B r o a d c a s t A / V D i v i s i o n
Operation Guide
V-SG4K-3G
HDMI / SDI Portable Signal Generator
1
Table of Contents
Table of Contents
8. Software - PC Control App
4. Specications
2. Features
6. Quick Start and System Check
1. Introduction
9. Software - Test Pattern Uploader App
10. Troubleshooting
11. Warranty & Contact Information
5. Package Contents
3. Controls and Connections
7. Menu Operations
01
09
06
03
07
02
18
20
21
06
04
07
5
1. RS-232 connector for PC control. Provides an alternative to the USB connection for control
from a PC.
2. SDI Output BNC connector.
3. Stereo Audio Input connector (3.5 mm mini-phone). Allows embedding of custom audio into
the HDMI or SDI video output.
4. HDMI Output / EDID capture connector.
5. 5-Volt DC Power connector. Note: Please use only 5-volt power sources, center pin positive.
Similar-looking 12-volt power supplies are common and may damage the unit if connected.
Rear Panel Description
1 2 3 4 5
