Instruction manual
EVSE ADAPTER
KEW 8602
—
1
—
Contents
1. Unpacking......................................................................................... 2
2. Safety precautions 2 ............................................................................
3. Features 5 ...........................................................................................
4. Instrument layout 7 ..............................................................................
5. Test procedures ................................................................................ 8
5.1 Connection 8 ...............................................................................
5.2 Pre-Test 8 ....................................................................................
5.3 CP (Control Pilot) state check 9 ..................................................
5.4 PP (Proximity Pilot) state check ............................................. 11
5.5 CP (Control Pilot) signal error simulation ............................... 11
5.6 PE (Earth fault) error simulation 12 .............................................
5.7 Various tests with measuring instrument (MFT) 12 .....................
5.8 CP (Control Pilot) signal output check 19 ....................................
6. Fuse replacement 20 ...........................................................................
7. Specifications 21 .................................................................................
—
2
—
1. Unpacking
Thank you for purchasing our EVSE adapter KEW 8602.
The following table is a list of the items included with the instrument.
1 Instrument KEW 8602 x1
2 Carrying case MODEL 9202 x1
3 Instruction manual x1
2. Safety precautions
This instrument has been designed, manufactured, and tested
according to IEC 61010: Safety requirements for electrical equipment
for measurement and delivered in the best condition after passing
quality control tests.
This instruction manual contains warnings and safety rules which must
be observed by the user to ensure safe operation of the instrument
and to maintain it in safe condition. Therefore, read through these
operating instructions before starting to use the instrument.
# DANGER
● Read through and understand instructions contained in this
manual before starting to use the instrument.
● Keep the manual at hand to enable quick reference whenever
necessary.
● The instrument is to be used only in its intended applications.
● Understand and follow all the safety instructions contained in the
manual.
It is essential that the above instructions are adhered to. Failure to
follow the instructions may cause injury, instrument damage and/or
damage to the equipment under test. KYORITSU is by no means
liable for any damage resulting from the instrument in contradiction
to these cautionary notes.
