© LINDY Group - THIRD EDITION (October 2018)
HDMI 2.0 Audio Extractor
User Manual English
Benutzerhandbuch Deutsch
Manuel Utilisateur Français
Manuale Italiano
No. 38171
lindy.com
Tested to comply with
FCC Standards
For Home and Oce Use!
User Manual English
Introduction
Thank you for purchasing the Lindy HDMI 2.0 Audio Extractor. This product has been designed to provide
trouble free, reliable operation. It benets from both a LINDY 2 year warranty and free lifetime technical
support. To ensure correct use, please read this manual carefully and retain it for future reference.
The Lindy HDMI 2.0 Audio Extractor allows the user to seamlessly extract both digital and analogue audio
from a HDMI source and output to an audio device in either digital or analogue formats, while sending the
video signal to a 4K display or projector.
Package Contents
HDMI 2.0 Audio Extractor
5VDC 2A Multi-country Power Supply (UK, EU, US & AUS)
Lindy Manual
Features
Supports resolutions up to 4096x2160@60Hz 4:4:4 8bit, with additional support for HDR
Extracts HDMI audio to both stereo and multi-channel audio
Supports High Bit Rate Audio and CEC pass-through
Operation
HDMI In: To connect the source device by HDMI cable.
5.1CH LED: This will illuminate when the output EDID is switched to 5.1.
Link LED: This will illuminate when the HDMI source device is connected and switched on.
Power LED: This will illuminate when the audio extractor is connected to the power supply.
EDID Switch: This switch allows the user to select the extractor’s audio EDID. For a full list of supported
audio and formats from each EDID, please see the table below.
5V/DC: For connection to the supplied 5VDC2A multi-country power supply.
Optical: For connection to digital audio equipment which support optical connections
HDMI Out: For connection to the display device for a video and audio signal
L/R: For connection to analogue audio equipment which support 3.5mm connections
