Sida 1/3
Operation Manual
Diva-Lite 41, 31, 21 LED
Part No. 3100112 Rev A 05-17-2018
(True Match
Firmware 3.0)
®
Diva-Lite 31 LED DMX Kits
KIT-DL31XU
Diva-Lite 31 LED DMX Kit w/ Travel Case, Univ
Kit Contents:
1 Diva-Lite 31 LED DMX Center
1 Travel Case
Dimensions: Weight:
45.5 x 9 x 16.5” 33.5 lb
(116 x 23 x 42cm) (15kg)
Diva-Lite 31 LED DMX Kit
w/ Travel Case
3
KIT-DL21XU
Diva-Lite 21 LED DMX Kit w/ Travel Case, Univ
Kit Contents:
1 Diva-Lite 21 LED DMX Center
1 Travel Case
Dimensions: Weight:
28.5 x 8.5 x 16” 22.5 lb
(72.5 x 22 x 41cm) (10kg)
Diva-Lite 21 LED DMX Kit
w/ Travel Case
Diva-Lite 21 LED DMX Kits
FX (Effects) Mode
Control Panel - FX (Effects)
FX mode provides access to effects including Candle, Fire, TV, Police, Lightning,
Paparazzi, Pulse and Scroll. Candle mode used as an example:
A) FX Option:
Choose the desired FX Mode by rotating the control knob. When on the
desired effect, there will be several pre-programmed effects as well as
control parameters that can be altered.
B) Preset Buttons:
In FX Mode, Kelvin custom settings and any control functions displayed such
as and can be saved as a preset. Chosen values can Rate Amplitude (Ampl)
be assigned to any preset button by holding down the desired button for
3 seconds. The Kelvin display will lash once the setting is registered.
To restore presets to default factory settings, choose under Reset General
settings and Clear Presets. This method will reset all buttons in all Modes.
Shortcut: If only want to clear presets for Candle Lock Mode, hold button
for 3 seconds while Candle mode is displayed.
C) Mode:
Press to navigate from Dim to Kelvin and FX settings.
Shortcut: Long press will bring you back one step.
A C
B
11
