Sida 1/2
IEC Dimensions
(mm)
Dimension Maximum Minimum
A 50,5
B 49,2
C 7,0
E 0,5
F 5,5
G 1,0
Ø 14,5 13,5
Specications
Name LR6 / M / AA / AM3 / MIGNON / MN1500 / 15A / 15AC
Made in Belgium
Type Alkaline Foil
Nominal Voltage 1,5 Volt
Electrolyte Potassium Hydroxide
Average weight 23,3 g
Storage temperature range +10°C ~ + 25°C
Operating temperature range -20°C ~ + 45°C
Average Impedance +/- 105 m-Ohm @ 1kHz fresh
Heavy metals No added mercury (Hg), Cadmium (Cd) or Lead (Pb)
Compliant to
IEC 60086
non dangerous goods regulation
Nordic ecolabeling (white Swan)
EU directive 2006/66/EC
Recommended cut o voltage 0,8V per cell
LR6
Technical specications
Alkaline
Panasonic Typical Dimensions
C
F
G
E
Ø
F
A
B
(+)
(_)
Pro Power
For more information:
www.panasonic-batteries.com
Typical discharge values
Copyright© Panasonic Energy Europe N.V. (“PECE“) 2010 - All rights reserved. The information contained herein is believed to be correct. However no warranty is made, either
expressed or implied regarding the accuracy or the results to be obtained from the use of such information. Test results are strictly according to IEC conditions. Capacities of batteries
are depending on drain, temperature and cut-o voltage. Data are subject to change. 01/2010.
Promoter: Panasonic Energy Europe N.V., P. Celis, Brusselsesteenweg 502, 1731 Zellik, Belgium
For more information: www.panasonic-batteries.com
VCD/MD: 1h/d 250 mA end 0,9 V
Remote Control: 15s/m 8h/d 24 ohm end 1,0 V
0
0,9
1
1,1
1,2
1,3
1,4
1,5
1,6
2 4 6 8 hrs
0
V
1,1
1,2
1,3
1,4
1,5
1,6
10 20 30 40 50 hrs
1
Radio: 4h/d 43 ohm end 0,9 V
0
0,9
1
1,1
1,2
1,3
1,4
1,5
1,6
20 40 60 80 100 hrs
V
Recorder: 1h/d 10 ohm end 0,9 V
0
0,9
1
1,1
1,2
1,3
1,4
1,5
1,6
4 8 12 16 20 24 hrs
V
Motor: 1h/d 3,9 ohm end 0,8 V
V
0
0,8
0,9
1
1,1
1,2
1,3
1,4
1,5
1,6
21 3 4 5 7 86 hrs
Photoflash: 10s/m1h/d 1000 mA end 0,9 V
0
0,9
1
1,1
1,2
1,3
1,4
1,5
1,6
50 100 150 200 250 300 350 400 450 500 pulses
V
0
1,05
1,15
1,25
1,35
1,45
1,55
25 50 75 100 120 pulses
V
DSC: 10x(2s 1,5W/28s 0,65W)
5min on/55min off, 24h/d end 1,05V
LR6
550 10
