OmniTik series
Quick setup guide and warranty information
The OmniTik is an outdoor wireless system with a built in antenna. It can be used as a wireless Access Point, CPE
or for point-to-point links. It supports wireless operation in the 5GHz range (specific frequencies depend on region).
Mounting
Slide the included pole mount adapter with the clip facing forward, until the clip clicks into place. Use the included
hose clamp to attach the unit to a pole or mast. Adjustable QuickMount adapters are available separately. The
OmniTik has a locking screw that secures the port door, it can be closed with a 5mm hex screwdriver.
Connecting
1. Open the Ethernet port door to connect your PC or LAN cables to the Ethernet ports, connect the other end
of the Ethernet cable to a PoE injector
2. Set LAN computer IP configuration to automatic (DHCP)
3. Default IP address of the unit is 192.168.88.1, open this address in your web browser to start configuration.
The username is and there is admin no password
Powering
The device accepts power from passive and active (802.3af/at) power sources. A passive PoE injector is included
in the box.
Power output
Applies only to OmniTik 5 PoE ac: This device can supply PoE power to external devices from its Ethernet ports.
This is convenient as you don't need any additional PoE injectors to power other devices. The output voltage will be
the same as input voltage. Maximum power output of each Ethernet port in this mode is 1A (total maximum for all
ports is 2A). To reach maximum output power it is recommended to use a high voltage adapter together with the
included PoE injector to power the OmniTik unit (48/56V), because 802.3af/at input is limited to 30W and OmniTik
will consume up to 15W by itself. Once Power Output is enabled in RouterOS, the Ethernet LED adds red color to
it (green means Ethernet link is made, red means power but no link, red and green both means there is link and
power).
Booting process
Initial connection has to be done via the Ethernet cable from the LAN side. Open 192.168.88.1 in your web
browser. Username is and there is . In case IP connection is not available, WinBox can be admin no password
used to connect to the MAC address of the device. More information here:
http://wiki.mikrotik.com/wiki/First_time_startup
In case you wish to boot the device from network, for example to use MikroTik Netinstall, hold the RESET button of
the device when starting it until the LED light turns off, and device will start to look for Netinstall servers.
Extension slots and ports
Five 10/100/1000 Gigabit Ethernet ports, supporting automatic cross/straight cable correction (Auto
MDI/X), so you can use either straight or cross-over cables for connecting to other network devices.
One integrated wireless 5GHz 802.11a/n/ac, 2x2 MIMO with built in grid antenna, max gain 7.5dBi
See www.routerboard.com for more information. Contact 6-May-16support@mikrotik.com
Buttons and jumpers
RouterBOOT reset button (RESET, front panel) has three functions:
•Hold this button during boot time until LED light starts flashing, release the button to reset RouterOS
configuration (total 5 seconds)
•Keep holding for 5 more seconds, LED turns solid, release now to turn on CAPs mode
(total 10 seconds)
•Or Keep holding the button for 5 more seconds until until LED turns off, then release it to make the
RouterBOARD look for Netinstall servers (total 15 seconds)
Operating system support
Currently tested operating system is MikroTik RouterOS starting from version 6.30
Copyright and warranty information
Copyright MikroTikls SIA. This document contains information protected by copyright law. No part of it may be
reproduced or transmitted in any form without prior written permission from the copyright holder. RouterBOARD,
RouterOS, RouterBOOT and MikroTik are trademarks of MikroTikls SIA. All trademarks and registered trademarks
appearing in this document are the property of their respective holders.
Hardware. MikroTik warrants all RouterBOARD series equipment for the term of twelve (12) months from the
shipping date to be free of defects in materials and workmanship under normal use and service, except in case of
damage caused by mechanical, electrical or other accidental or intended damages caused by improper use or due
to wind, rain, fire or other acts of nature.
To return failed units to MikroTik, you must perform the following RMA (Return Merchandise Authorization)
procedure. Follow the instructions below to save time, efforts, avoid costs, and improve the speed of the RMA
process.
1. If you have purchased your product from a MikroTik Reseller, please contact the Reseller company
regarding all warranty and repair issues, the following instructions apply ONLY if you purchased your
equipment directly from MikroTik in Latvia.
2. MikroTik does not offer repairs for products that are not covered by warranty. Exceptions can be made for:
CCR1016-12G, CCR1016-12G-BU, CCR1036-12G-4S, RB1100, RB1100AH, RB1100AHx2, RB1200,
RB600, RB600A and RB800 as a paid service (fees apply).
3. Out-of-warranty devices and devices not covered by warranty sent to Mikrotik will be returned to the sender
at sender's cost. If the customer has not organized return of such rejected devices within 12 months from
the day of arrival, MikroTik has the right to discard them.
RMA Instructions are located on our webpage here: http://rma.mikrotik.com
This document is provided “as is” without a warranty of any kind, expressed or implied, including, but not limited to,
the implied warranty of merchantability and fitness for a particular purpose. The manufacturer has made every
effort to ensure the accuracy of the contents of this document, however, it is possible that it may contain technical
inaccuracies, typographical or other errors. No liability is assumed for any inaccuracy found in this publication, nor
for direct or indirect, incidental, consequential or other damages that may result from such an inaccuracy, including,
but not limited to, loss of data or profits. Please report any inaccuracies found to support@mikrotik.com
See www.routerboard.com for more information. Contact 6-May-16support@mikrotik.com
Federal communication commission interference statement
(FCC ID: TV7OMNITIKPG5HACD )
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
This device and its antenna must not be co-located or operation in conjunction with any other antenna or
transmitter.
IMPORTANT: Exposure to Radio Frequency Radiation.
13 cm minimum distance has to be maintained between the antenna and the occupational user and 28 cm to
general public. Under such configuration, the FCC radiation exposure limits set forth for an population/uncontrolled
environment can be satisfied.
Antenna Installation. WARNING: It is installer's responsibility to ensure that when using the authorized antennas
in the United States (or where FCC rules apply); only those antennas certified with the product are used. The use
of any antenna other than those certified with the product is expressly forbidden in accordance to FCC rules CFR47
part 15.204. The installer should configure the output power level of antennas, according to country regulations and
per antenna type. Professional installation is required of equipment with connectors to ensure compliance with
health and safety issues.
Industry Canada (IC: 7442A-OMNTKPG5AC)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following
two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement.
See www.routerboard.com for more information. Contact 6-May-16support@mikrotik.com
