Marshall Electronics

Model No. V-LCD17H

Rack Mountable High Definition LCD Monitor

Operating Instructions

Edition 1 Revision 5P

This page intentionally left blank

Maintenance

■ Screen Cleaning

Periodically clean the screen surface using ammonia-free cleaning wipes (Marshall Part No. V-HWP-K). A clean micro-fiber cloth

can also be used using only non-abrasive and ammonia-free cleaning agents. Do not use paper towels. Paper towel fibers are

coarse and may scratch the surface of the polycarbonate faceplate or leave streaks on the surface. Antistatic and fingerprint

resistant cleaning agents are recommended. Do not apply excessive pressure to the screen to avoid damaging the LCD.

■ Faceplate Dusting

Dust the unit with a soft, damp cloth or chamois. Dry or abrasive cloths may cause electrostatic charge on the surface, attracting

dust particles. Neutralize static electricity effects by using the recommended cleaning and polishing practice.

Warranty

Marshall Electronics warranties to the first consumer that this V-LCD17H LCD monitor will, under normal use, be free from

defects in workmanship and materials, when received in its original container, for a period of one year from the purchase date.

This warranty is extended to the first consumer only, and proof of purchase is necessary to honor the warranty. If there is no

proof of purchase provided with a warranty claim, Marshall Electronics reserves the right not to honor the warranty set forth

above. Therefore, labor and parts may be charged to the consumer. This warranty does not apply to the product exterior or

cosmetics. Misuse, abnormal handling, alterations or modifications in design or construction void this warranty. It is considered

normal for a minimal amount of pixels, not to exceed three, to fail on the periphery of the display active viewing area. Marshall

Electronics reserves the option to refuse service for display pixel failure if deemed unobtrusive to effective use of the monitor by

our technicians. No sales personnel of the seller or any other person is authorized to make any warranties other than those

described above, or to extend the duration of any warranties on behalf of Marshall Electronics, beyond the time period

described above. Due to constant effort to improve products and product features, specifications may change without notice.

This page intentionally left blank

Table of Contents

Installation and Initial Setup ------------------------------------------------------------------------------------------------------5

Top and Front Panel Features ----------------------------------------------------------------------------------------------------7

Rear Panel Features-----------------------------------------------------------------------------------------------------------------8

Input Module Installation----------------------------------------------------------------------------------------------------------9

MAIN MENU AND NAVIGATION------------------------------------------------------------------------------------------------ 10

VIDEO CONFIGURATION SUBMENU....................................................................................................................................................10

MARKER CONFIGURATION SUBMENU ................................................................................................................................................13

FILTER CONFIGURATION SUBMENU....................................................................................................................................................16

SYSTEM CONFIGURATION SUBMENU .................................................................................................................................................17

FUNCTION PRESETS SUBMENU ...........................................................................................................................................................18

IMD CONFIGURATION .........................................................................................................................................................................19

SYSTEM INFORMATION SUBMENU .....................................................................................................................................................20
