What’s in the box …
IMPORTANT: System can only be
operated using the Remote Control.
Vertically: Do not operate
subwoofer without stand.
Horizontally: Remove
stand and use bumper pads
(included) on each corner.
Inpu t
SHIFTSERIES™
HIGH-DEFINITION SOUND
™
6’ Power Cable
This end …
to subwoofer
This end …
to wall outlet
1
… to TV for
digital audio
6’ Optical Cable
… to control box
“DIGITAL IN”
2
6’ 3.5-mm Cable
… to control box
“ANALOG IN”
… 3.5-mm to TV
for analog audio
3
R
15’ Speaker Cable
… to subwoofer
… to speaker … to subwoofer
4
15’ Controller Cable
… to control box
“TO SUB”
5
Remote Control
includes CR 2025
3V lithium battery
Set-Up Guide
Paradigm Reference, MilleniaOne CT and associated proprietary and patented designs and technologies are registered
trademarks of Paradigm Electronics Inc. Copyright © Paradigm Electronics Inc. All rights reserved. All other trademarks are
the property of their respective owner(s). Paradigm Electronics reserves the right to change specifications and/or features
without notice as design improvements are incorporated.
Paradigm Electronics Inc.
205 Annagem Blvd., Mississauga, ON Canada L5T 2V1
MAN0077
REV. 072012
Pull o plastic tips
before attaching cables
For more information visit www.paradigm.com
1x1x1x 2x
2x
2x
2x
1x 4x
1x
2x
2x
2x
2x
1x
1x
3 4
1
4
4
4
4
1
5
Connect Subwoofer Connect Control Box
Analog connection to TV
(use for good audio)
2
35
Your subwoofer’s switch is set to 12 o’clock LEVEL
to suit average preferences. If desired, adjust up or
down to match sound level of your speakers.
Digital connection to TV
(use for best audio)
TIP: If after set-up and
“power on” you do not hear
audio, press the “input”
button on the remote.
Connect controller cable to
subwoofer and to control box
(+) to (+),
(–) to (–)
Connect power cable to
subwoofer and to wall outlet
Top View
Side View
BEFORE YOU BEGIN, READ THE SAFETY PRECAUTIONS AND IMPORTANT SAFETY INSTRUCTIONS INCLUDED IN THE OWNERS MANUAL.
OPTIONAL:
Connect digital
output cable
Paradigm DOES NOT supply hardware for
mounting brackets to the wall. Use 2 #8 1-1/2”
wood screws to mount the wall bracket to the wall.
Mount bracket to wood stud or use anchor bolts
rated for 20 lb weight.
On Stands: Adjust
angle of tilt, if desired Wall-Mounting Adjust On-Wall Angle
of Tilt, if desired
To Use Control Box
with Apple TV
For further instructions, refer to your Apple TV
Set-Up Guide.
Adjust Subwoofer Loundness
A DB C
Tighten knob before
sliding into bracket
5
Squeeze here (both
sides) to allow bracket
to slide snugly
Attach Speakers to Stands
1
2
Press down on binding
post to allow wire access.
Left cable to left speaker.
Right cable to right speaker.
DO NOT pinch wires when
attaching speakers to stands
NOTE: Pre-attached wall mounting
brackets must be removed in order
to attach stands
NOTE: Choose analog
OR digital connections
Tighten knob
to secure stand
Wire Speakers
GAIN
+
BASS
–
BASS
4
