Model

709095

Get fast data access, create portable storage and

simplify hard-disk drive exchanges.

Ideal for IT technicians and desktop or notebook computer owners with numerous hard-disk

drives, the MANHATTAN® SATA Quick Dock eliminates the need for multiple external enclosures

and inconvenient PC case installation and removal. The spring-loaded door and dual slot safely

accepts and firmly holds 3.5” and 2.5” hard-disk drives with easy “pop-in/pop-out” operation.

Its compact size with heavy-duty construction and rubber underside mounts help isolate and

reduce vibration to keep the MANHATTAN SATA Quick Dock and an installed drive securely

in place on a desk or technician’s bench.

Easy to Install and Use

Plug and Play with Windows compatibility quickly installs the MANHATTAN SATA Quick Dock in seconds

through an available USB port without special drivers or complicated conﬁguration. Its hot-swap capability

allows rapid, multi-HDD exchanges and quick data access without computer restarts.

Lifetime Warranty

Strict manufacturing standards ensure the highest quality in all MANHATTAN products. All items

carry a full Lifetime Warranty — the strongest quality commitment anyone can make.

SATA Quick Dock

Hi-Speed USB 2.0, SATA, 3.5” / 2.5”

Features

• Provides fast data access, creates portable

storage and simpliﬁes hard-disk drive backup

and exchanges

• Dual insertion slot accepts 3.5” and 2.5” SATA

hard-disk drives up to 1 TB

• Quick and easy USB installation — no special

drivers or conﬁguration required

• Supports Hi-Speed USB 2.0 data transfer rates

up to 480 Mbps

• Windows compatible; Plug and Play and hot-

swappable

• Lifetime Warranty

Speciﬁcations

STANDARDS AND CERTIFICATIONS

• USB 2.0

• USB 1.1

• SATA 300

• FCC

• CE

GENERAL

• Sunplus SPIF225A chipset

• Connections: external, DC power input and USB

type B; internal, SATA data and power

• Dual insertion slot with eject button ts 2.5” and

3.5” SATA HDD

• Power and activity LED indicators with power

button

TRANSFER RATE

• Hi-Speed USB 2.0 480 Mbps

PHYSICAL

• Power adapter, 140 cm (55 in.)

• USB cable: 120 cm (47 in.)

• Dimensions: 13 x 9 x 6.8 cm (5.1 x 3.5 x 2.7 in.)

• Weight: 561.3 g (19.8 oz.)

ELECTRICAL

• Input: 100 – 240 V AC; 50/60 Hz / 0.4 A

• Output: +12 V / 2 A center post

SYSTEM REQUIREMENTS

• Available USB type A port

• Windows 2000/XP/Vista compatible

PACKAGE CONTENTS

• SATA Quick Dock

• Power adapter and USB cable

• Reference guide

Model

709095

MH-709095-DS-0708-03

All names of products or services mentioned herein are trademarks or registered trademarks of their respective owners. Distribution and reproduction of this document, and use and disclosure of

the contents herein, are prohibited unless speciﬁcally authorized.

For more information on MANHATTAN products, consult your

local dealer or visit

www.manhattan-products.com
