Sida 1/5
http://www.orion.ua
I
IN
NS
ST
TR
RU
UC
CT
TI
IO
ON
N
M
MA
AN
NU
UA
AL
L
ELECTRIC FAN
Model: OF16HS
ENGLISH GB
AC220V~50Hz, 120W
RoHS
http://www.orion.ua
2
DEAR CUSTOMERS!
MANY THANKS FOR BUYING ORION ELECTRIC FAN!
We really believe you will get the greatest pleasure from using this device for the years!
Please, read the user’s guide in detail before first using of this fan.
Introduction
This product has both fan and humidifier functions, which can be used together or separately.
The humidifier is especially useful on very hot days, when the extra mist in the air helps not only
to cool you down, but also to increase the humidity in the dry heat.
How does it work?
This Mist Fan uses ultrasonic vibration to atomise water into 1-5 micron particles, which can
then be blown through the room with the fan.
Why is it useful?
Not only does this fan help to cool you down with air containing micro water droplets, it also
helps to avoid dry skin and eyes which are common in dry heat. A relative humidity of 45% -
65% is recommended for comfortable living, and this fan can help maintain that balance in the
hot summer months.
Parts
1. Front mist plate
2. Front Guard
3. Blade cap
4. Blade
5. Guard Mounting Nut
6. Rear Guard
7. Motor
8. Fan Body
9. Base
10. Castor wheels
11. Base Nut
12. Fixer
13. Plastic Tube
14. Tube Button
Rated Voltage: 220-240V~
Rated Frequency: 50Hz
Fan Power: 80W
Humidity Power: 40W
General Power: 120W
Max Mist Capacity: 200ml/h
Fan Head Size: 400mm
Water Tank Capacity: 1500ml
http://www.orion.ua
3
Installation
1: First base is installed in place of the main stable
2: The head fixed in the main part of the bearing hole
3: Installed guard and blade, and net fixed firmly lock the lookout Network
Filling the water tank
Place the fan on a flat, stable floor, then add water for the humidifying function as follows:
1. Open the water tank 2. Lift out the water tank 3. Take out the water tank.
cover.
4. Over a sink, turn the water 5. Screw off the tank cap, and 6. Screw tank cover tightly, and
tank so the outlet cap is add water. put it into the fan, then close
facing upwards. panel.
Operation
*Insert plug to the electrical outlet, and the indicator light turns on.
*Press “ON/SPEED” button to choose the wind for low, Med, High speed that matches the light
on the control panel.
*Press “MODE” to choose the wind type from one of the following:
“Normal”: Wind flow based on Low/Med/High speed.
“Breeze”: Imitates the flow of natural wind based on strong and soft wind.
“Sleep”: The fan runs for half an hour on strong then soft natural wind mode, then changes to
soft natural wind for the next half hour, and then the fan turns off automatically.
(1).Setting H:
Operation pattern: H→Stop→H→Stop→H
(2).Setting M:
Operation pattern: M→stop →M→Stop→M
