Active PoE Injector

User Manual English

LINDY No. 52052

www.LINDY.com

English Manual

English 2

Introduction

This PoE Mid-Span is 1-pair port power supply consisting of 1 Ethernet data input ports and

1 Ethernet data output ports with 48V power equipped, which is fully IEEE 802.3af compliant.

Any Ethernet Cat. 5 “Data” cable can directly connect to the input port and then come out

“Data + Power” from output port. It is smart plug and play and very easy to install in any

existing networking system, to bring in PoE features without any new reconfiguration.

Package Contents

Before you start to install this PoE Mid-Span Power Supply, please verify your package that

contains the following items:

 One PoE Mid-Span Power Supply

 One Power Cord

 One User’s Manual

Note: If any of these items is found missing or damaged, please contact your local supplier

for replacement.

Key Features

 1 “Data” input ports compliant with IEEE 802.3 10BaseT and IEEE 802.3u 100BaseTX

 1 “Data + Power” PSE/PoE output ports compliant with IEEE 802.3 10BaseT, IEEE

802.3u 100BaseTX and IEEE 802.3af PoE

 Supporting the power Max. 15.4 W for PSE/PoE port

 Each output port has output current limited, short-circuit protection, complete Power

Device (PD) detection and classification

 Smart plug & play

English Manual

English 3

Front Panel (LEDs)

LED Indicators of 1-Pair Port PoE Mid-Span Power Supply

LED

Status

Description

Power On Power is on.

Off Power is off.

Connections

Power Device/Existing Switch to this 1-Pair Port Mid-Span Power Supply

Use Cat. 5 twisted-pair cable from the existing switch to the “Data” input port of this Mid-span

Power Supply, and then connect the “Data + Power” output port to the Power Device, such

as Wireless AP, another switches with PD function…etc.

Technical Specifications

Standar

IEEE 802.3af

IEEE 802.3 10BaseT

IEEE 802.3u 100BaseTX

Features

Number of Ports:

1 Ethernet Input (data only) Port

1 Ethernet Output (data + power) Port

LED

Indicator

Per Unit: Power

Power

Input 100~240V/AC, 50~60Hz

Power

Output 48V/DC at Full 15.4 W Output Supported

Power

Consum

ption

19 Watts (Max)

Dimensi

ons

120 × 50 × 35 mm

(L x W x H)

Weight 0.2 kg

Operatin

Temper

ature

0 to 40

℃

Storage

Temper

ature

-20 to 85

℃

Humidity 10 to 90% RH (non-condensing)

Certificat

ions FCC Class A, CE

Radio Frequency Energy, Certifications

FCC Warning

This device complies with

part 15 of

Operation is subject to the following

This device may not cause harm

This device must accept any inte

operation.

CE Statement,

EMC Comp

This device complies with EN Stand

Directive.

It must be used with shield

Dieses Produkt entspricht den einsc

abgeschirmten Kabeln verwendet w

LINDY Herstellergarantie

LINDY gewährt für dieses Produkt ü

Herstellergarantie ab Kaufdatum. D

LINDY Website aufgelistet bei den A

WEEE (Waste of Electrical a

Recycling of Electronic Pro

In 2006 the European Union introdu

electrical and electronic equipment

be disposed of with household w

environmentally friendly. For more

local recycling centre or your hous

implement

ed the WEEE regulation

national law when you want to dispo

More details can be obtained from y

Germany / Deutschland

Die Europäische Union hat mit der

das Recycling von Elektro-

und Elek

im Elektro-

und Elektronikgeräteg

verbietet vom 24.März 2006 an

Hausmülltonne! Diese Geräte mü

zugeführt werden! Dort werden s

Recyclingprozess übernimmt die Ge

Energy, Certifications

f the FCC Rules.

two conditions:

mful interference, and

erference received, including interference tha

patibilty

dards EN55022 and EN55024 according to th

ded cables only to maintain EMC compatibili

chlägigen EMV Richtlinien

der EU und darf n

werden.

über die gesetzliche Regelung hinaus eine zw

ie detaillierten Bedingungen dieser

Garantie

AGBs.

and Electronic Equipment),

ducts

uced regulations (WEEE) for the collection a

The wheelie bin symbol shown indicates th

waste. Instead the p

roduct must be recycl

information on how to dispose of this prod

ehold waste disposal service.

Each individu

ns into national law in slightly different w

ose of any electrical or electronic products.

your national WEEE recycling agency.

WEEE Direktive umfassende Regelungen fü

ktronikprodukten geschaffen. Diese wurden v

gesetz

– ElektroG in

deutsches Recht um

n das Entsorgen von Elektro

und Elek

üssen den lokalen Sammelsystemen bzw.

sie

kostenlos entgegen genommen. Die K

esamtheit der Gerätehersteller.

at may cause undesired

he relevant EC EMC

ty.

ur zusammen mit

weijährige

finden Sie auf der

and recycling of all waste

hat this product must not

ed in a manner that is

duct, please contact your

ual EU member state has

ays. Please follow your

ür die Verschrottung und

von der Bundesregierung

mgesetzt. Dieses Gesetz

ktronikgeräten über die

örtlichen Sammelstellen

Kosten für den weiteren

LINDY No 25052

Edition, August 2011

www.lindy.com
