Makita DC18RE Bruksanvisning

Makita Batteriladdare DC18RE

Läs nedan 📖 manual på svenska för Makita DC18RE (56 sidor) i kategorin Batteriladdare. Denna guide var användbar för 6 personer och betygsatt med 4.5 stjärnor i genomsnitt av 2 användare

Ladda ner PDF
Sida 1/56
EN Fast charger 2 ....................... SV Snabbladdare 30 ...................
FR Chargeur rapide 4 ................. NO Hurtiglader 32 .......................
DE Schnelladegerät 7 ................. FI Pikalataaja 35 .......................
IT Caricatore rapido 10 ............. LV Ātras darbības lādētājs ... 37
NL Snellader 13 .......................... LT Greitas įkroviklis..............40
ES Cargador rápido 16 ............... ET Kiirlaadija 42 .........................
PT Carregador rápido 19 ............ RU Устройство быстрой
зарядки ............................45
DA Hurtigoplader 22 ...................
ZHCN
快速充电器...........................48
EL Ταχυφορτιστής ................. 24 FA ....52
TR Hızlı şarj aleti ................... 27 AR ....54
DC18RE
2
ENGLISH
Warning: This appliance can be used by children
aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they have
been given supervision or instruction concerning
use of the appliance in a safe way and understand
the hazards involved. Children shall not play with
the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
Symbols
The followings show the symbols used for the equipment. Be sure that you understand their meaning before use.
• Indoor use only. • Read instruction manual.
• DOUBLE INSULATION • Ready to charge.
• Charging. • Charging complete.
• Delay charge (Battery cooling, too cold
battery, or waiting for charging). • Defective battery.
• Conditioning • Cooling abnormality.
• Do not short battery. • Do not destroy battery by re.
• Do not expose battery to water or rain. • Always recycle battery.
• Only for EU countries
Do not dispose of electric equipment or battery pack together with household waste material!
In observance of the European Directives, on Waste Electric and Electronic Equipment and Batteries and
Accumulators and Waste Batteries and Accumulators and their implementation in accordance with national laws,
electric equipment and batteries and battery pack(s) that have reached the end of their life must be collected
separately and returned to an environmentally compatible recycling facility.
CAUTION:
1. SAVE THESE INSTRUCTIONS – This manual contains
important safety and operating instructions for battery
charger.
2. Before using battery charger, read all instructions and
cautionary markings on (1) battery charger, (2) battery,
and (3) product using battery.
3. CAUTION – To reduce risk of injury, charge only Makita
type rechargeable batteries. Other types of batteries may
burst causing personal injury and damage.
4. Non-rechargeable batteries cannot be charged with this
battery charger.
5. Use a power source with the voltage specied on the
nameplate of the charger.
6. Do not charge the battery cartridge in presence of
ammable liquids or gases.
7. Do not expose charger to rain, snow, or wet condition.
8. Never carry charger by cord or yank it to disconnect from
receptacle.
9. After charging or before attempting any maintenance
or cleaning, unplug the charger from the power source.
Pull by plug rather than cord whenever disconnecting
charger.
10. Make sure cord is located so that it will not be stepped
on, tripped over, or otherwise subjected to damage or
stress.
11. Do not operate charger with damaged cord or plug. If the
cord or plug is damaged, ask Makita authorized service
center to replace it in order to avoid a hazard.
12. Do not operate or disassemble charger if it has received
a sharp blow, been dropped, or otherwise damaged in
any way; take it to a qualied serviceman. Incorrect use
or reassembly may result in a risk of electric shock or
re.
13. Do not charge battery cartridge when room temperature
is BELOW 10°C (50°F) or ABOVE 40°C (104°F). At the cold
temperature, charging may not start.
14. Do not attempt to use a step-up transformer, an engine
generator or DC power receptacle.
15. Do not allow anything to cover or clog the charger vents.
16. Do not plug or unplug the cord and insert or remove the
battery with wet hands.
17. Never use gasoline, benzine, thinner, alcohol or the
like to clean the charger. Discoloration, deformation or
cracks may result.
(See the last part of this instruction manual for all the
illustrations.)
3
NOTE:
• The battery charger is for charging Makita-battery cartridge.
Never use it for other purposes or for other manufacturer’s
batteries.
• If charging light may ash in red color, battery condition is as
below and charging may not start.
– Battery cartridge from just-operated tool or battery cartridge
that has been left in a location exposed to direct sunlight for
a long time.
– Battery cartridge that has been left for a long time in a location
exposed to cold air.
• When the battery cartridge is too hot, charging does not begin
until the battery cartridge temperature reaches the degree at
which charging is possible.
• If the charging light ashes alternately in green and red color,
charging is not possible. The terminals on the charger or battery
cartridge are clogged with dust or the battery cartridge is worn
out or damaged.
Series Voltage Number of cells Li-ion battery cartridge Capacity (Ah)
according to IEC61960
Charging time
(Minutes)
CXT 10.8V–
12 V (max.)
3BL1015, BL1016 1.5 22
BL1020B, BL1021B 2.0 30
6 BL1040B, BL1041B 4.0 60
LXT
14.4 V
4BL1415 1.3 15
BL1415N, BL1415NA 1.5 15
8
BL1430, BL1430B 3.0 22
BL1440 4.0 36
BL1450 5.0 45
BL1460A, BL1460B 6.0 55
18 V
5
BL1815 1.3 15
BL1815N 1.5 15
BL1820, BL1820B 2.0 24
10
BL1830, BL1830B 3.0 22
BL1840, BL1840B 4.0 36
BL1850, BL1850B 5.0 45
BL1860B 6.0 55
Cooling system
• This charger is equipped with cooling fan for heated battery in
order to enable the battery to prove its own performance. Sound
of cooling air comes out during cooling, which means no trouble
on the charger.
• Yellow light will ash for warning in the following cases.
– Trouble on cooling fan
– Incomplete cool down of battery, such as, being clogged with
dust
The battery can be charged in spite of the yellow warning light.
But the charging time will be longer than usual in this case.
Check the sound of cooling fan, vent on the charger and battery,
which can be sometime clogged with dust.
• The cooling system is in order although no sound of cooling fan
comes out, if the yellow warning light will not ash.
• Always keep clean the vent on charger and battery for cooling.
• The products should be sent to repair or maintenance, if the
yellow warning light will frequently ash.
Charging
This charger can charge LXT and CXT battery alternatively.
1. Plug the battery charger into the proper AC voltage source.
Charging lights will ash in green color repeatedly.
2. Insert the battery cartridge into charger until it stops adjusting
to the guide of charger. (Fig.1)
For LXT battery, the terminal cover of the charger can be
opened with inserting and closed with pulling out the battery
cartridge.
3. When the battery cartridge is inserted, the charging light
color will change from green to red and charging will begin.
The charging light will keep lighting up steadily during
charging. One red charging light indicates charged condition
in 0–80% and red and green ones indicate 80–100%. The
80% indication mentioned above is approximate value. The
indication may differ according to battery temperature or
battery condition.
4. With nish of charge, the charging lights will change from red
and green ones to green one.
5. Charging time varies by temperature (10°C (50°F)–40°C
(104°F)) that battery cartridge is charged at and conditions of
the battery cartridge, such as a battery cartridge which is new
or has not been used for a long period of time.
6. After charging, remove the battery cartridge from charger and
unplug the charger.
NOTE:
• The charger does not charge two batteries at the same time but
charges one by one.
Conditioning charge (for LXT battery only)
Conditioning charge can extend the life of battery by automatically
searching the optimum charging condition for the batteries in every
situation.
The battery employed in the following conditions repeatedly
requires “conditioning charge” to prevent fast wear out. In that
case, yellow light lights up.
1. Recharge of battery with its high temperature
2. Recharge of battery with its low temperature
3. Recharge of full charged battery
4. Over-discharge of battery (continue to discharge battery
inspite of down of power.)
The charging time of such battery is longer than usual.
