Sida 1/26
Paradigm Electronics Inc.: 205 Annagem Blvd., Mississauga, ON L5T 2V1 www.paradigm.com
THE ULTIMATE IN HIGH-END SOUND FOR MUSIC AND HOME THEATER™
OWNERS MANUAL
MILLENIA™ LP SPEAKER SYSTEM
TABLE OF CONTENTS
Introduction . . . . . . . . . . . . . . . . . . . 1
The Technology
Behind Your New Speakers. . . . . . . . 2
Your New Speakers . . . . . . . . . . . . . 3
How To Avoid Speaker Damage . . . . 3
Your Listening Room . . . . . . . . . . . . . 4
Placement Guidelines . . . . . . . . . . . . 5
Installation . . . . . . . . . . . . . . . . . . . . . 7
Connection . . . . . . . . . . . . . . . . . . . . . 9
Troubleshooting . . . . . . . . . . . . . . . . . 9
Technical Specifications . . . . . . . . . 10
Limited Warranty . . . . . . . . . . . . . . . 11
Paradigm DOES NOT supply hardware for mounting speakers to the wall.
Hardware shown in this manual is for example only and will vary depending
on the wall type. Always use screws appropriate for wall type and weight
of speakers.
If installing into drywall, install into 1/2˝ (13 mm) or 5/8˝ (16 mm) drywall only.
Screws must be long enough to go through anchor bolts (not supplied) and
firmly into drywall (see inset circle, page 8).
IMPORTANT: Read before mounting Millenia™LP speakers
Wall mount speakers securely enough that they cannot fall and cause
personal injury or damage to property. Use safety straps. Detailed information
on attaching the safety straps is included in the section on Installation later
in the manual.
NON LIABILITY: We are aware that the mounting assemblies provided for Millenia™
LP speakers could be used for purposes and in ways other than those for which
they were intended. The manufacturer, distributor, retailer and their respective agents
cannot be held responsible or liable for injuries or property damage—direct, indirect
or consequential—arising from the use of or inability to use these products safely and
properly. Every effort has been made to provide accurate, error-free installation
instructions. Paradigm Electronics Inc. disclaims liability for difficulties that may arise
from the misinterpretation of information contained in these instructions.
RECYCLING AND REUSE GUIDELINES (Europe)
In accordance with the European Union WEEE (Waste Electrical and Electronic Equipment) directive effective August 13, 2005, we would like to notify you that our speakers
may contain regulated materials which, upon disposal, require special reuse and recycling processing. For this reason Paradigm Electronics Inc. (the manufacturer of Paradigm
speakers and Anthem electronics products) has arranged with its distributors in European Union member nations to collect and recycle this product at no cost to you. To
find your local distributor please contact the dealer from whom you purchased this product or go to our website at www.paradigm.com.
Please note that only the product falls under the WEEE directive. When disposing of packaging and other shipping material we encourage you to recycle through the
normal channels.
© PARADIGM ELECTRONICS INC. 072911
1
INTRODUCTION
Thank you for choosing Paradigm®Reference Millenia™LP speakers and congratulations! You are about
to hear the difference these state-of-the-art high-end speakers will make in your music and home
theater system.
Paradigm speakers are internationally recognized for their exceptional sound. In fact, Paradigm is the
only speaker company in the world to be rated #1* year after year. Quite simply, our speakers are the best
sounding speakers in the world. Why?
Extensive listener preference tests conducted by the National Research Council (NRC) give our design
engineers a firm understanding of how we hear speakers and clearly establish which design parameters are
most critical to good sound. Using the NRC findings along with measurement-based analysis done in our
anechoic chamber as well as listening tests carried out in our controlled double-blind listening rooms,
our engineers work to constantly improve Paradigm speakers in three critical areas:
Flat Midrange: Smooth and even with coloration reduced to the lowest level possible.
Smooth Total Energy Response: On and off axis, sound must be fundamentally similar. Dispersion must
be wide and uniform ensuring superior imaging and a wide listening area.
Low Distortion: Lowest levels possible.
In addition, we concentrate on two other significant performance areas:
Better Bass Response: Tight, extended and well defined.
Higher Power Handling: To improve dynamic contrasts and by extension, sonic realism, power
compression must be minimized.
Unyielding attention to these areas results in speakers that are measurably and audibly superior. When
it comes to state-of-the-art sound, Paradigm gets it right. And your Paradigm®Reference Millenia™LP
speakers are a perfect example.
Comprehensive R&D, leading-edge design, use of the finest materials and sophisticated manufacturing
and quality control techniques provide vastly superior performance for each component part at every
stage of design. Your Millenia™LP speakers boast S-PAL™satin-anodized pure-aluminum domes; MLP™
mica-loaded-polymer cones and polypropylene passive radiators; a proprietary HTD™heat transfer and
dissipation system and “reference
”
quality crossover networks with ideal response characteristics.
Millenia™LP speakers will provide you with stunning high-end sound and unparalleled listening pleasure
for many years. In fact, their ultra-thin on-wall profile was designed to complement the thinnest flat-panel
television on the market today as well as the “even thinner
”
panels yet to come. Installation is as easy
as deciding where on the wall you want to mount them. However, to achieve all of the exceptional sound
these speakers are capable of providing requires care in installation and operation. Please take the time
to read this manual and follow all instructions. If you have further questions, contact your Authorized
Paradigm®Reference Dealer or visit the Q&A page in the Tech Support section of our website at
www.paradigm.com.
* Rated #1 Best Price/Value. Inside Track Annual Dealer Survey. An annual independent nationwide survey of consumer electronics specialist retailers and custom installers.
