Sida 1/18

is guide will help you hook up the Forte SE to your sound system and MIDI system, give you a quick

overview, and show you how to start playing music with the Forte SE. A full manual for the Forte SE can

be obtained in electronic format from www.kurzweil.com.

Specications

Forte SE is Kurzweil’s latest entry in the Forte line of stage pianos. Some of the key specications include:

• FlashPlay technology with support for 2GB of Sound ROM

• High Denition Japanese Grand Piano and High Denition Electric Piano

• ROM sounds included from Kurzweil’s acclaimed PC3 series, KORE64 expansion,

and German D Grand EXP Grand Piano expansion

• New Piano String Resonance Simulation

• Full KB3 organ simulations with 9 sliders as drawbars

• 8 Zone MIDI Controller

• Space for 1024 Factory and 1024 User Programs and Multis (16 Categories of Programs)

• Arpeggiator with dedicated On/O button (1 per Program, up to 8 in Multi Mode)

• MP3 player audio input jack

• Full 128 voices of polyphony

• Hundreds of Eects Chains

It’s the

sound

GETTING STARTED GUIDE

Before You Start…

GETTING STARTED GUIDE

Before You Start…

Don’t connect anything until you make sure the Forte SE is properly and safely situated. If

your Forte SE keyboard has been out in the cold, give it time to warm up to room temperature

before starting it, since condensation may have formed inside.

Setting up the Forte SE

1. Set the keyboard on a hard, at, level surface.

2. Four adhesive-backed rubber feet are provided with Forte SE. Carefully turn the keyboard

over onto a soft surface, remove the paper backing from the rubber feet and attach them.

NOTE : Unless the instrument will always be used with a keyboard stand,

attachment of the rubber feet is strongly advised. Otherwise protruding

screws will scratch the tabletop.

3. Connect the AC power cord to the Forte SE. Before plugging the cable into the power

outlet, check that the power is compatible with the Forte SE. e Forte SE runs on AC

power and works with voltages from 80-265 volts 50-60 Hz. e voltage level is detected

and set automatically by the Forte SE. If your power source does not have the standard

three hole outlet, you should take the time to install a proper grounding system. is will

reduce the risk of a shock. If your power outlet is not within these ranges it is recommended

you use an appropriate adaptor.

4. Plug the power cable into the wall.

5. Plug the Switch Pedal into the marked SW1 (Sustain) Pedal jack on the Forte SE rear

panel.

6. Connect stereo headphones to the headphone jack on the rear panel or connect the audio

outputs to your mixer or amplier inputs using standard (1/4-inch) audio cables (use the

Left out for Balanced (“TRS” or “Stereo”) cables are recommended if your mixer mono).

or amp supports balanced inputs.

The Rear Panel

Using the Forte SE

GETTING STARTED GUIDE

7. Make sure your sound system is at a safe volume level. Also make sure that the Forte SE

Master Volume slider (on the far left side of the front panel) is all the way down.

Using the Forte SE

1. Power up the Forte SE using the power switch on the rear left side of the instrument, and

then raise the Master Volume slider, and mixer/amp volume. Your Forte SE keyboard starts

up in Program Mode by default. Press one of the buttons under the “Mode” label to the

right of the display to switch Modes.

Master Volume Slider Mode Selection

2. If you are connected to a mixing board and hear distortion, reduce the gain level on your

mixing board, or use the pad (a switch that decreases the input audio signal level, typically by

20dB) if it has one.

3. To hear the capabilities of the Forte SE, you can play the demo songs. Press the 13 & 14

Program/Multi buttons simultaneously to listen to a demo song.

4. In Program Mode, scroll through the Programs using the Alpha Wheel, the Previous and

Next buttons, or press a Category button to audition the sounds in the Forte SE. e Forte

SE has short demos for each of the factory Programs. To hear a Program Demo for the

current Program, press the 11 & 12 Program/Multi buttons simultaneously.

The Rear Panel

e power switch and most of the Forte SE connections are located on the rear panel.

Produktspecifikationer

Varumärke:	Kurzweil
Kategori:	Tangentbord
Modell:	Forte SE
