Sida 1/2

size 445 x 210 mm

Danger! - Read the operating instructions to re-

duce the risk of inquiry

Caution! Wear ear-mus. The impact of noise

can cause damage to hearing.

Caution! Wear a breathing mask. Dust which

is injurious to health can be generated when

working on wood and other materials. Never use

the device to work on any materials containing

asbestos!

Caution! Wear safety goggles. Sparks gene-

rated during working or splinters, chips and dust

emitted by the device can cause loss of sight.

Store the battery only in dry rooms with an am-

bient temperature of +10°C to +40°C. Place only

charged batteries in storage (charged at least

40%). (not included in delivery)

The reprinting or reproduction by any other me-

ans, in whole or in part, of documentation and

papers accompanying products is permitted only

with the express consent of the iSC GmbH.

Subject to technical changes

PXMSS-700U

GB Additonal operating & safety instructions Cordless Detail Sander

Service information

We have competent service partners in all countries named on the guarantee certicate whose contact

details can also be found on the guarantee certicate. These partners will help you with all service re-

quests such as repairs, spare and wearing part orders or the purchase of consumables.

Please note that the following parts of this product are subject to normal or natural wear and that the

following parts are therefore also required for use as consumables.

Category Example

Wear parts* Grinding/sanding plate, Battery

Consumables* Grinding/sanding paper

Missing parts

* Not necessarily included in the scope of delivery!

In the eect of defects or faults, please register the problem on the internet at www.isc-gmbh.info. Plea-

se ensure that you provide a precise description of the problem and answer the following questions in all

cases:

• Did the equipment work at all or was it defective from the beginning?

• Did you notice anything (symptom or defect) prior to the failure?

• What malfunction does the equipment have in your opinion (main symptom)?

Describe this malfunction.

Yang/Product-ManagementWeichselgartner/General-Manager

explains the following conformity according to EU directives and norms for

the following product

Cordless Detail Sander PXMSS-700U / Fast Charger PXCG-030U (Ozito)

2014/29/EU

2005/32/EC_2009/125/EC

2014/35/EU

2006/28/EC

X 2014/30/EU

2014/32/EU

2014/53/EC

2014/68/EU

90/396/EC_2009/142/EC

89/686/EC_96/58/EC

X 2011/65/EU

X 2006/42/EC

Annex IV

Noti ed Body:

Noti ed Body No.:

Reg. No.:

2000/14/EC_2005/88/EC

Annex V

Annex VI

Noise: measured LWA = dB (A); guaranteed LWA = dB (A)

P = KW; L/Ø = cm

Noti ed Body:

2004/26/EC

Emission No.:

Standard references: EN 60745-1; EN 60745-2-4; EN 60335-1;

EN 60335-2-29; EN 62233; EN 55014-1; EN 55014-2; EN 61000-3-2; EN 61000-3-3

Landau/Isar, den 21.03.2016

First CE: 16 Archive-File/Record: NAPR014207

Art.-No.: 45.607.12 I.-No.: 11016 Robert GerhardDocuments registrar:

Subject to change without notice Wiesenweg 22, D-94405 Landau/Isar

ISC GmbH · Eschenstraße 6 · D-94405 Landau/Isar

Declaration of conrmity

size 445 x 210 mm

Charger indicator / Fast Charger

Indicator status Explanations and actions

Red LED Green LED

O Flashing Ready for use

The charger is connected to the mains and is ready for use; there is no

battery pack in the charger

On O Charging

The charger is charging the battery pack in quick charge mode.

O On The battery is 85% -100% charged and ready for use.

(Charging time for 1.5 Ah battery: 30 min)

(Charging time for 2.0 Ah battery: 40 min)

(Charging time for 3.0 Ah battery: 60 min)

(Charging time for 4.0 Ah battery: 80 min)

(Charging time for 5.2 Ah battery: 105 min)

Action:

Take the battery pack out of the charger. Disconnect the charger from

the mains supply.

Flashing O Adapted charging

The charger is in gentle charging mode.

For safety reasons the charging is performed less quickly and takes

more than 1 hour. The reasons can be:

- The battery pack has not been used for a very long time or an already

at battery was further discharged (exhaustive discharge).

- The battery pack temperature is outside the ideal range (between 25°

C and 45° C).

Action:

Wait for the charging to be completed; you can still continue to charge

the battery pack.

Flashing Flashing Fault

Charging is no longer possible. The battery pack is defective.

Action:

Never charge a defective battery pack.

Take the battery pack out of the charger.

On On Temperature fault

The battery pack is too hot (e.g. due to direct sunshine) or too cold

(below 0° C).

Action:

Remove the battery pack and keep it at room temperature (approx. 20°

C) for one day .

Items supplied

Please check that the article is complete as

specied in the scope of delivery. If parts are

missing, please contact our service center or the

sales outlet where you made your purchase at

the latest within 5 working days after purchasing

the product and upon presentation of a valid bill

of purchase. Also, refer to the warranty table in

the service information at the end of the operating

instructions.

• Open the packaging and take out the equip-

ment with care.

• Remove the packaging material and any

packaging and/or transportation braces (if

available).

• Check to see if all items are supplied.

• Inspect the equipment and accessories for

transport damage.

• If possible, please keep the packaging until

the end of the guarantee period.

Battery and charger sold separately. This tool is

compatible with all 18V battery and chargers from

the Power X Change range.

Danger!

The equipment and packaging material are

not toys. Do not let children play with plastic

bags, foils or small parts. There is a danger of

swallowing or suocating!

Proper use

The equipment is designed for the sanding of

wood, iron, plastic and similar materials using the

appropriate sanding paper. The equipment is not

suitable for wet sanding.

The equipment is to be used only for its prescri-

bed purpose. Any other use is deemed to be a

case of misuse. The user / operator and not the

manufacturer will be liable for any damage or inju-

ries of any kind caused as a result of this.

Please note that our equipment has not been de-

signed for use in commercial, trade or industrial

applications. Our warranty will be voided if the

machine is used in commercial, trade or industrial

businesses or for equivalent purposes.

Technical data

Motor power supply: ............................... 18 V DC

Idling speed 12000/min .........................................

Sanding area: 102 x 62 x 93 mm .........................

Oscillatory circuit Ø: 1.6 mm ................................

Weight: 0.75 kg .....................................................

Danger!

Sound and vibration

Sound and vibration values were measured in

accordance with EN 60745.

LpA sound pressure level 77.2 dB(A) .....................

KpA uncertainty 3 dB .............................................

LWA

sound power level 88.2 dB(A) .......................

KWA uncertainty .............................................3 dB

Wear ear-mus.

The impact of noise can cause damage to hea-

ring.

Total vibration values (vector sum of three direc-

tions) determined in accordance with EN 60745.

Vibration emission value ah = 6.585 m/s2

K uncertainty = 1.5 m/s2

The specied vibration value was established in

accordance with a standardized testing method. It

may change according to how the electric equip-

ment is used and may exceed the specied value

in exceptional circumstances.

The specied vibration value can be used to

compare the equipment with other electric power

tools.

The specied vibration value can be used for initi-

al assessment of a harmful eect.

Keep the noise emissions and vibrations to a

minimum.

• Only use appliances which are in perfect wor-

king order.

• Service and clean the appliance regularly.

• Adapt your working style to suit the appliance.

• Do not overload the appliance.

• Have the appliance serviced whenever

necessary.

• Switch the appliance off when it is not in use.

• Wear protective gloves.

Caution!

Residual risks

Even if you use this electric power tool in ac-

cordance with instructions, certain residual

risks cannot be rules out. The following ha-

zards may arise in connection with the equip-

ment’s construction and layout:

1. Lung damage if no suitable protective dust

mask is used.

2. Damage to hearing if no suitable ear protecti-

on is used.

3. Health damage caused by hand-arm vibra-

tions if the equipment is used over a pro-

longed period or is not properly guided and

maintained.

For EU countries only

Never place any electric power tools in your

household refuse.

To comply with European Directive 2012/19/EC

concerning old electric and electronic equipment

and its implementation in national laws, old elec-

tric power tools have to be separated from other

waste and disposed of in an environment-friendly

fashion, e.g. by taking to a recycling depot.

Recycling alternative to the return request:

As an alternative to returning the equipment to

the manufacturer, the owner of the electrical

equipment must make sure that the equipment

is properly disposed of if he no longer wants to

keep the equipment. The old equipment can be

returned to a suitable collection point that will

dispose of the equipment in accordance with the

national recycling and waste disposal regulations.

This does not apply to any accessories or aids

without electrical components supplied with the

old equipment.

This consignment contains lithium-ion batteries.

In accordance with special provision 188 this

consignment is not subject to the ADR regula-

tions. Handle with care. Danger of ignition in case

of damage to the consignment package. If the

consignment package is damaged: Check and

if necessary repackage. For further information

contact: 0049 1807 10 20 20 66 (xed network

14 ct/min, mobile phone max. 42 ct/min) Outside

Germany charges will apply instead for a regular

call to a landline number in Germany.
