Sida 1/4
4K 2-Port HDMI Splitter
4K@30Hz, AC Powered, Black
Part No.: 207669
EAN-13: | UPC: 0766623207669 766623207669
Easily distribute a single Ultra-High-Definition (UHD)
signal to multiple displays.
The Manhattan 4K 2-Port HDMI Splitter with built-in booster streams a 4K HDMI
signal from a single UHD source to up to two UHD displays.
Flexible Solution for Many A/V Applications
Ideal for trade shows, classrooms, video conferencing, home theater,
presentations and retail applications, the Manhattan 4K HDMI Splitter features a
built-in booster for added signal strength. It’s a good choice for splitting and
distributing a synchronous signal to multiple 4K HDMI displays when source
equipment is remotely stored in a secured room or cabinet. Cascade multiple
units up to three levels to output HDMI video/audio on additional displays in
widely distributed applications.
Quality Construction and Easy Installation
Full compliance with HDMI, HDCP 1.4 and DVI 1.0 ensures that the Manhattan
HDMI Splitter can provide long service and reliable performance. Quickly
connect HDMI cables (not included) and the AC power adapter, and this
affordable UHD solution is complete — no software/hardware configuration or
complicated settings required.
For more information on Manhattan products, consult your local dealer or visit www.manhattan-products.com.
All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and
reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specically authorized.
Features:
Duplicates an Ultra-High-Definition (UHD) digital audio/video signal for
up to two UHD HDMI displays
4K@30Hz resolution, full 3D video and Deep Color
Supports video amplifier bandwidth up to 340 MHz, 3.4 Gbps per
channel (10.2 Gbps total) for 4Kx2K displays
Supports compressed DTS-HD Master Audio and 7.1 surround sound as
well as Dolby TrueHD and uncompressed LPCM 8 channel audio
Supports 48-bit Deep Color (12-bits per channel) and xvYCC (x.vColor)
Supports LPCM, DTS Digital, DTS-HD Master Audio and Dolby TrueHD
audio
HDCP compliant
AC powered with Plug and Play installation; no special setup or remote
required
Up to three splitters may be cascaded to support four 4K displays
Gold-plated contacts for corrosion-free connections
Works with Playstation and Xbox game systems, Blu-ray players, set-
top boxes, satellite receivers and more
Three-year warranty
Specifications:
Standards and Certifications
• HDCP 1.4
• DVI 1.0
• CTS 1.4a
• CE
• FCC
• RoHS2
General
• Source-to-splitter range: up to 15 m (49 ft.)
• Splitter-to-display range: up to 15 m (49 ft.)
• Power: 5 VDC; AC power adapter, 0.9 m (2.9 ft.)
Connections
• One HDMI port (female), 19-pin (input)
• Two HDMI ports (female), 19-pin (output)
• One DC power female, OD 3.5 mm / ID 1.3 mm (input)
Signal Input/Output
• Input video signal: 0.5 – 1.0 V p-p
• Input DDC signal: 5 V p-p (TTL)
• Maximum single-link range: 3840x2160 at 30 Hz, 4096x2160 at 24 Hz
resolution
For more information on Manhattan products, consult your local dealer or visit www.manhattan-products.com.
All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and
reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specically authorized.
• Output video: HDCP 1.4, DVI 1.0, supports 3D
• Frequency: 3.4 Gbps / 340 MHz
Video Resolutions
• DTV/HDTV: 480i/480p/576i/576p/720p/1080i/1080p/4K@30Hz
Physical
• LED indicators: power and port connection
• Dimensions: 75 x 49 x 16 mm (3 x 1.9 x 0.6 in.)
• Power adapter: 5 VDC / 1 A; 0.9 m (2.9 ft.)
• Weight: 0.04 kg (0.09 lb.)
• Housing: plastic
Operating Environment
• Operation Temperature: 0 – 40°C (32 – 104°F)
• Storage Temperature: -20 – 60°C (-4 – 140°F)
• Humidity (noncondensing): 0 – 96%
Package Contents
• 4K 2-Port HDMI Splitter
• AC power adapter
• Quick Instruction Guide
For more information on Manhattan products, consult your local dealer or visit www.manhattan-products.com.
All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and
reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specically authorized.
