-magnetic utensils are
not suitable for this appliance. If these cooking vessels are used, the appliance will emit a series of
beeps, then automatically shut down.
c. Non suitable cooking vessels are plastic pots, ceramic pots, pottery, pyrex, glass pots, aluminium,
copper, or any other non-magnetic utensils etc.
d. The base of the cooking vessels must be at least 12cm in diameter.
e. The base of the cooking vessels if concave or convex in design must not be 2mm away from surface
of appliance.
f. Stainless steel double layer pots with compound encased bottoms are not suitable. Refer to pot
manufacturer. Always look for induction ready logo etched in pots.
Boil-Dry Protection
a. When there is no water in the pot or the pot being heated up to dry state, the appliance will produce
a series of beeps and shut off automatically. An error code (E5) will appear on the display. To re-set the
function to normal again, please press the Power Button to re-set to “On” state. Please make sure the
pot is not empty when you start the cooking function.
Pot Movement Protection
a. If the pot is removed from the appliance during cooking, the appliance will emit a series of beeps
before shutting down automatically, an erro code “E0” will appear on the display.
Usable Pans
Steel or cast iron, enameled iron, stainless steel, flat-bottom pans/pots with diameter from 12 to 26 cm.
Non-usable Pans
Heat-resistant glass, ceramic container, copper, aluminium pans/pots.
Rounded-bottom pans/pots with bottom measuring less that 12 cm.
Important Notice
Cleaning & Maintenance
1. Please turn off and unplug the appliance before cleaning or maintenance, wait until the crystal plate
surface of the induction cooker had been cooled down.
2. Never immerse the appliance into the water or other liquids. Do not rinse it under the tap.
3. Clean the surface of the appliance with a dry cloth. Do not use scouring pads, abrasive cleaning agents or
corrosive solvent to clean the appliance.
4. Black Crystal Plate: When it is dirty, wipe it with a soft damp cloth and if necessary, with some mild
cleaning agent.
5. Appliance’s Body and Control Panel: Wipe with a soft damp cloth. For the oil stains, use a damp cloth with
some mild cleaning agent to clean it.
6. Air Intake/ Air Outlet Vent surface: Get rid of the dust with a cotton stick. Oil stains can be removed by
using toothbrush with mild cleaning agents.
7. When the appliance is not in use for a prolonged period, please turn it off, unplug it, pack it well, and store
it in dry cool place.
WARNING: Please put the pot to be heated on the heating area of the induction cooker. Do not heat an
empty pot on the heating area.
WARNING: Avoid causing impacts on the heating plate. It may damage the plate. If cracking is found on the
cooker plate, turn off the appliance to avoid any electric shock that might occur.
WARNING: Do not switch off the main power supply on the wall socket immediately after cooking, wait for at
least 30seconds to cool down the appliance by the cooling fan.
CAUTION: The temperature of accessible surfaces may be high when the appliance operates.
CAUTION: The black crystal plate is hot after used, please do not touch with hand!
CAUTION: Keep the main cord out of the reach of children. Do not let the main cord hang over the edge of
the table or worktop on which the appliance stands.
Cautions
3 4
Hot surface
Caution
Do not touch with your hand
