Sida 1/5
PRINTED IN CHINA 71909A
NINTENDO OF AMERICA INC.
P.O. BOX 957, REDMOND, WA
98073-0957 U.S.A.
NEED HELP WITH INSTALLATION,
MAINTENANCE OR SERVICE?
Nintendo Customer Service
SUPPORT.NINTENDO.COM
or call 1-800-255-3700
BESOIN D’AIDE POUR L’INSTALLATION,
L’ENTRETIEN OU LA RÉPARATION?
Service à la clientèle de Nintendo
SUPPORT.NINTENDO.COM
ou composez le
1 800 255-3700
¿
NECESITAS AYUDA DE INSTALACI N,Ó
MANTENIMIENTO O SERVICIO?
Servicio al cliente de Nintendo
SUPPORT.NINTENDO.COM
o llama al 1-800-255-3700
The official seal is your assurance that this
product is licensed or manufactured by
Nintendo. Always look for this seal when
buying video game systems, accessories, games
and related products.
Ce sceau officiel est votre garantie que le
présent produit est agréé ou manufacturé par
Nintendo. Recherchez-le toujours quand vous achetez des appareils
de jeu vidéo, des accessoires, des jeux et d'autres produits apparentés.
El sello oficial es tu ratificación de que este producto está autorizado
o p1-ha sido fabricado por Nintendo. Busca siempre este sello al comprar
sistemas de videojuegos, accesorios, juegos y otros productos
relacionados.
Wii RemoteTM Plus Controller
Operations Manual
Mode d’emploi – page 7
Manual de operaciones – página 13
MAA-RVL-A-WR-USZ-C0
Product recycling information:
visit recycle.nintendo.com
Information sur le recyclage des produits :
Visitez : recycle.nintendo.com
Información sobre reciclaje de productos:
Visita recycle.nintendo.com
1 2
Wii MotionPlus
technology built into
the Wii Remote Plus
Original Wii Remote
controller
Wii Remote Plus
controller
PLEASE CAREFULLY READ THE Wii™ OPERATIONS MANUAL COMPLETELY BEFORE
USING THIS ACCESSORY. THIS MANUAL CONTAINS IMPORTANT HEALTH AND SAFETY
INFORMATION.
THE Wii REMOTE™ PLUS CONTROLLER MUST BE SYNCHRONIZED WITH YOUR Wii
CONSOLE BEFORE USE. SEE THE Wii OPERATIONS MANUAL FOR COMPLETE INSTRUCTIONS.
WARNING – Radio Frequency Interference
The Wii console and Wii Remote Plus can emit radio waves that can affect the operation of nearby electronics, including
cardiac pacemakers.
• Do not operate the Wii console or remote within 9 inches of a pacemaker.
• If you have a pacemaker or other implanted medical device, do not use the Wii console or remote without first consulting
your doctor or the manufacturer of your medical device.
WARNING – Battery Leakage
Leakage of battery fluid can cause personal injury as well as damage to your remote. If battery leakage occurs, thoroughly wash
the affected skin and clothes. Keep battery fluid away from your eyes and mouth. Leaking batteries may make popping sounds.
To avoid battery leakage:
• Do not mix used and new batteries (replace all batteries at the same time).
• Do not mix different brands of batteries.
• Nintendo recommends alkaline batteries. Do not use Lithium ion, nickel cadmium (nicad), or carbon zinc batteries.
• Do not leave batteries in the Wii Remote Plus for long periods of non-use.
• Do not recharge alkaline or non-rechargeable batteries.
• Do not put the batteries in backwards. Make sure that the positive (+) and negative (-) ends are facing in the correct
directions. Insert the negative end first. When removing batteries, remove the positive end first.
• Do not use damaged, deformed or leaking batteries.
• Do not dispose of batteries in a fire.
IMPORTANT SAFETY INFORMATION WHEN USING THE Wii SYSTEM
Before setup and use of the Wii system, please review this safety information to insure an enjoyable and safe play experience.
1. WEAR THE WRIST STRAP WHEN USING THE Wii REMOTE PLUS CONTROLLER.
• Make sure all players use the wrist strap and that the strap lock is correctly tightened.
• When sharing Wii Remote accessories between multiple players, make sure each person uses the wrist strap properly.
• Wearing the wrist strap will prevent you from accidentally dropping or throwing the remote during game play, which could
damage the remote or surrounding objects, or cause injury to other people.
2. DO NOT LET GO OF THE REMOTE DURING GAME PLAY.
• Read the Instruction booklet for the game you are playing and follow all game control instructions for correct use of the Wii
Remote Plus or accessory controllers.
• Hold the remote securely and avoid excessive motion, as it may cause you to let go of the remote and may break the wrist
strap.
• If your hands become moist, stop and dry your hands.
3. ALLOW ADEQUATE ROOM AROUND YOU DURING GAME PLAY.
• Stay at least three (3) feet away from the television.
• As you may move around during game play, make sure objects and other people are out of your range of movement or arm
motion to prevent damage or injury.
4. USE THE Wii REMOTE JACKET.
The Wii Remote Plus controller incorporates the technology of the Wii MotionPlus™ accessory, allowing
more precise and detailed control of gameplay. The Wii Remote Plus is compatible with both standard
Wii games and all Wii MotionPlus games, without having to attach the Wii MotionPlus accessory.
• Some software may require additional accessories.
NOTE: The Wii MotionPlus accessory can be attached to the Wii Remote Plus without damaging it or
effecting its operation, however this is unnecessary and will not provide any additional
features or benefit when using the Wii Remote Plus.
• If the cursor on the TV screen moves even if the Wii Remote Plus is not
being moved, or moves differently than when the Wii Remote Plus is
moved, the remote may need to be recalibrated due to the following:
1. Changing batteries in the Wii Remote Plus during gameplay.
2. Moving the Wii Remote Plus from a cold environment into a
warm environment.
To recalibrate the Wii Remote Plus, place it on a flat horizontal surface with the
buttons facing down. It should be 20” or more from your television and Wii
console for correct calibration. Wait for a few seconds and check the operation.
Also, review the instruction manual for the game you are playing for more information.
NOTE: This procedure must be done during gameplay.
TM, ® and the Wii logo are trademarks of Nintendo. © 2010 Nintendo.
Wii Remote Plus Features
Unlicensed Accessories
Do not attach unlicensed accessories to the Wii Remote Plus, as the use of unlicensed accessories may lead to injury
to yourself or others and may cause performance issues and/or damage to the system. Use of any such unlicensed
accessories will invalidate your Nintendo product warranty.
NOTE: This product does not contain latex.
This product complies with applicable laws barring the use of toxic materials such as lead, mercury, cadmium,
hexavalent chromium, PBB or PBDE in consumer products.
3 4
Wii Remote
Jacket
1. Press the Power button on the Wii console to turn it on.
2. Remove the battery cover on the back of the remote. Press and release the SYNC. button inside
the cover. The Player LEDs will blink.
3. Open the SD Card Slot cover on the front of the Wii console. Press and release the SYNC. button
on the inside of the compartment.
4. When the Player LED blinking stops, connection is complete. The LED that is illuminated
indicates the player number.
5. Close the SD Card Slot cover on the front of the Wii console and replace the battery cover on the
Wii Remote Plus.
Synchronizing your Wii Remote Plus with the Wii console
5. If you remove the jacket from the remote,
replace it by inserting the top of the remote
into the large hole on the front of the jacket.
Be sure to push it all the way into the inside of
the jacket.
Thread the wrist strap through hole in the
bottom of the jacket, as shown in step 4, above.
6. Insert the connector cover into the
External Extension Connector on the bottom
of the remote.
Installing Batteries (continued)
This procedure must be followed for each additional Wii Remote Plus added to your system.
The Wii Remote Plus uses AA batteries. Nintendo recommends high quality alkaline batteries for best
performance and longevity of battery life. If you use rechargeable nickel metal hydride (NiMH)
batteries, be sure to follow the manufacturer’s guidelines for safety and proper usage.
1. Pull the Wii Remote Jacket off the base of
the Wii Remote Plus and pull the wrist strap
out of the hole in the bottom of the jacket.
2. Pull the jacket up the remote far enough
to expose the entire battery door and remove
the door.
3. Insert the batteries into the battery
chamber. Be sure to insert the minus (–)
end first when inserting new batteries,
and remove the plus (+) end first when
replacing the batteries.
4. IMPORTANT: If this is the first time
you have installed batteries in the Wii
Remote Plus, you must synchronize the
remote with the Wii console before
using it. See the next page,
Synchronizing your Wii Remote Plus
with the Wii console, for instructions.
Then return to Step 4.
Replace the battery cover, thread the wrist
strap through the hole in the bottom of the
jacket and pull the jacket back over the
bottom of the remote.
The Wii Remote Plus comes with the Wii Remote Jacket
installed.
• Be sure that the Wii Remote Jacket is installed
during gameplay to reduce the risk of harm to the
remote, surrounding objects, or people.
• It may be necessary to remove the Wii Remote
Jacket – for example, to replace the batteries in the
Wii Remote Plus. If you do remove the Wii Remote
Jacket, be sure to replace it before further play.
Installing Batteries
Setup of the Wii Remote Plus
