INSTALLATION INSTRUCTIONS
59-2781-0 1908-05
EN
QX Infinity series
Wide Angle Outdoor Detector
Wide Angle Outdoor Detector
QX Infinity series
QXI-R: Standard Battery Operated Model
QXI-RDT-X5: +Microwave detection (10.525 GHz)
QXI-RDT-X8: +Microwave detection (10.587 GHz)
QXI-RDT-X9: +Microwave detection ( 9.425 GHz)
BATTERY OPERATED MODEL
1Introduction
2Manufacturer s statement
!Warning Prohibited Recommended
< QXI-RDT only >
Multi Level
Pet Alley
!Caution
Mounting height
2.2 m (7 3 ) to 2.7 m (8 11 )
0.8 m (2 7 ) to 1.2 m (4 )
Tilt
PDF download
and
additional
information
with
m ti nguageul la
,
avai e in;labl
http://navi.optex.net/manual/50337
FR
DE
IT
ES
PT
NL
Le téléchargement PDF et des informations supplémentaires multilingues sont disponibles dans l'URL indiquée.
PDF-Download und zusätzliche Informationen in mehreren Sprachen finden Sie unter der angezeigten URL.
Download PDF e ulteriori informazioni con multilingua sono disponibili nell'URL mostrato.
La descarga de PDF y la información adicional en varios idiomas están disponibles en la URL que se muestra.
PDF download e informações adicionais com multilanguage estão disponíveis no URL mostrado.
PDF-downloads en aanvullende informatie met meertalige zijn beschikbaar in de getoonde URL.
Replace the transmitter battery with the dummy
battery (included) for battery sharing.
- 1 -
3Installation
<Accessories>
30
50
90
MaximumTransmitter
Size (mm)
Connector for
TROUBLE
Dummy battery
and Connector for
ALARM
Transmitter sideMain unit side
Power
Alarm
Trouble
Red
Black
White
Yellow
Green
Blue
Red
Black
White
Yellow
Green
Blue
Connectors
Battery Life (DIP SW No.5)
Battery saving timer
QXI-R
QXI-RDT
120 5
6 5
4 3
Unit: estimated years
CR123A
(3 V DC, 1,300 mAh)
Wall tamper option
Cover
Lens
DIP switch
Base
Microwave module
(QXI-RDT only)
PIR sensor
Main unit
[1] Warm-up
[2] Alarm
[3] Walk test end
60
2
5
Seconds
LED
MW Sensitivity
Do not touch the
parts with this sign.
!
!
!
Cover lock screw
(optional)
Mirror
Tamper switch
!
How to open the cover
Lock screw
(optional)
* Remove before,
if used.
[1] Unlock the cover using a
screwdriver (-).
[2] Lift the cover up.
Battery sharing
[1] Install dummy battery
in transmitter
[2] CR123A
!Except levers
on side
<Opti s>on
CA-2C(W)
Bracket for ceiling mount
CA-1W(W)
Bracket for wall mount
Mounting screw
(4 × mm) x 320
Area masking strips
Fixing screw
for the Main unit
(3 × mm) x 112
a
b
c
d
e
b
c
d
e
ｆｆ
a
b
c
d
e
ｆ
b
c
d
e
ｆ
L H
default
OPTEX INC./ HQ (U.S.)AMERICAS
www.o examerica.compt
OPTEX (EUROPE) LTD./EMEA HQ (U.K.)
www.optex-eur e.comop
OPTEX TECHNOLO ES B.V. GI
(The Netherl ds)an
www.optex.eu
OPTEX SECURITY SAS (Fr ce)an
www.optex-europe.com/fr
OPTEX SECURITY Sp.z o.o. (Pol d)an
www.o ex.com.plpt
OPTEX PINNACLE INDIA,
PVT., LTD. (I ia)nd
www.optexpinnacle.com
OPTEX K EA CO.,LTD. (Korea)OR
www.o exkorea.compt
OPTEX (DO GUAN) CO.,LTD.NG
SHANGHAI OFFICE (C na)hi
www.o exch a.compt in
OPTEX (T il d) CO., LTD. (T il d)ha an ha an
www.optex.co.th
Copyright (C) 20 OPTEX CO.,LT19 D.
OPTEX ., LTD. ( )CO JAPAN
www.o expt .net
• These units are designed to detect an intruder and activ e an rm control nel.at ala pa
Being only a rt of a com ete s tem, we cannot accept responsi lity for any damages or pa pl ys bi
ot r consequences res ting from an intrusion.he ul
• Specifications and designs are subject to change without prior notice.
12.0 m (40') 120°wide
Multi level： 40 zones
Pet alley： 18 zones
0.3 to 2.0 m/s (1' to 6'7"/s)
2.0 ( 3.6°F) at 0.6 m/s℃
Remove lower area detection to avoid small animals.
CR123A (3 V DC) *Not included.
9 µA stand-by 16µA stand-by
11 mA max. at 3 V DC 11 mA max. at 3 V DC
2.0 ± 0.5 s
Approx. 60 s (LED blinks)
N.C/N.O. switchable solidstate switch, 3 V DC 0.01 A max.
N.C/N.O. switchable solidstate switch, 3 V DC 0.01 A max.
[1] Warm-up [2] Alarm [3] Walk test end
-40 to +60 (-40°F to +140°F) -40 to +45 (-40°F to +113°F)℃ ℃ ℃ ℃
95% max.
IP 54
Wall (Outdoor, Indoor)
Multi level： 2.2 to 2.7 m (7' 3" to 8'11")
Pet alley：0.8 to 1.2 m (2' 7" to 4' )
215 g (7.58 oz) 230 g (8.11 oz)
[1] Dummy battery and connector for ALARM
[2] Connector for TROUBLE [3] Mounting screw (4 x 12 mm) x 3
[4] Lock screw (3 x 12 mm) x 1 [5] Area masking strips
Model
Detection method
PIR coverage
PIR zones
Detectable speed
Sensitivity
Pet alley
Power source
Current draw
Alarm period
Warm-up period
Alarm output
Trouble output
(with tamper)
LED indicator
Operation temperature
Environment humidity
Internation protection
Mounting
Mounting height
Weight
Accessories
QXI-R
Passive infrared
QXI-RDT
Passive infrared & Microwave
EU contact for t nin ma io
Manufacturer:
OPTEX CO., LTD.
5-8-12 Ogoto, Otsu, Shiga, 520-0101 JAPAN
Authori d re esentative in Europe:ze pr
OPTEX (EUROPE) LTD./EMEA HEADQUART SER
Unit 13, Cordwallis Park, Clive nt Road, mo
Maiden ad, Berkshire, SL6 7BU U.K.he
■OPTEX declares that QXI-RDT-X5, QXI-RDT-X8 and QXI-RDT-X9 comply with RE Directive
2014/53/EU. Doc documents can be found on our website; www.optex.net
■
Microwave emission Frequency and Power
QXI-RDT-X5: 10.525 GHz 15.78 mW e.i.r.p
QXI-RDT-X8: 10.587 GHz 8.93 mW e.i.r.p
QXI-RDT-X9: 9.425 GHz mW e.i.r.px.xx
■
The following list indicates the areas of intended use of the equipment and any known
restrictions. For countries not included in this list, please consult the responsible
Spectrum Management Agency.
10.525 GHz: Belgium, Denmark, F nd, Germany, Greece, Italy, Luxembourg, inla
IThe Nether , S n, Sw n,lands pai ede c d, Norway, Switzer delan lan
10.587 GHz: Be , Fr ce, Germany, d, Luxembourg, The Nether ,lgium an Irelan lands
United Kingdom
9.425 GHz: Austria, Czechia, Esthonia, Germany, Slovakia, Turkey, Russia
■QXI-RDT-X5, QXI-RDT-X8 and QXI-RDT-X9 also comply with EU radiation exposure limits
set forth for an uncontrolled
environment. This equipment should be installed and
operated with minimum distance
20 cm between the radiator & your body.
- 2 -
5Specifications
5-1 5-2. Specifications . Dimensions 78(3.07) 83.5 (3.28)
144.5 (5.69)
Unit: mm (inch)
LED flashes 5 times
33
3
DIP switch ON OFF
Future use
Battery
saving timer 5 s 120 s
See right for the PIR sensitivity
Alarm output N.O. N.C.
LED ON OFF
1
2
3
4 5 6 7 8
[8]
[7]
[6]
[5]
[4]
[3]
[2]
[1]
Default settings
[2]
4Settings
4-3. Walk test
[1] Close cover [2] Walk test (3 minutes) [3] Walk test ends
With the cover open, the tamper activates.
This enables the LED function, regardless of DIP switch [1] setting.
When the cover is closed, the Walk test timer starts and automatically returns
to the normal mode after 3 minutes.
If the unit is powered up with the cover closed, it will not enter walk test mode.
Open and close the cover once to activate the walk test timer.
NOTE
4-2. DIP switch settings
3 4 3 4 3 4 3 4
L
M
PIR sensitivity
H
SH
Default
[1] Loosen the lock screw.
[2] Slide the Main unit down.
[3] Rise the mirror up to the fixing position.
[4] Tighten the lock screw as before.
[1], [4] [3]
4-1. Detection area
Top view
Side view
Side view
30 3525
0
10
9 12 m
4
7.5 m
2
0
2
5 10 2015
3
4
6
40 ft.
5
15
25 ft.
7.5 m
5
10
15
25 ft.
0
0
206
6 20
353025
9
20
6
2.2 m
0
15105
0
3 12 m
40 ft
2.7 m
353025
9
20
6
0.8 m
0
15105
0
3 12 m
40 ft
1.2 m
Multi Level
Pet Alley PIR
MW
PIR
MW
PIR
MW
