MA-708

User Guide

PORTABLE WIRELESS PA SYSTEM

Portability

Simplicity

Flexibility

2 CE5 3 7 A

Do not copy or forward without prior approvals MIPRO.

Specifications and design subject to change without notice.

MN015/03

THIS DEVICE COMPLIES WITH PART15 OF THE FCC RULES AND RSS-123 ISSUE2 OF CANADA.

OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:

(1) This device may not cause interference.

(2) This device must accept any interference, including interference that may cause undesired

operation of the device. This equipment complies with FCC RF radiation exposure limits set forth

for an uncontrolled environment.

“This product can only be used at the area that the altitude is lower than 2000m for safety

purpose.”

“This product can be used in non-tropical locations only for safety purpose.”

& IC - ID

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any ventilation openings. Install in accordance with the manufacturer's

instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other

apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarised or ground plug: A polarised plug has two

blades with one wider than the other. The wide blade is provided for your safety. When

the provided plug does not fit into your outlet, consult an electrician for replacement of the

obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plug, convenience

receptacles, and the point where they exit from the apparatus.

11. Only use attachments/accessories specified by the manufacturer.

12. Use only with a cart, stand, tripod, bracket, or table specified by the

manufacturer, or sold with the apparatus. When a cart is used, use

caution when moving the cart/apparatus combination to avoid injury

from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus

has been damaged in any way, such as power-supply cord or plug is damaged, liquid has

been spilled or objects have fallen into the apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or has been dropped.

15. To reduce the risk of fire or electric shock, do not expose this apparatus to rain or

moisture.

16. Apparatus should not be exposed to dripping or splashing and no objects filled with liquids,

should be placed on the apparatus.

17. Use only with the battery which specified by manufacturer.

18. The power supply cord set is to be the mains disconnected device.

19. Where the MAINS plug or an appliance coupler is used as the disconnect device, the

disconnect device shall remain readily operable.

20. Maximum operating temperature range is 50°C (122°F).

Note: Battery characteristics may limit this range.

IMPORTANT SAFETY INSTRUCTIONS WARNING

1. FOR OUTDOOR USE:

To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.

2. UNDER WET LOCATION:

Apparatus should not be exposed to dripping or splashing and no objects filled with liquids,

such as vases should be placed on the apparatus.

3. SERVICE INSTRUCTIONS:

CAUTION - These servicing instructions are for use by qualified service personnel only. To

reduce the risk of electric shock, do not perform any servicing other than that contained in

the operating instructions unless you are qualified to do so.

This symbol indicates that dangerous voltage constituting a risk of electric shock

is present within this unit.

This symbol indicates that there are important operating and maintenance

instructions in the literature accompanying this unit.

Disposal

2005-08-13

2005-08-132005-08-13

Dispose of any unusable devices or batteries responsibly and in accordance with

any applicable regulations.

Disposing of used batteries with domestic waste is to be avoided!

Batteries/NiCad cells often contain heavy metals such as cadmium(Cd),

mercury(Hg) and lead(Pb) that makes them unsuitable for disposal with domestic

waste. You may return spent batteries/accumulators free of charge to recycling

centres or anywhere else batteries/accumulators are sold.

By doing so, you contribute to the conservation of our environment!

CONTENTS

CONTROLS AND INDICATORS

CONTROL PANEL ---

OPERATING INSTRUCTIONS

CONNECTION FOR EXTERNAL AUDIO SOURCES 05

OPERATION OF TRANSMITTERS STORAGE

REPLACING BATTERIES --

POWER USAGE INSTRUCTION

SELECTION AND INSTALLATION OF WIRELESS RECEIVER MODULES

UHF WIRELESS DIVERSITY RECEIVER MODULE

SET-UP RECEIVER AND TRANSMITTER FREQUENICES

WIRELESS INTERLINKING TRANSMITTER AND RECEIVER MODULES

COMPARTMENT FOR BODYPACK TRANSMITTER

INSTALLATION OF MIPRO CD/MP3 PLAYER 15

TROUBLESHOOTING-PORTABLE PUBLIC ADDRESS 16

TROUBLESHOOTING-WIRELESS MICROPHONE SYSTEMS -- 17

FAQ - PORTABLE PA 18

FAQ - RECHARGEABLE BATTERY 18

RECHARGEABLE BATTERY GUIDE -- 19 --

OPTIONAL MA-708 ACCESSORIES -------- - -

MIPRO WIRELESS MICROPHONE SYSTEMS 21

---------------------------------------------------- 01

--------------------------------------------------------------- 03

----------------------------------------------------- 05

--------------------------------

-------------------------------------- 06

-------------------------------------------------------- 07

---------------------------------------------------- 09

--------- 10

-------------------------------- 11

------------------------- 12

--------- 13

-------------------------------- 14

--------------------------------------

------------------------------

---------------------

---------------------------------------------------------------

--------------------------------------------------

-------------- ------------------------------

----- -- ------------------------------ 20

--- -- ------------------------------- -

00 01

Portable Wireless PA SystemPortable Wireless PA System

Retractable Carry Handle: Pull the handle upward from the space on the rear center to

retrieve retractable handle. Push downward to store the retractable handle.

Fixed Handle: For balanced, easy hand carrying.

Storage Compartment: A handy storage compartment for 2 wireless

handheld or bodypack transmitters.

Treble Speaker: 1" Titanium Compression Driver.

Bass Speaker: 8" Neodymium Cone Driver.

Speaker Grille: To protect the internal speaker.

Tripod Mount (Optional): There is a tripod mating socket mounted in the base of the

MA-708 to accommodate a 35mm tripod stand.

Transmitters

Front Panel

CONTROLS AND INDICATORS

Tripod Mount

(Optional)

Speaker Grille

Fixed Handle

Transmitters Storage

Compartment

Retractable Carry Handle

Treble Speaker

Bass Speaker

MMA

AA-

--7

770

008
