Sida 1/5
© LINDY ELECTRONICS LIMITED & LINDY-ELEKTRONIK GMBH - FIRST EDITION (Mar 2010)
For Home and Office Use
Tested to Comply with
FCC Standards
8 Port PoE Midspan Switch
User Manual English
LINDY No. 25058
www.LINDY.com
English Manual
English 2
Introduction
This PoE Mid-span is 8-pair port power supply consisting of 8 Ethernet data input ports, and
8 Ethernet data output ports with 48V power equipped, which is fully IEEE 802.3af compliant.
Any Ethernet “Data” cable can directly connect to the input port and then come out “Data +
Power” from output port. It is smart plug and play and very easy to install in any existing
networking system, to bring in PoE features without any new reconfiguration.
The compact rigid desktop size was specifically designed for small to medium workgroups. It
can be installed where space is limited; moreover, it provides smooth network migration and
easy upgrade to network capacity.
Package Contents
Before you start to install this switch, please verify your package that contains the following
items:
One PoE Mid-Span Power Supply
One Power Cord
One User’s Manual
Note: If any of these items is found missing or damaged, please contact your local supplier
for replacement.
Key Features
8 “Data” input ports compliant with IEEE 802.3 10BaseT and IEEE 802.3u 100BaseTX
8 “Data + Power” PSE/PoE output ports compliant with IEEE 802.3 10BaseT, IEEE 802.3u
100BaseTX and IEEE 802.3af PoE
Supporting the power Max. 15.4 W for each PSE/PoE port
11” Desktop size with metal case
Can be installed in a 19” cabinet by rack-mount kit
Each output port has output current limited, short-circuit protection, complete Power Device
(PD) detection and classification
Smart Plug & Play
English Manual
English 3
Front Panel (LEDs)
LED Indicators of 8 Pair Port PoE Mid-Span Power Supply
LED Status Description
Power On Power is on.
Off Power is off.
PD
Link
On Port is connected to a Power Device
port and supplies 48
Off No Power Device is connected
Connections
Power Device/Existing Switch to this 8 Pair Port Mid-Span Power Supply
Use Cat. 5 twisted-pair cable from the existing switch to the “Data” input port of this Mid-span
Power Supply, and then connect the “Data + Power” output port to the Power Device, such
as Wireless AP, another switches with PD function…etc.
