Sida 1/20

INSTRUCTION MANUAL

Cordless Lawn Mower

DLM460

DLM461

ENGLISH: Original instructions

Read before use.

2 ENGLISH

SPECIFICATIONS

Model: DLM460 DLM461

Mowing width (blade diameter) 460 mm

No load speed 2,500 min-1

Maximum speed 3,300 min-1

Part number of replacement mower blade 199367-2 199368-0

Dimensions

(L x W x H)

during operation L: 1,319 mm to 1,518 mm

W: 532 mm

H: 879 mm to 1,138 mm

when stored

(without grass basket)

L: 1,004 mm to 1,125 mm

W: 532 mm

H: 533 mm to 713 mm

Rated voltage D.C. 36 V

Net weight 25.3 - 27.6 kg 26.6 - 28.4 kg

Protection degree IPX4

• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange

without notice.

• Specicationsandbatterycartridgemaydifferfromcountrytocountry.

• Theweightmaydifferdependingontheattachment(s),includingthebatterycartridge.Thelightestandheavi-

est combination, according to EPTA-Procedure 01/2014, are shown in the table.

Applicable battery cartridge

BL1815N / BL1820 / BL1820B / BL1830 / BL1830B / BL1840 / BL1840B / BL1850 / BL1850B / BL1860B

• Someofthebatterycartridgeslistedabovemaynotbeavailabledependingonyourregionofresidence.

WARNING: Only use the battery cartridges listed above.Useofanyotherbatterycartridgesmaycause

injuryand/orre.

Symbols

Thefollowingsshowthesymbolsusedfortheequipment.

Besurethatyouunderstandtheirmeaningbeforeuse.

Take particular care and attention.

Read instruction manual.

Danger;beawareofthrownobjects.

The distance between the tool and

bystandersmustbeatleast15m.

Neverputyourhandsandfeetnearthe

blade under the mower. Blades continue to

rotate after the motor is switched off.

Removethelockkeybeforeinspecting,

adjusting,cleaning,servicing,leavingand

storing the mower.

Ni-MH

Li-ion

OnlyforEUcountries

Donotdisposeofelectricequipmentor

batterypacktogetherwithhouseholdwaste

material!

In observance of the European Directives,

on Waste Electric and Electronic

EquipmentandBatteriesandAccumulators

and Waste Batteries and Accumulators

and their implementation in accordance

withnationallaws,electricequipmentand

batteriesandbatterypack(s)thathave

reached the end of their life must be col-

lectedseparatelyandreturnedtoanenvi-

ronmentallycompatiblerecyclingfacility.

Intended use

The tool is intended for lawn mowing.

Noise

ThetypicalA-weightednoiseleveldeterminedaccord-

ing to EN60335-2-77:

Model DLM460

Sound pressure level (L

pA) : 79 dB(A)

Sound power level (L

WA) : 91 dB (A)

Uncertainty(K):3.4dB(A)

Thenoiselevelunderworkingmayexceed80dB(A).

NOTE:

The declared noise emission value(s) has been

measured in accordance with a standard test method

andmaybeusedforcomparingonetoolwithanother.

NOTE:

Thedeclarednoiseemissionvalue(s)may

alsobeusedinapreliminaryassessmentofexposure.

WARNING: Wear ear protection.

WARNING:

The noise emission during actual

use of the power tool can differ from the declared val-

ue(s) depending on the ways in which the tool is used

especially what kind of workpiece is processed.

WARNING:

Be sure to identify safety measures

to protect the operator that are based on an estima-

tion of exposure in the actual conditions of use (tak-

ing account of all parts of the operating cycle such

as the times when the tool is switched off and when

it is running idle in addition to the trigger time).

3 ENGLISH

Vibration

The vibration total value (tri-axial vector sum) deter-

mined according to EN60335-2-77:

Model DLM460

Vibration emission (a

h) : 2.5 m/s2 or less

Uncertainty(K):1.5m/s

NOTE: The declared vibration total value(s) has been

measured in accordance with a standard test method

andmaybeusedforcomparingonetoolwithanother.

NOTE:Thedeclaredvibrationtotalvalue(s)mayalso

beusedinapreliminaryassessmentofexposure.

WARNING:

The vibration emission during actual

use of the power tool can differ from the declared val-

ue(s) depending on the ways in which the tool is used

especially what kind of workpiece is processed.

WARNING:

Be sure to identify safety measures

to protect the operator that are based on an estima-

tion of exposure in the actual conditions of use (tak-

ing account of all parts of the operating cycle such

as the times when the tool is switched off and when

it is running idle in addition to the trigger time).

EC Declaration of Conformity

For European countries only

TheECdeclarationofconformityisincludedasAnnexA

to this instruction manual.

SAFETY WARNINGS

Lawn Mower Safety Instructions

WARNING: Read all safety warnings and

all instructions. Failure to follow the warnings and

instructionsmayresultinelectricshock,reand/or

seriousinjury.

Save all warnings and instruc-

tions for future reference.

1. Do not insert the lock key into mower until it is

ready to be used.

2. Children should be supervised to ensure that

they do not play with the mower.

3. Never allow children or people unfamiliar with

these instructions to use the mower. Local

regulations can restrict the age of the operator.

4. Never operate the mower while people, espe-

cially children, or pets are nearby.

5. Keep in mind that the operator or user is

responsible for accidents or hazards occurring

to other people or their property.

While operating the mower, always wear sub-

stantial footwear and long trousers. Do not

operate the mower when barefoot or wearing

open sandals. Avoid wearing clothing or jewelry

that is loose tting or that has hanging cords or

ties. They can be caught in moving parts.

7. Always wear protective goggles to protect

your eyes from injury when using power tools.

The goggles must comply with ANSI Z87.1 in

the USA, EN 166 in Europe, or AS/NZS 1336

in Australia/New Zealand. In Australia/New

Zealand, it is legally required to wear a face

shield to protect your face, too.

It is an employer's responsibility to enforce

the use of appropriate safety protective equip-

ments by the tool operators and by other per-

sons in the immediate working area.

8. Operate the mower only in daylight or in good

articial light.

9. Avoid operating the mower in wet grass.

10. Battery tool use and care

- Recharge only with the charger specied by

the manufacturer. A charger that is suitable for

onetypeofbatterycartridgemaycreateariskof

rewhenusedwithanotherbatterycartridge.

- Use power tools only with specically desig-

nated battery cartridges.Useofanyotherbat-

terycartridgesmaycreateariskofinjuryandre.

- When battery cartridge is not in use, keep

it away from other metal objects, like paper

clips, coins, keys, nails, screws or other small

metal objects, that can make a connection

from one terminal to another. Shorting the bat-

teryterminalstogethermaycauseburnsorare.

- Under abusive conditions, liquid may be

ejected from the battery; avoid contact. If con-

tact accidentally occurs, ush with water. If

liquid contacts eyes, additionally seek medical

help.Liquidejectedfromthebatterymaycause

irritation or burns.

- Do not dispose of the battery(ies) in a re.

Thecellmayexplode.Checkwithlocalcodesfor

possible special disposal instructions.

- Do not open or mutilate the battery(ies).

Releasedelectrolyteiscorrosiveandmaycause

damagetotheeyesorskin.Itmaybetoxicif

swallowed.

- Do not charge battery in rain, or in wet locations.

11. Always keep a rm hold on the handle.

12. Always be sure of your footing on slopes.

13. Walk, never run.

14. Don't grasp the exposed cutting blades or

cutting edges when picking up or holding the

mower.

15. Physical condition - Do not operate mower

while under the inuence of drugs, alcohol, or

any medication.
