INSTRUCTION MANUAL

MANUAL DE INSTRUCCIONES

Cordless Blower

Sopladora Inalámbrica

XBU02

IMPORTANT: Read Before Using.

IMPORTANTE: Lea antes de usar.

2 ENGLISH

ENGLISH (Original instructions)

SPECIFICATIONS

Model XBU02

Capacities Air volume (max.) 0 - 13.4 m

3/min (0 - 473 cu.ft./min)

Air speed (average) 0 - 54.0 m/s (0 - 120 MPH)

Air speed (max.) 0 - 65.0 m/s (0 - 145 MPH)

Overall length (without long nozzle) 585 mm (23")

(with long nozzle) 830, 880, 930 mm (32-3/4", 34-3/4", 36-5/8")

Rated voltage D.C. 36 V

Net weight 3.5 - 4.2 kg (7.7 - 9.3 lbs)

•

Due to our continuing program of research and development, the specications herein are subject to change without notice.

• Specications and battery cartridge may di󰀨er from country to country.

• The weight may di󰀨er depending on the attachment(s), including the battery cartridge. The lightest and heavi-

est combinations, according to EPTA-Procedure 01/2014, are shown in the table.

Applicable battery cartridge and charger

Battery cartridge

BL1815N / BL1820B / BL1830 / BL1830B / BL1840B / BL1850B / BL1860B

Charger

DC18RC / DC18RD / DC18RE / DC18SD / DC18SE / DC18SF / DC18SH

•

Some of the battery cartridges and chargers listed above may not be available depending on your region of residence.

WARNING: Only use the battery cartridges and chargers listed above. Use of any other battery cartridges

and chargers may cause injury and/or re.

Recommended cord connected power source

Battery adapter BAP182

Portable power pack PDC01 / PDC1200

• The cord connected power source(s) listed above may not be available depending on your region of residence.

• Before using the cord connected power source, read instruction and cautionary markings on them.

IMPORTANT SAFETY

INSTRUCTIONS

When using an electrical appliance, basic precautions

should always be followed, including the following:

READ ALL INSTRUCTIONS.

BEFORE USING THIS

APPLIANCE

WARNING - To reduce the risk of re, electric shock,

or injury:

1. Do not leave appliance when battery tted.

Remove battery from appliance when not in use

and before servicing.

2. Do not expose to rain. Store indoors.

3. Do not allow to be used as a toy. Close attention is

necessary when used by or near children.

4. Use only as described in this manual. Use only

manufacturer's recommended attachments.

5. Do not use with damaged battery. If appliance is

not working as it should, has been dropped, dam-

aged, left outdoors, or dropped into water, return it

to a service center.

6. Do not put any object into openings. Do not use

with any opening blocked; keep free of dust, lint,

hair, and anything that may reduce air ow.

7. Keep hair, loose clothing, ngers, and all parts of

body away from openings and moving parts.

8. Use extra care when cleaning on stairs.

9. Use only the charger supplied by the manufacturer

to recharge.

SAVE THESE INSTRUCTIONS.

This appliance is intended for commercial use.

BLOWER SAFETY WARNINGS

1. Always use protective goggles, a cap and mask

when using the blower. Ordinary eye or sun

glasses are NOT safety glasses.

2. While operating the machine, always wear sub-

stantial and non-skid footwear and long trousers.

3. Do not wear loose clothing or jewellery that can be

drawn into the air inlet. Keep long hair away from

the air inlets.

4. Never point the nozzle at anyone in the vicinity

when using the blower.

3 ENGLISH

5. Never block suction inlet and/or blower outlet.

• Do not block suction inlet or blower outlet to

clean up in dusty areas.

• Do not use the blower with a tapered nozzle

smaller than the original one, such as a new

nozzle obtained by attaching an extra diam-

eter-reduced hose or smaller hose to the

nozzle top end.

• Do not Use the blower to inate balls, rubber

boat or the similar.

Increased motor revolution may cause dangerous

fan breakage and result in serious personal injury.

Heated motor and control circuit may cause a re.

6. AVOID UNINTENTIONAL STARTING. Do not

carry battery tted tool with nger on switch.

7. Some material contains chemicals which may be

toxic. Take caution to prevent dust inhalation and

skin contact. Follow material supplier safety data.

8. Make sure that there are nobody around you when

you work at high places.

9. Recharge only with the charger specied by the

manufacturer. A charger that is suitable for one

type of battery pack may create a risk of re when

used with another battery pack.

10. Use power tools only with specically designated

battery packs. Use of any other battery packs may

create a risk of injury and re.

11. When battery pack is not in use, keep it away from

other metal objects, like paper clips, coins, keys,

nails, screws or other small metal objects, that can

make a connection from one terminal to another.

Shorting the battery terminals together may cause

burns or a re.

12. Under abusive conditions, liquid may be ejected

from the battery; avoid contact. If contact acci-

dentally occurs, ush with water. If liquid contacts

eyes, additionally seek medical help. Liquid

ejected from the battery may cause irritation or

burns.

13. Do not handle charger, including charger plug, and

charger terminals with wet hands.

14. Do not charge the battery outdoors.

SAVE THESE INSTRUCTIONS.

WARNING: DO NOT let comfort or famil-

iarity with product (gained from repeated

use) replace strict adherence to safety

rules for the subject product. MISUSE or

failure to follow the safety rules stated in

this instruction manual may cause serious

personal injury.

Symbols

The followings show the symbols used for tool.

volts

direct current

Important safety instructions for

battery cartridge

1. Before using battery cartridge, read all instruc-

tions and cautionary markings on (1) battery

charger, (2) battery, and (3) product using

battery.

2. Do not disassemble or tamper the battery

cartridge. It may result in a re, excessive heat,

or explosion.

3. If operating time has become excessively

shorter, stop operating immediately. It may

result in a risk of overheating, possible burns

and even an explosion.

4. If electrolyte gets into your eyes, rinse them

out with clear water and seek medical atten-

tion right away. It may result in loss of your

eyesight.

5. Do not short the battery cartridge:

(1) Do not touch the terminals with any con-

ductive material.

(2) Avoid storing battery cartridge in a con-

tainer with other metal objects such as

nails, coins, etc.

(3) Do not expose battery cartridge to water

or rain.

A battery short can cause a large current

ow, overheating, possible burns and even a

breakdown.

6. Do not store and use the tool and battery car-

tridge in locations where the temperature may

reach or exceed 50 °C (122 °F).

7. Do not incinerate the battery cartridge even if

it is severely damaged or is completely worn

out. The battery cartridge can explode in a re.

8. Do not nail, cut, crush, throw, drop the battery

cartridge, or hit against a hard object to the

battery cartridge. Such conduct may result in a

re, excessive heat, or explosion.

9. Do not use a damaged battery.

10. The contained lithium-ion batteries are subject

to the Dangerous Goods Legislation require-

ments.

For commercial transports e.g. by third parties,

forwarding agents, special requirement on pack-

aging and labeling must be observed.

For preparation of the item being shipped, consult-

ing an expert for hazardous material is required.

Please also observe possibly more detailed

national regulations.

Tape or mask o󰀨 open contacts and pack up the

battery in such a manner that it cannot move

around in the packaging.

11. When disposing the battery cartridge, remove

it from the tool and dispose of it in a safe

place. Follow your local regulations relating to

disposal of battery.

12. Use the batteries only with the products

specied by Makita. Installing the batteries to

non-compliant products may result in a re, exces-

sive heat, explosion, or leak of electrolyte.

13. If the tool is not used for a long period of time,

the battery must be removed from the tool.
