Marshall Electronics, Inc.

1910 East Maple Ave.

El Segundo, CA 90245

Tel: (800) 800-6608 / (310) 333-0606 • Fax: 310-333-0688

www.LCDRacks.com sales@lcdracks.com •

511v2 1

Marshall Electronics

Model No. V-LCD70XHB-HDA

Model No.V-LCD70XHB-HDMIPT

Model No.V-LCD70XHB-3GSDI

7” Portable Field / Camera-Top Monitor

Operating Instructions

Maintenance

■ Screen Cleaning

Periodically clean the screen surface using ammonia-free cleaning wipes (Marshall Part No. ). A clean micro-V-HWP-K

fiber cloth can also be used using only non-abrasive and ammonia-free cleaning agents. Do not use paper towels.

Paper towel fibers are coarse and may scratch the surface of the polycarbonate faceplate or leave streaks on the

surface. Antistatic and fingerprint resistant cleaning agents are recommended. Do not apply excessive pressure to the

screen to avoid damaging the LCD.

■ Faceplate Dusting

Dust the unit with a soft, damp cloth or chamois. Dry or abrasive cloths may cause electrostatic charge on the surface,

attracting dust particles. Neutralize static electricity effects by using the recommended cleaning and polishing practice.

Warranty

Marshall Electronics warranties to the first consumer that this LCD monitor will, under normal use, V-LCD70XHB series

be free from defects in workmanship and materials, when received in its original container, for a period of one year from

the purchase date. This warranty is extended to the first consumer only, and proof of purchase is necessary to honor the

warranty. If there is no proof of purchase provided with a warranty claim, Marshall Electronics reserves the right not to

honor the warranty set forth above. Therefore, labor and parts may be charged to the consumer. This warranty does not

apply to the product exterior or cosmetics. Misuse, abnormal handling, alterations or modifications in design or

construction void this warranty. It is considered normal for a minimal amount of pixels, not to exceed three, to fail on the

periphery of the display active viewing area. Marshall Electronics reserves the option to refuse service for display pixel

failure if deemed unobtrusive to effective use of the monitor by our technicians. No sales personnel of the seller or any

other person is authorized to make any warranties other than those described above, or to extend the duration of any

warranties on behalf of Marshall Electronics, beyond the time period described above. Due to constant effort to improve

products and product features, specifications may change without notice.

Dimensions

Contents

Installation and Initial Setup ................................................................................................................................................ 4

Front and Side Monitor Features......................................................................................................................................... 6

Rear Monitor Features .......................................................................................................................................................... 7

Compatible Input Formats.................................................................................................................................................... 8

Menu Overview ...................................................................................................................................................................... 9

Main Menu and Navigation................................................................................................................................................. 11

Video Configuration Submenu ...................................................................................................................................... 11

Marker Configuration Submenu .................................................................................................................................... 16

Filter Configuration Submenu ....................................................................................................................................... 19

System Configuration Submenu ................................................................................................................................... 20

Function Presets Submenu ........................................................................................................................................... 23

System Information Submenu....................................................................................................................................... 24

Specifications ...................................................................................................................................................................... 25

Dimensions .......................................................................................................................................................................... 26

Maintenance......................................................................................................................................................................... 27

Warranty............................................................................................................................................................................... 27
