www.tiptopaudio.com
ZEUS Series:
microZEUS with
Flying Bus Boards
01
Zeus Series: microZEUS with Flying Bus Boards
The uZeus is a 4HP power supply module for Eurorack format
synthesizers. This version comes with two (2) flying bus boards that are
already attached to the module. An additional connection is available on
the uZeus for attaching an extra flying bus board if needed. The flying bus
boards use a keyed connector, ensuring that module power cables can
only be connected in the correct position.
When ordering your uZeus make sure to order a power adapter that fits
your country’s power plug. These adapters are usually oered along side
the uZeus by the shops carrying them in your country.
Connecting the uZeus:
First, attach your uZeus to your system. It can be placed in any position
along the rails, but it is strongly recommended that it be placed on the
rightmost edge of your case.
Next, plug the wall adapter in to your mains supply and insert the barrel
plug into the uZeus. Once connected, turn the switch to the ‘ON’ position
and make sure all three (3) red lights are illuminated.
If for any reason, one or all of them are not illuminated then immediately
turn the switch to the ‘OFF’ position.
Check all of your connections before continuing. Is the uZeus in contact
with another object? Are all of the modules plugged in properly?
Once you have successfully powered your uZeus, all you have left to do
now is play!
It is important to note that the front panel of the uZeus may get very warm.
Please do not be alarmed as this is normal and is part of the standard op-
eration of the uZeus, more on that in the next pages, please continue
reading.
WARNING: The internal components of the uZeus can get very hot. Do
not touch the internal components while the uZeus is connected and/or
powered.
02
Zeus Series: microZEUS with Flying Bus Boards
Owners of uZeus bought after Janurary 2017 please skip this page
Tiptop Audio has the following recommendations for connecting your
modules and using your uZeus:
The uZeus is designed to power systems ranging from 3U to 6U of 84HP
of mixed analog and digital modules. As you keep adding modules to your
system beyond 3U x 84HP we recommend a simple test that will help you
protect your uZeus and adapter from mistakenly getting overloaded and
eventually failing. To do so check the heat of your uZeus face plate and
the power adapter roughly 10 minutes after power up. If they become
almost too hot to the touch then you are overloading one of them and this
will cause them to fail. Please remove a few modules and test again,
repeating until they are reasonably but not burning hot. Please note: the
uZeus was designed to be mounted on metal rails with good heat transfer
such as Tiptop Z-Rails. install the uZeus directly to wood or any Do not
other flammable material, this will cause the uZeus to overheat.
To insure long life for the power supply, you should be aware of the total
power consumption of your system. This is determined by adding
together the amount of current used by each of your modules. Please
refer to the power consumption figures provided by your modules’
manufacturer(s). Please note, digital modules are usually by far more
demanding than analog modules.
To avoid crosstalk, it is recommended that High current-drawing modules
like digital and DSP modules, VCOs and sound/noise generators should
not all be plugged into a single bus board. For modules that are placed
next to the uZeus and have more than one circuit board and may block the
flying bus boards, take advantage of the ribbon cables flexibility and route
it around the module. The bus boards were designed with this
consideration in mind.
Wall Adapter Information:
The Tiptop wall adapter supplied with the Happy Ending kit is rated
1000mA and must be kept at that limit, it is a starter power supply and is
not meant for powering large systems beyond a Happy Ending Kit. Higher
power adapters can be used as long as you carefully keep checking how
hot the uZeus face plate gets as recommended above. The uZeus uses
15VDC adapters with 2.5mm barrel jack center pin positive.
