INSTRUCTION MANUAL

Cordless Grass Shear /

Cordless Hedge Trimmer

UM600D / UH201D

ENGLISH: Original instructions

Read before use.

2 ENGLISH

SPECIFICATIONS

UM600D with shear blade for grass shear installed

Model: UM600D

Cutting width 160 mm

Strokes per minute 2,500 min-1

Dimensions

(L x W x H)

347 mm x 177 mm x 131 mm

Rated voltage D.C. 10.8 V

Battery cartridge BL1015 / BL1020B / BL1040B

Net weight 1.3 - 1.4 kg

UH201D with shear blade for hedge trimmer installed

Model: UH201D

Blade length 200 mm

Strokes per minute 2,500 min-1

Dimensions

(L x W x H)

504 mm x 120 mm x 131 mm

Rated voltage D.C. 10.8 V

Battery cartridge BL1015 / BL1020B / BL1040B

Net weight 1.3 - 1.5 kg

• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange

without notice.

• Specicationsandbatterycartridgemaydifferfromcountrytocountry.

• Weight,withbatterycartridge,accordingtoEPTA-Procedure01/2003

Symbols

Thefollowingshowthesymbolsusedfortheequip-

ment. Be sure that you understand their meaning before

use.

Takeparticularcareandattention.

Read instruction manual.

Danger;beawareofthrownobjects.

Keep bystanders away.

Cutting means continues to run after the

motor is switched off.

Do not expose to moisture.

Ni-MH

Li-ion

OnlyforEUcountries

Donotdisposeofelectricequipmentor

battery pack together with household waste

material!

InobservanceoftheEuropeanDirectives,

onWasteElectricandElectronic

EquipmentandBatteriesandAccumulators

andWasteBatteriesandAccumulators

and their implementation in accordance

withnationallaws,electricequipmentand

batteries and battery pack(s) that have

reached the end of their life must be col-

lected separately and returned to an envi-

ronmentally compatible recycling facility.

Intended use

UM600D with shear blade for grass shear installed

Thetoolisintendedforcuttinglawnedgesorsprouts.

UH201D with shear blade for hedge trimmer

installed

Thetoolisintendedfortrimminghedges.

Noise

ThetypicalA-weightednoiseleveldeterminedaccord-

ingtoEN50636:

UM600D/UH201D with shear blade for grass shear

installed

Sound pressure level (L

pA):75dB(A)

Uncertainty(K):0.11dB(A)

Thenoiselevelunderworkingmayexceed80dB(A).

WARNING: Wear ear protection.

ThetypicalA-weightednoiseleveldeterminedaccord-

ingtoEN60745:

UM600D/UH201D with shear blade for hedge trim-

mer installed

Sound pressure level (L

pA):74dB(A)

Uncertainty(K):3dB(A)

Thenoiselevelunderworkingmayexceed80dB(A).

WARNING: Wear ear protection.

3 ENGLISH

Vibration

Thevibrationtotalvalue(tri-axialvectorsum)deter-

minedaccordingtoEN50636:

UM600D/UH201D with shear blade for grass shear

installed

Vibration emission (a

h):2.5m/s2 or less

Uncertainty(K):1.5m/s

Thevibrationtotalvalue(tri-axialvectorsum)deter-

minedaccordingtoEN60745:

UM600D/UH201D with shear blade for hedge trim-

mer installed

Vibration emission (a

h):2.5m/s2 or less

Uncertainty(K):1.5m/s

NOTE:

Thedeclaredvibrationemissionvaluehasbeen

measured in accordance with the standard test method

and may be used for comparing one tool with another.

NOTE:

Thedeclaredvibrationemissionvaluemay

also be used in a preliminary assessment of exposure.

WARNING:Thevibrationemissionduringactual

use of the power tool can differ from the declared

emission value depending on the ways in which the

tool is used.

WARNING: Be sure to identify safety measures

to protect the operator that are based on an estima-

tion of exposure in the actual conditions of use (taking

account of all parts of the operating cycle such as

the times when the tool is switched off and when it is

running idle in addition to the trigger time).

EC Declaration of Conformity

For European countries only

TheECdeclarationofconformityisincludedasAnnexA

to this instruction manual.

SAFETY WARNINGS

General power tool safety warnings

WARNING: Read all safety warnings and

all instructions. Failure to follow the warnings and

instructionsmayresultinelectricshock,reand/or

seriousinjury.

Save all warnings and instruc-

tions for future reference.

Theterm"powertool"inthewarningsreferstoyour

mains-operated (corded) power tool or battery-operated

(cordless) power tool.

Work area safety

1. Keep work area clean and well lit. Cluttered or

dark areas invite accidents.

2. Do not operate power tools in explosive atmo-

spheres, such as in the presence of ammable

liquids, gases or dust.Powertoolscreatesparks

which may ignite the dust or fumes.

3. Keep children and bystanders away while

operating a power tool. Distractions can cause

you to lose control.

Electrical Safety

1. Power tool plugs must match the outlet. Never

modify the plug in any way. Do not use any

adapter plugs with earthed (grounded) power

tools. Unmodiedplugsandmatchingoutletswill

reduce risk of electric shock.

2. Avoid body contact with earthed or grounded

surfaces, such as pipes, radiators, ranges and

refrigerators.Thereisanincreasedriskofelec-

tric shock if your body is earthed or grounded.

3. Do not expose power tools to rain or wet con-

ditions. Water entering a power tool will increase

the risk of electric shock.

4. Do not abuse the cord. Never use the cord for

carrying, pulling or unplugging the power tool.

Keep cord away from heat, oil, sharp edges

or moving parts. Damaged or entangled cords

increase the risk of electric shock.

5. When operating a power tool outdoors, use an

extension cord suitable for outdoor use.Useof

a cord suitable for outdoor use reduces the risk of

electric shock.

6. If operating a power tool in a damp location

is unavoidable, use a residual current device

(RCD) protected supply.UseofanRCDreduces

the risk of electric shock.

Personal Safety

1. Stay alert, watch what you are doing and use

common sense when operating a power tool.

Do not use a power tool while you are tired or

under the inuence of drugs, alcohol or med-

ication.Amomentofinattentionwhileoperating

powertoolsmayresultinseriouspersonalinjury.

2. Use personal protective equipment. Always

wear eye protection.Protectiveequipmentsuch

as a dust mask, non-skid safety shoes, hard hat or

hearing protection used for appropriate conditions

willreducepersonalinjuries.

3. Prevent unintentional starting. Ensure the

switch is in the off-position before connecting

to power source and/or battery pack, picking

up or carrying the tool. Carrying power tools with

yourngerontheswitchorenergisingpowertools

that have the switch on invites accidents.

4. Remove any adjusting key or wrench before

turning the power tool on.Awrenchorakeyleft

attached to a rotating part of the power tool may

resultinpersonalinjury.

5. Do not overreach. Keep proper footing and

balance at all times.Thisenablesbettercontrol

of the power tool in unexpected situations.

6. Dress properly. Do not wear loose clothing or

jewellery. Keep your hair, clothing, and gloves

away from moving parts.Looseclothes,jewel-

lery or long hair can be caught in moving parts.

7. If devices are provided for the connection of

dust extraction and collection facilities, ensure

these are connected and properly used.Useof

dust collection can reduce dust-related hazards.
