Sida 1/4
MAS-TV2
Masera AV Input
NTV-KIT412
BHM
11/03/13
NTV-DOC110
3950 NW 120th Ave, Coral Springs, FL 33065 TEL 561- -9770 FAX 561- -955 955 9760
BHM
11/03/13
NTV-DOC110
Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV- Corp. would not be held liable for : TV
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
2 | P a g e
Overview
The Mas-TV2 adds audio and video input t the factory media screen on select Masera o
vehicles. This kit is not intended for a backup camera soluon, it only emulates the factory TV
Tuner.
Kit Contents
MAS-TV2 Module Pin Out
NAV-TV RG
Pin #
Descripon
Color
2
Constant 12v (+)
Red
6
Ground (-)
Black
7
CAN LO
Yellow
8
CAN HI
Yellow/White
MAS-TV2 Module
NTV-ASY107
CAN/Power Harness
NTV-HAR 090
AV Input Harness
NTV-CAB073
USB Cable (updates)
NTV-CAB009
NAV-TV RGB
NTV-INT005
Video IN 1
Video IN 2
Power
RGB OUT
Sync Over Green switch
RGB Power Harness
NTV-CAB034
Addional
wires are
not used.
BHM
11/03/13
NTV-DOC110
Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV- Corp. would not be held liable for : TV
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
3 | P a g e
Installaon
1. Remove the cup holder insert and remove (1x) Phillips screw. Pull up the shier trim
panel and unplug connectors to lights under trim panel.
2. Using a plasc trim tool remove the AC vent and clock trim panel above radio and
unplug the clock.
3. Remove (4x) Phillips screws from around radio and climate control panel. Two above
and two below the panel.
4. Pull out the radio climate control panel to gain access to
back of radio.
5. Disconnect the 44-pin main power plug from the
factory radio.
6. Connect the black plug from the provided
CAN/Power harness to the port on the main power
plug it is keyed to t (see diagram at right).
7. From the provided , connect the CAN/Power Harness
black wire to ground (-).
8. From the provided , connect the CAN/Power Harness
red wire to Constant 12v (+).
9. Connect the white, 8-pin Molex connector to the MAS-TV2 CAN module.
10. Place the interface module in the dash behind the radio.
11. Connect the red, 18-pin cam-lock style provided AV
Input Harness plug to the back of the radio where it
is keyed to t. Connect your AUX AV source signals
to the red/black RCA’s aached to this plug for
audio input.
12. Connect the other end of the provided AV Input
Harness -TV RGB to the provided NAV at the port
labeled ‘RGB OUT’.
13. Connect your AUX Video source to the port on the
provided RGB labeled . ‘Video 1’
14. From the provided , connect the black RGB Power Harness
wire to Ground (-). Connect the red wire to a 12v (+)
accessory source. Connect the free end of this plug to the
power port on the provided NAV-TV RGB.
15. Reassemble dash in reverse order.
