M-500 BTW

Wireless portable bluetooth speaker

USER MANUAL

Please read the instruction carefully

before operating the unit.

English GB - 1

CONTROLS IDENTIFACATION

GB - 2 GB - 3

1. Indicator light

2. [ Volume -] Previous / volume down button

3. [ POWER] On/off and play/pause button

4. [ Volume +] Next / volume up button

5. Speakers

6. RESET hole

POWER YOUR SYSTME

Batteries

Operated by built-in Lithium battery or DC power.

Charging the speaker

Use the provide USB cable. Connect one end to the speaker and the

other end to a computer or use an adaptor(sold separately) and connect

it to a wall socket. The “ POWER light” should be on.

● During charging the red LED will be lit. When charging is complete it

will turn off.

● Please not that the USB cable can only be used for charging and not for

data transfer. USB cable can be used during playback.

OPERATION

NOTE: If you have connected any Bluetooth devices before, press the POWER button (3) for 5

seconds to turn on the speaker. The speaker will reconnect with that device automatically and the

indicator will ash blue quickly, then it becomes steadily lit.

Raising and lowering the volume.

● Press and hold in the volume buttons(2&4) to lower or raise the volume.

● An audible signal is emitted once either the highest or lowest volume level is reached.

● Sometimes volume adjustments made on your device will also affect volume output from the speaker.

Changing tracks/songs

To skip to the previous/next songs, press the [ Volume -] or [ Volume +] button to change.

Incoming calls

When you receive an incoming mobile phone, music audio will automatically mute. Once the call has

ended, it depends entirely on you mobile phone whether the current track will return to playback or

not.

Cable connection

To listen to the music using a wired connection, Connect your music device to the audio port using

the included audio cable.

CARE AND MAINTENANCE

Clean the product by wiping it with a soft dry cloth.

Never use solvent or abrasive cleaning agents.

TROUBLE SHOOTING GUIDE

Turning the speaker on/off

1. Turn ON: Press and hold in POWER button(3) until the indicator begin ashing blue.

2. Turn OFF: Press and hold in POWER button(3) until the indicator turns red.

Establishing a wireless connection

In order to listen to audio from your mobile phone or other bluetooth device, you must rst pair the

devices with each other.

1. Turn off any other devices that are paired with your device.

2. Start the bluetooth function on the device before pairing.

3. If it is the first time you use the speaker system, press and hold the Power button to turn the

system on. After 5s, the status indicator ashes blue with the frequency of 1s. Do not stop pressing

and holding it, one second later, the status indicator will ash blue with frequency of 80 ms.

4. Place the device into bluetooth search mode. The device will begin searching for the speaker.

5. Select M-500BT from the list.

6. Select OK or yes to pair the devices.

7. If needed, use 0000 as the password.

8. The display will remain lit if the pairing is successful.

Problem Solution

The speaker turns

off automatically

Recharge the battery

No connection ● Make sure the speaker is charged and that audio source is not out

of range of the speaker.

● Make sure that your bluetooth devices are properly paired.

Not functioning

correctly

If the speaker is not functioning correctly, you can push the reset

button by inserting a narrow object into the hole on the back of the

speaker. The speaker will be turned off and you can then restart it.

Safety

- Never expose the product to re as this could result in personal injury.

- Do not store the product in extremely cold or warm environments.

- Never dismantle the product.

- Never let children play with the product.

- Do not expose the product to dampness or moisture.

SPECIFICATIONS

Dimensions:

Weight:

Battery type:

Bluetooth version

Operating time

Charging time

Max output

Charging voltage

Working distance:

Standard:

80 x 80 x76 mm

Approx 150g

850 mAh lithium battery

V2.1+EDR

Up to 5 hors at 60% volume

Approx 2-3 hours

2x1.5 W

Up to 10 meters measured in open s pac e. (Wall and

structures may affect range of device)

USB cable&line-in cable(included)

● The socket is only meant for connecting an audio source and not for use as a headphone outlet.

When the cable is successfully connected, the display will be blue.

● The functions(2&3&4) on the speaker will not work with the cable connected. You must control the

functions using the audio source device.

● The speaker volume(2&4) can not be adjusted in this mode.

NEW ONE S.A.S

10, Rue de la Mission, 25480 Ecole Valentin, France

SP-3155 IB MUSE 002 REV1- GB.in1 1 2013-11-13 11:40:54
