Part no.:
| DESCRIPTION
43905
USB Type A 4K30 Conference Soundbar & Camera
All-In-One Camera, Speaker & Microphone for Huddles Spaces & Meeting Rooms
All-In-One collaboration system with meeting room camera, soundbar speaker & microphone
4K Ultra HD Camera for amazing clarity, detail and accuracy
In-built high, performance 360° omni-directional microphone with 5m range
High- delity premium speaker for clear, room lling audio playbackfi fi
Versatile installation for small or medium sized meeting rooms or home office use
Simple plug and play USB installation
2-Year Warranty
Lindy’s USB Type A 4K30 Conference Soundbar & Camera is the perfect all-in-one solution for huddle spaces, meeting rooms and
other hybrid collaboration environments with a high-quality camera, hi- speaker and omni-directional microphone housed withinfi
a compact, sleek design.
Crystal clear video with 4K support
This conferencing room solution utilises a premium 8MP camera with 4K30Hz support, ensuring superior clarity with minimal
distortion. This allows for amazing clarity of presenters or meeting participants ensuring focus for the viewer on the other side.
The 100° wide angle lens provides the scope for capturing all meeting participants, giving greater involvement of the team in
collaboration settings.
Wide-scale collaboration – pick up every moment of the meeting
The in-built omnidirectional microphone captures every second in excellent detail with a pickup range of 5m and 360° covering
small to medium sized huddle spaces and meeting rooms. Combined with an audio DSP and specially tuned echo noise
cancellation algorithms (AEC, AGC & ANS), background and environmental noise is reduced, providing limited interference when
call clarity is vital.
•
•
•
•
•
•
•
| TECHNICAL DATA SHEET
Immersive audio playback
All features are housed within a neat, compact soundbar speaker which provides immersive, hi- sound, meaning both sides of afi
call can be heard with optimum clarity across the room whether collaborating on a video call, listening to a training video, or
engaging in a lecture.
Fully Compatible with Microsoft Teams, Skype and Zoom
With a simple USB Type A connection, this conferencing camera can be seamlessly integrated with a variety of UC software
including Teams, Skype or Zoom, making this the perfect solution for hybrid workspaces, educational setups or other collaborative
environments.
Hassle free, simple installation & setup for a variety of applications
The USB Type A connection can be easily connected to a source PC or laptop with no software require for installation, ensuring
setup is hassle free for the user. The camera itself can be mounted and positioned in a variety of ways, depending on the required
application. The tted clamp can be used with laptops or monitors for small scale use or laid on a desk for a quick and simple butfi
high performing workspace. The mounting points also allow for easy installation to a bracket next to a display or touch panel within
Camera Speci cationsfi
Resolution: 3840x2160@30Hz
Sensor: 1/2.8" HD Sony CMOS
Pixels: 8MP, 16:9:
Diagonal Field of View: 98°
Horizontal Field of View: 86°
Vertical Field of View: 55°
Focal Length: 2.88mm (0.11in)
Aperture: F/2.7
Minimum Illumination: 350Lux
White Balance: Automatic
Gain Control: Automatic
Backlight Compensation: Yes
Electronic Shutter: Automatic
Speaker Speci cationsfi
Drivers: 50x50mm
Output: 2W
Sensitivity: 82±3dB 1M/1W At2.83V 300.400.500.600
THD: 5% Max AT 1000Hz 1W/1M
Impedence: 4Ω±15% At 1000Hz
Microphone Speci cationsfi
Type: 360° Omnidirectional Reception Microphone
Frequency Response: -27dBFS
Sensitivity: -35db
Microphone Data Rate Output: 64.3dB(A)
Pickup Range: 5m (16.4ft)
Pickup Angle: 360°
Audio Processing: AEC, AGC and ANS:
Noise Reduction: 2D & 3D Digital Noise Reduction, Acoustic Echo & Noise Cancellation
Connectors
Input: USB 2.0 Type A (Male), 1.8m
Power: -
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
| TECHNICAL DATA SHEET
Physical Properties
Dimensions (approx.) WxDxH: 230x56x60mm (9.06x2.2x2.36in)
Housing Material: ABS & Plastic
Net Weight: 0.4kg (0.88lb)
Operating Temperature: 0°C - 50°C (32°F - 122°F)
Storage Temperature: 0°C - 60°C (32°F - 140°F)
Humidity: 0 - 95% RH (non-condensing)
Input Voltage: 5V
Power Consumption: 2W
Colour: Black
Installation: Monitor Clamp, Desktop, Tripod or Wall Mountable
Miscellaneous
Packaging Type: Carton Box
Packaging Dimensions: 244x98.5x78mm (9.61x3.88x3.07in)
Gross Weight: 0.52kg (1.15lb)
Warranty (Years): 2
Compatibility: Supports USB UVC Protocol, Zoom, MS Teams, Skype for Business, Zoom, WebEx etc
Certificated: CE, UKCA, FCC, RoHS, REACH & California Proposition 65
Package Contents
USB Type A 4K30 Conference Soundbar & Camera
Lindy Manual
Purchasing Information
No.: 43905
EAN: 4002888439053
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
| TECHNICAL DATA SHEET
