Sida 1/2
Overview
Roti Pola is a four channel attenuverting CV mixer and offset
with visual feedback in a small package. With nothing patched
to channel 1, a 5v offset is applied to the mix, useful for
controlling other parameters or modifying CV signals.
1
Noise Engineering
Roti Pola
Small attenuverting CV mixer
Type
Attenuverter/Mixer
Size
4HP Eurorack
Depth
.8 Inches
Power
2x5 Eurorack
+12 mA
58
-12 mA
40
Etymology
Roti -- from Latin: “spinny/whirly”
Pola -- from Latin: “tiny”
“Tiny Whirlification”
Roti Pola is rated for voltages between ±10v.
Input & output voltages
Patch Tutorial
Patch an LFO into channel 2. Patch the output to a CV input in your system. Use
channel 2’s attenuverter to modify the signal, and observe the LED feedback given
by channel 2’s indicator and the mix out LED. Next, play with channel 1’s
attenuator to add an offset and see how your LFO signal is modified. Patch more
CV sources into channels 3 and 4 to create more interesting and chaotic
modulation.
2
Interface
Channel knobs 1-4: Attenuverters; with nothing patched into its input, channel 1
is normaled to a 5v offset. Corresponding channel LEDs show the signal post
attenuversion being sent to the mixer. Green indicates a positive signal, red
indicates a negative signal.
Inputs 1-4: Input your CV here for mixing and attenuverting.
Output: Final mix output. LED shows outgoing CV, with green indicating a
positive signal and red indicating a negative signal.
Special Thanks
Baseck
Design Notes
A while back, our friend Baseck called us up and said, “Guys! You have to come
see this!” He had patched up this incredible bit with the Cursus Iteritas and a load
of other stuff -- and it became clear that we needed, among other things, a CV
mixer. We brainstormed the schematics for things to fit into a setup similar to
what he was doing, but with our own character. The first version of RP one was
workable but once we had it in hand, we realized adding the 5V supply to channel
1 would make it so much more useful. The desire for that add-on led us to a
revision that allowed us to fix a few wacky layout issues on the first one and we
had a product.
