Sida 1/2
POR-0100
Power over Ethernet Repeater
Maximum Range
Connect with Standard 15.4W PSE
End to end distance 100m 200m 300m 400m 500m
Daisy-Channing
( POR-0100)
0 1 2 3 N/A
Power Available ≦
≦
≦
≦≦ ≦
≦
≦
≦≦ ≦
≦
≦
≦≦10.9 W 6.5 W 3.84 W
Data only
No power
Connect with Hi-Power 30W PSE
End to end
distance
100m 200m 300m 400m 500m 600m 700m 800m
Daisy-Channing
( POR-0100)
0 1 2 3 4 5 6 7
Power Available ≦
≦
≦
≦≦
25.5W
≦
≦
≦
≦≦
21W
≦
≦
≦
≦≦
16.5W
≦
≦
≦
≦≦
12W
≦
≦
≦
≦≦
7.5W
≦
≦
≦
≦≦
3.84W
Data only
No Power
Connect with Hi-Power 40W PSE
End to end
distance
100m200m
300m 400m
500m 600m
700m
800m 900m
Daisy-Channing
( POR-0100)
0 1 2 3 4 5 6 7 8
Power Available
≦
≦
≦
≦≦
28W
≦
≦
≦
≦≦
25.5W
≦
≦
≦
≦≦
21W
≦
≦
≦
≦≦
16.5W
≦
≦
≦
≦≦
12W
≦
≦
≦
≦≦
7.5W
≦
≦
≦
≦≦
3.84W
Data only
No Power
PD Device (6.5W Max)
POE
Ethernet Switch
100 m
POR-0100
100 m 100 m
POR-0100
Quick Guide
Step 1: Connection to Power over Ethernet Switch
A. Connect one of the Ethernet Switch port with PoE power supply to the LAN IN port of POR-0100
as the following connection.
B. The LED indicators “ and “ POWER” IN” will turn on indicating the PoE and Ethernet connection.
C. The LED indicators “ IN” will flash to indicate Ethernet data activity.
Step 2: Connection to PoE PD
D. Connect the LAN OUT port of P0R-0100 to power up the PD device as the following connection.
E. The LED indicators “ OUT” will turn on indicating the PoE and Ethernet connection.
F. The LED indicators “ OUT” will flash to indicate Ethernet data activity.
** Note: If the Ethernet cable is not standard CAT5 cable, the POR-0100 may be working for shorter
length than 100 meter.
V1.0
PoE Switch
PoE Switch PR100 PD Device (6.5W Max)
100 m
100 m
