Specications

Technical specications

Alkaline

Panasonic Typical Dimensions

IEC Dimensions

(mm)

Dimension Maximum Minimum

A 44,5

B 43,3

C 4,3

E 0,5

F 3,8

G 0,8

Ø 10,5 9,5

Name LR03 / S / AAA / AM4 / MICRO / MN2400 / 24A / 24AC

Made in Belgium

Type Alkaline Foil

Nominal Voltage 1,5 Volt

Electrolyte Potassium Hydroxide

Average weight 11,2 g

Storage temp. range +10°C ~ + 25°C

Operating temp. range -20°C ~ + 45°C

Average Impedance +/- 135 m-Ohm @ 1kHz fresh

Heavy metals No added mercury (Hg), Cadmium (Cd) or Lead (Pb)

Compliant to

IEC 60086

non dangerous goods regulation

Nordic ecolabeling (white Swan)

EU directive 2006/66/EC

Recommended cut o voltage 0,8V per cell

LR03

(+)

(_)

Pro Power

For more information:

Typical discharge values

expressed or implied regarding the accuracy or the results to be obtained from the use of such information. Test results are strictly according to IEC conditions. Capacities of batteries

are depending on drain, temperature and cut-o voltage. Data are subject to change. 07/2010.

Promoter: Panasonic Energy Europe N.V., P. Celis, Brusselsesteenweg 502, 1731 Zellik, Belgium

For more information: www.panasonic-batteries.com
