Lifenaxx ® * User Manual
Otoscope LX- 3 03
The Declaration of Conformity for this device is under the Internet link: www.technaxx.de/
(in bottom bar “Konformitätserklärung”). Before using the device the rst time, please read
the user manual carefully. Service phone No. for technical support: 01805 43 (14 0126
cent/minute from German xed-line and 42 cent/minute from mobile networks).
Free Email: support@technaxx.de
Keep this user manual for future reference or product sharing carefully. Do the same with
the original accessories for this product. In case of warranty, please contact the dealer or
the store where you bought this product.
Warranty 2 years
This product is intended to use on humans and animals. The product may only be
used for cleaning and checking the auditory canal or nasal cavity. When using the
device, make sure that you do not penetrate too deeply into the openings, you
could cause damage.
Features
⚫ CMOS Camer 2MP. a
⚫ Resolution 1920 x 1080P 30FPS.
⚫ 6 Axis Gyroskop
⚫ Focus distance 1,5-3 cm
⚫ Battery indicator
⚫ TF Card 32GB
⚫ 180° picture Video rotation
Technical specications
USB (load in dry condition only)
5V max. 1A
Battery
3,7V / 00mAh 25
Camera
2MP 1920x1080 30FPS
Working time
4 – 5 hours
Loading time
~2 hours
LED
6
Diameter of the Lens
Ø3,9mm
Dimension
15,6 x 7,5 x 1,9cm
Weight
18 7g
Display/ Resolution
4.5-inch /854 x 480
Languages
DE, EN, FR, CN, JA, SP, IT, RU
Accessory
3 x safety fu nnel
4 x ear spoon dierent designs
1 x Display stand
1 x 32GB TF card
First use
⚫Load the device fully with the USB cable, this may take up to 2Hours
⚫ ⚫Conect the camera with the otoscope before power on the device. insert
the TF-Card into the (9) TF Card slot, make sure the contacts of the card show
into direction of the Display (the card must click audibly into place) Press the ⚫
(8) Power on/off button for 1-2 seconds to start the Otoscope. The default ⚫
language is German, and the system supports English, Chinese, German,
French, Spanish, Italian, Russian and Japanese. To change the Language ⚫
Press 2 times (7) settings button, go down to Language, press (6) OK Button
and chose the language you want change to with the (7) up/down button.
Press (6) OK button again to chose you preferred language. In the same ⚫
way you can adjust the Time and date under the point Date/Time, or the Auto
Power off time under the relevant point under settings. If you can not take ⚫
pictures or videos, make sure the TF Card is formatted in the correct format
(FAT32). Press 2 times the (7) setting button, press the (4) up/down button to ⚫
come to the point Format, press (6) OK Button, select ok on the menue to
format the TF card.
1
2
Photo Video taking button
3
4
Up/ down in Menue and rotate Picture/
Video on Camera
5
6
OK, conrm changes, freeze picture
7
8
Power on/off (hold for 1 sec.)
9
10
Charging Port (USB-C max.5V, 1A)
11
12
Installation hole for bracket
13
14
Microphone
Instruction of use
⚫ ⚫Conect the camera with the otoscope before power on the device. insert
the TF-Card into the (9) TF Card slot, make sure the contacts of the card show
into direction of the Display (the card must click audibly into place) Press the ⚫
(8) Power on/off button for 1-2 seconds to start the Otoscope. For the rst ⚫
view add one of the safety funnels The ear channel is not perfectly straight, . ⚫
gently adjust the position of the otoscope in your ear. To have a clearer view ⚫
without glare you can adjust the (3) LED brightness.
⚫The focal length of the camery is 1,5-3cm, adjust the distance between the
camera lens and your ear to get focused.
To take a picture you can press (2), change to video press the MODE
button and press (2) again to start and stop the video. To switch to your
photo/ video archive, press MODE button again, select the le with the (4) up
down button and press ok for playback.
Connect to computer (Windows 10)
⚫ Conect your USB cable to the Otoscope, then to an USB port of your
computer. Switch on your Otoscope, you can nd a new USB-device in your
Explorer. The Folder DCIM contains your pictures and videos.⚫
Normal use
⚫ The otoscope should only be inserted into the auditory canal or nose when
a spoon or safety funnel is tted.
⚫ Place the spoon, safety funnel on the otoscope so that ts tightly. it
⚫ be carefull auditory canal nose are sensitive. and
Cleaning
Before and after use you should clean the camera, spoon and safety funnel.
Safety Instructions
→ Do not look into the LED light. → Only recharge with supplied or compatible
USB cable This device is not intended for use by children or persons with . →
limited mental capacity or lacking experience and/or lacking expertise. This →
