Overview 2

Technical data 3

Instrument Set-up 5

Operations 8

How to use the adapters and wall mount 11

Message Codes 13

Accuracy Check 14

Care 16

Safety instructions 17

Optional accessories 22

Makita SK105D/SK105GD 1

OOver

ver

ververvi

viview

ewew

Ove rview

The Makita SK105D/SK105GD is a self-levelling

cross-line laser. It is a reliable precision laser for

any kind of tasks like levelling, plumbing, trans-

fering and setting out right angles.

It supports you on job side with two crossing ver-

tical and horizontal lines.

1Window of vertical line

2Window of horizontal line

3Status LED

4ON / Set key

5Levelling lock / Transportation lock

6Battery (optional)

7Tripod thread 1/4"

8DC jack

There are 2 different types available:

lSK105D (red laser)

lSK105GD (green laser)

On all images in this document only the

SK105D is shown.

Makita SK105D/SK105GD 2

TeTechni

chni

chnichnical

cal

calcal dat

dat

datdata

Te chn ica ld ata

Makita SK105D/SK105GD 3

DeDes

ssc

ccr

rri

iipti

pti

ptiption

onon SK105D

SK105D

SK105DSK105D SK105G

SK105G

SK105GSK105GD

Beam direction/fan angle Vertical / >1 0°, Horizontal / >180°6

Range* 25 m (82 ft) 35 m (115 ft)

Range* with receiver 80 m (262 ft)

Levelling accuracy ±0.3 mm/m = ±3.0 mm @ 10m (±0.004 in/ft = ±0.12 in @ 33ft)

Horizontal/Vertical line accuracy ±0.3 mm/m (±0.004 in/ft)

Self-levelling range ± 4 °

Self-levelling time < 3 s

Out-of-level warning Yes - blink lines every 5 s

Levelling system Automatic pendulum lockable

Laser type 635 ± 5 nm, Class 2 (acc. IEC 60825-1) 525 ± 5 nm, Class 2 (acc. IEC 60825-1)

Battery cartridge BL1015 / BL1016 / BL1020B / BL1021B / BL1040B / BL1041B

Operating time with Li-Ion battery

(2 beam)

15 h (BL1015/BL1016)

20 h (BL1020B/BL1021B)

40 h (BL1040B/BL1041B)

7 h (BL1015/BL1016)

10 h (BL1020B/BL1021B)

20 h (BL1040B/BL1041B)

Net weight 0.46 kg

Weight with Li-Ion battery 0.67 kg – 0.84 kg

Power supply Makita battery cartridge / USB adapter

Rated voltage D.C. 10.8 V - 12 Vmax, D.C. in 5 V

Dimensions (L x W x H) 112 x 61 x 102 mm (4.41 x 2.40 x 4.01 in)

Operating temperature (instrument) -10…+50 °C (+14…+122 °F)

Storage temperature (instrument) -25…+70 °C (-13…+158 °F)

Laser line width at 5m distance < 2 mm (<0.08 in)

Tripod thread 1/4’’ (+ 5/8’’ with adapter)

Pulse power for receiver Yes, auto

* depending on lighting conditions
