Sida 1/57
1
ENGLISH
FOREWORD
This section must be read carefully before any connection is
made to the mains supply.
WARNINGS
Do not expose the equipment to rain or moisture.
Do not remove the cover from the equipment.
Do not insert anything into the equipment through the
ventilation holes.
Do not handle the mains lead with wet hands.
Make a space of about 0.1 meter around the unit.
CE marking
This product is in conformity with the EMC
directive and low-voltage directive.
EQUIPMENT MAINS WORKING SETTING
Your Marantz product complies with the household power and
safety requirements in your area.
IMPORTANT: (FOR UK version only)
This apparatus is fitted with an approved moulded 13 Amp plug.
To change a fuse in this type of plug proceed as follows:
1. Remove fuse cover and fuse.
2. Fix new fuse which should be a BS1362 5A, A.S.T.A. or BSI
approved type.
3. Refit the fuse cover.
If the fitted plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place.
If the mains plug contains a fuse, this should have a value of 5A.
If a plug without a fuse is used, the fuse at the distribution board
should not be greater than 5A.
NOTE : The severed plug must be destroyed to avoid a possible
shock hazard should it be inserted into a 13A socket
elsewhere.
HOW TO CONNECT A PLUG
The wires in the mains lead are coloured in accordance with the
following code:
BLUE—”NEUTRAL” (“N”)
BROWN—”LIVE” (“L”)
1. The BLUE wire must be connected to the terminal which is
marked with the letter “N” or coloured BLACK.
2. The BROWN wire must be connected to the terminal which is
marked with the letter “L” or coloured RED.
3. Do not connect either wires to the earth terminal in the plug
which is marked by the letter “E” or by the safety earth symbol
or coloured green or green-and-yellow.
Before replacing the plug cover, make certain that the cord grip
is clamped over the sheath of the lead — not simply over the two
wires.
PRECAUTIONS
The following precautions should be taken when operating the
equipment.
GENERAL PRECAUTIONS
When installing the equipment ensure that:
– the ventilation holes are not covered.
– air is allowed to circulate freely around the equipment.
– it is placed on a vibration-free surface.
– it will not be exposed to excessive heat, cold, moisture or dust.
– it will not be exposed to direct sunlight.
– it will not be exposed to electrostatic discharges.
In addition, never place heavy objects on the equipment.
If a foreign object or water does enter the equipment, contact
your nearest dealer or service center.
Do not pull out the plug by pulling on the mains lead; grasp the
plug.
It is advisable when leaving the house, or during a thunderstorm,
to disconnect the equipment from the mains supply.
2
ENGLISH
Features of This Player
Compatible with DVD, Video CD and
CD formats
DVD, Video CD and CD discs that display the logos shown
below can be played back on MARANTZ DVD players. For
more information on discs compatible with this player, refer to
the table below.
The disc format logos shown above are found on disc labels
or on disc jackets.
• To prevent malfunction, do not use an 8 cm (3 in.) adaptor
(for CDs).
• Discs other than the ones indicated above cannot be
played on this unit.
• DVDs that have incompatible region numbers, DVD-Audio,
DVD-ROM, and CD-ROM cannot be played on this unit.
The region number of the player can be found on the rear
panel.
*1Playing recordable CDs
• Note that this unit cannot record onto recordable discs.
• This unit can play music-use CD-R and CD-RW discs. However,
depending on the condition of the player and the disc, you may
find that not all discs will play successfully. (For example, if the
disc is scratched or dirty, or if the player’s pickup lens is dirty.)
12 cm (5in.)/
single-sided
12 cm (5in.)/
double-sided
8 cm (3 in.)/
single-sided
8 cm (3 in.)/
double-sided
1 layer
2 layer
1 layer
2 layer
1 layer
2 layer
1 layer
2 layer
DVD VIDEO DVD VIDEO
Types of playable
discs and their marks
Diameter/
Playable sides Playback time
Digital audio
Digital video
(MPEG 2)
133 min.
242 min.
266 min.
484 min.
VIDEO CD
CD
Digital audio
Digital video
(MPEG 2)
DVD VIDEO
VIDEO CD
CD
41 min.
75 min.
82 min.
150 min.
VIDEO CD single
CD single
Digital audio
Digital video
(MPEG 1)
Max. 74
minutes
Digital audio
Digital video
(MPEG 1)
Max. 20
minutes
Digital audio
Max. 74
minutes
12 cm (5 in.)/
single-sided
8 cm (3 in.)/
single-sided
12 cm (5 in.)/
single-sided
8 cm (3 in.)/
single-sided
Digital audio
Max. 20
minutes
*1
*1
CONGRATULATIONS ON YOUR PURCHASE OF THIS
FINE MARANTZ PRODUCT.
MARANTZ is on the leading edge of DVD research for
consumer products and this unit incorporates the latest
technological developments.
We are sure you will be fully satisfied with the DVD player.
Thank you for your support.
Please read through these operating instructions so you
will know how to operate your model properly. After you
have finished reading the instructions, put them away in a
safe place for future reference.
• This player is not suitable for commercial use.
This product incorporates copyright protection
technology that is protected by method claims of certain
U. S. patents and other intellectual property rights owned
by Macrovision Corporation and other rights owners. Use
of this copyright protection technology must be
Authorized by Macrovision Corporation, and is intended
for home and other limited viewing uses only unless
otherwise authorized by Macrovision corporation.
Reverse engineering or disassembly is prohibited.
3
ENGLISH
Wide range of DVD viewing options
Multi-Angle (page 31)
You can view scenes from different camera angles when
watching movies or other media with multiple angle playback
available.
Multiple Languages (page 34)
You can select the language on when watching movies or
other media that have multiple language and/or audio
soundtracks recorded on them.
Multi-Language Subtitles (page 35)
You can select a subtitle language or turn subtitles off when
watching movies or other media with subtitles available.
This mark indicates this may not be possible with certain discs.
Audio : 1 English
Dolby Digital
5.1CH Audio : 2 Spanish
HELLO
HOLA
Dolby Digital
5.1CH
HELLO! HOLA!
Subtitle :1 English Subtitle :2 Spanish
ANGLE : 3/4
ANGLE : 2/4
Compatible with a wide range of DVD
digital audio output formats
DVDs are recorded in one of four types of digital audio
formats (as of October 1998). The digital audio output jacks
of this player output Dolby Digital*, DTS**, MPEG, and linear
PCM digital bitstreams.
This player has a function that converts Dolby Digital and
MPEG audio formats into the linear PCM format. This allows
playback of DVDs recorded in Dolby Digital and MPEG
without the need for a decoder.
Equipped with six channel discrete audio output
and an internal Dolby Digital and DTS decoder
Enjoy the cinematic surround sound produced by Dolby
Digital and DTS audio soundtracks without the need for an
external decoder. This player features six channel discrete
audio output jacks so you can connect this player directly to
an amplifier or receiver with 6 channel discrete input, and
utilize the player’s built-in Dolby Digital and DTS decoding
capabilities.
Multiple video output formats that can be selected
to best suit your TV or monitor
This player features one composite, one S-video jacks, and
one AV CONNECTOR terminals. RGB signal output is
possible from the AV CONNECTOR terminal.
TruSurround and Virtual Dolby Digital
TruSurround*** uses technology that simulates multichannel
surround sound using only two speakers. Virtual Dolby Digital
works in conjunction with Dolby Digital audio sources to
create a realistic surround sound. Virtual Dolby Digital is
selected automatically when Dolby Digital sources are
loaded.
Frame advance playback in foward and reverse
direction
This player incorporates technology that enables frame
advance playback of DVDs. In the foward direction, the
playback speed can be adjusted four steps. In the reverse
direction, the playback speed can be adjusted two steps.
1
Answer a few questions and
have all the necessary audio,
video, and on-screen
language adjustments set
automatically by the player
using the Setup Navigator
(page 15).
Audio1 Audio2 GeneralLanguageVideo
Setup Navigator
Move
Exit
SETUP
Select
ENTER
Setup Navigator
Auto Start Off
Start
Easy setup and adjustment using on-
screen menus
Press SETUP on the remote control to open the Setup screen
and you’ll find setting up and adjusting the system easy to do
with on-screen menus conveniently organized and arranged.
Additionally, on-screen information (
i
)❖ appears to clarify
the functions and explain the options available. Below are just
a few examples.
Set up the on-screen
speaker system to match
your home audio system in
the Audio 2 menu for ideal
presentation of multichannel
audio (page 28).
Audio1 Audio2 GeneralLanguageVideo
Speaker Setting
Center
On
—/+
SETUP
Move
Exit
ENTER
Select
Speaker
Return
L R
SW
LS RS
RETURN
* Manufactured under license from Dolby Laboratories. “Dolby” and
the double-D symbol are trademarks of Dolby Laboratories.
Confidential unpublished works, © 1992-1997 Dolby Laboratories.
All rights reserved.
** “DTS” and “DTS Digital Surround” are trademarks of Digital
Theater Systems, Inc. Manufactured under license from Digital
Theater Systems, Inc.
*** TruSurround and the symbol are trademarks of SRS Labs, Inc.
in the United States and selected foreign countries. TruSurround
technology is incorporated under license from SRS Labs, Inc.

Produktspecifikationer

Varumärke: Marantz
Kategori: Inte kategoriserad
Modell: DV2100

Behöver du hjälp?

Om du behöver hjälp med Marantz DV2100 ställ en fråga nedan och andra användare kommer att svara dig


Inte kategoriserad Marantz Manualer

Marantz

Marantz Sound Shield Bruksanvisning

9 Oktober 2024
Marantz

Marantz Sound Shield Live Bruksanvisning

26 September 2024
Marantz

Marantz MPM-500A Bruksanvisning

26 September 2024
Marantz

Marantz MPM-3500R Bruksanvisning

26 September 2024
Marantz

Marantz Audio Scope SG-5BC Bruksanvisning

26 September 2024
Marantz

Marantz PS2100 Bruksanvisning

14 September 2024
Marantz

Marantz SR2100 Bruksanvisning

13 September 2024
Marantz

Marantz PM7003 Bruksanvisning

13 September 2024
Marantz

Marantz DV2100 Bruksanvisning

13 September 2024
Marantz

Marantz DR4160 Bruksanvisning

13 September 2024

Inte kategoriserad Manualer

Nyaste Inte kategoriserad Manualer

Franke

Franke ANX211RHD Bruksanvisning

11 December 2024
Franke

Franke Urban UBG 610-78 Bruksanvisning

11 December 2024
Xblitz

Xblitz R4 Power Bruksanvisning

11 December 2024
Xblitz

Xblitz R8 Power Charge Bruksanvisning

11 December 2024
SurgeX

SurgeX SA-20-AR Bruksanvisning

11 December 2024
Angler

Angler PortaScreen Bruksanvisning

11 December 2024
Angler

Angler Muslin Bruksanvisning

11 December 2024
Angler

Angler Chromakey Bruksanvisning

11 December 2024
Angler

Angler Beauty Reflector EG-53 Bruksanvisning

11 December 2024
Angler

Angler Beauty Reflector EG-55 Bruksanvisning

11 December 2024
