4K Compact 4-Port HDMI Splitter
4K@30Hz, AC Powered, Black
Part No.: 207706
EAN-13: | UPC: 0766623207706 766623207706
Easily distribute a single Ultra-High-Definition (UHD) signal to multiple displays.
The Manhattan 4K 4-Port HDMI Splitter with built-in booster streams a 4K HDMI
signal from a single UHD source to up to four UHD displays.
Best Possible Image Quality and Easy Installation
Full compliance with HDMI and HDCP 1.4 ensures the Manhattan 4K 4-Port HDMI
Splitter provides nothing short of high-quality performance and reliability. It
delivers cinematic 4K resolution and supports 3D video, Deep Color, as well as
LPCM, DTS and Dolby TrueHD audio. Quickly connect HDMI cables (not
included) and the power supply to complete this cost-effective 4K solution — no
software or hardware configuration or complicated settings required.
Features:
Replicates an Ultra-High-Definition (UHD) digital audio/video signal for
up to four UHD HDMI displays
4K@30Hz resolution, full 3D video and Deep Color
Supports video amplifier bandwidth up to 340 MHz and 3.4 Gbps per
channel (10.2 Gbps total) for 4Kx2K displays
Supports 36-bit Deep Color (12-bits per channel) and sYCC Color Space
Supports compressed DTS-HD Master Audio, 7.1 surround sound, Dolby
TrueHD and uncompressed LPCM 8 channel audio
HDCP compliant
Multiple splitters (five total) may be cascaded up to support 16 4K
displays
For more information on Manhattan products, consult your local dealer or visit www.manhattan-products.com.
All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and
reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specically authorized.
Works with PlayStation and Xbox game systems, Blu-ray players, set-
top boxes, satellite receivers and more
Plug and play
Gold-plated contacts for corrosion-free connections
Three-year warranty
Specifications:
Standards and Certifications
• HDCP 1.4
• CTS 1.4b
• CE
• FCC
• RoHS2
General
• Source-to-splitter and splitter-to-display range: up to 15 m (49 ft.)
• Power adapter: 5 VDC / 1 A; 70 cm (2.3 ft.)
• Power consumption: 5 W
Connections
• One HDMI female (input)
• Four HDMI female (output)
• One 5 VDC power female (input)
Signal Input/Output
• Input video signal: 0.5 – 1.0 V p-p
• Input DDC signal: 5 V p-p (TTL)
• Maximum single-link range: 10.2 Gbps and 4096x2160 at 24 Hz resolution
• Output video: HDMI 1.4, HDCP 1.4
Supported Video Resolutions
• DTV/HDTV: 480i/480p/576i/576p/720p/1080i/1080p/4K@30Hz
Physical
• LED indicators: power and port connection
• Reset button
• Dimensions: 81 x 58 x 18 mm (3.2 x 2.3 x 0.7 in.)
• Weight: 0.3 kg (10.6 oz.)
• Housing: plastic
Operating Environment
• Operation Temperature: 0 – 40°C (32 – 104°F)
• Storage Temperature: -20 – 60°C (-4 – 140°F)
• Humidity (noncondensing): 0 – 96%
Package Contents
For more information on Manhattan products, consult your local dealer or visit www.manhattan-products.com.
All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and
reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specically authorized.
• 4K Compact 4-Port HDMI Splitter
• Power adapter
• Quick Instruction Guide
For more information on Manhattan products, consult your local dealer or visit www.manhattan-products.com.
All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and
reproduction of this document, and use and disclosure of the contents herein, are prohibited unless specically authorized.
