User Guide

Linksys WUMC710 Wireless-AC Universal Media Connector

ContentsLinksys WUMC710

Product Overview

LED panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Ports panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Wireless Security Checklist

Change the default wireless network name or SSID 4

Change the default password 4

Enable MAC address ltering 4

Enable encryption 4

General Network Security Guidelines. . . . . . . . . . . . . . . . . .4

Additional Security Tips . . . . . . . . . . . . . . . . . . . . . . . . . .5

Advanced Conguration

How to access the browser-based utility. . . . . . . . . . . . . . . .6

Setup > Basic Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Language 7

Network Setup 7

Wireless > Basic Wireless Settings . . . . . . . . . . . . . . . . . . . .7

Basic Wireless Settings 8

Wireless Security 8

Wi-Fi Protected Setup 9

Wireless > Wireless Network Site Survey . . . . . . . . . . . . . . . 10

Wireless Network Site Survey 10

Wireless > QoS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Wireless 11

Administration > Management . . . . . . . . . . . . . . . . . . . . 12

Management 12

Administration > Factory Defaults. . . . . . . . . . . . . . . . . . . 12

Factory Defaults 12

Administration > Upgrade Firmware . . . . . . . . . . . . . . . . . 13

Upgrade Firmware 13

Status > Device. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Device Information 13

Local Network 13

Status > Wireless Network . . . . . . . . . . . . . . . . . . . . . . . . 13

Wireless 13

Troubleshooting

WUMC710 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Specications

WUMC710 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Contents

Product OverviewLinksys WUMC710

Thank you for choosing the Linksys Wireless-AC Universal Media Connector.

The media connector can connect any wired Ethernet device to your wireless

network. The media connector is based on Wireless-AC, so it is compatible

with Wireless-N (5 GHz) and Wireless-A routers or access points. For first-

time installation, follow the steps in the . To configure Quick Installation Guide

advanced settings, use the convenient browser-based utility.”

LED panel

Wireless (Blue) The Wireless LED lights up when there

is a wireless connection. The LED flashes when the media

connector is actively sending or receiving data over the

wireless network.

Wi-Fi Protected Setup Button If your router supports Wi-

Fi Protected Setup and uses WPA or WPA2 security, then

you can use Wi-Fi Protected Setup to automatically connect

the media connector. To use Wi-Fi Protected Setup, refer to

“Wireless > Basic Wireless Settings” on page 7.

Wi-Fi Protected Setup LED (Blue/Amber) The LED flashes

blue for two minutes during Wi-Fi Protected Setup. It

lights up blue when wireless security is enabled. If there

is an error during the Wi-Fi Protected Setup process, then

the LED lights up amber. Make sure the network router

supports Wi-Fi Protected Setup. Wait until the LED is off,

and then try again.

Ethernet (Blue) The Ethernet LED lights up when there

is a wired connection. The LED flashes when the media

connector is actively sending or receiving data over the

Ethernet port(s).

Power (Blue) The Power LED lights up when the media

connector is powered on.

Product Overview
