Sida 1/6
13
Shown: SE 3, SE Center, SE Sub
Special Edition (SE) Series
“… they don’t just sound like far more expensive products, they also look like ‘em … mastered the frequency
spectrum from top to bottom … belongs on anyone’s short list of affordable yet high-performing speakers.”
– Mark Fleischman, Home Theater
14
www.p a r a d i g m . c o m
Not buying a new home or the car of your dreams right now? Staying home with friends and family—connecting and
being entertained? When it comes to home entertainment, if you’re looking for a well-priced mix of aesthetics and
competitive performance, the Paradigm SE Series is the perfect choice. Designed and engineered to be a complete
music and home theater solution!
STYLE: Soft edges and clean lines! Even the subwoofer has a compact ‘easy-to-live-with’ footprint … our smallest
subwoofer yet!
PERFORMANCE: Combines award-winning technology from our Monitor Series and high-end ‘Reference’ Studio
Series … the best of both with the emphasis on affordability
QUALITY: Real wood veneer cabinets at these prices? Unheard of. But we delivered!
VALUE: Paradigm®is the #1 Brand in affordable high-end performance. And has been for more than 25 years.
Rosenut Black Gloss
Mineral-Filled Co-Polymer Polypropylene Bass Cones with
oversized magnet structures are engineered for very high
power. The high-stiffness design is intrinsically low in distortion,
allowing the bass cone to respond instantly to the starts and
stops of even the leading edge of changing bass notes.
Real Wood Veneer Cabinets! Soft edges and clean lines,
even the sleek design of the soft rubber feets adds a touch
of class and elegance. Grilles attach magnetically.
Advanced S-PAL™ Satin-Anodized Pure-Aluminum
Midrange and Bass/Midrange Cones with advanced
Santoprene®rubber suspensions and powerful ceramic/ferrite
magnets. FEA-optimized, elliptical shaped suspensions allow
for inaudible levels of distortion with deeper and louder bass
performance than is typical in speakers at this price range.
Output linearity is simply superb!
Advanced G-PAL™ Gold-Anodized Pure-Aluminum Domes
Exceptionally rigid low-mass domes with treated textile
suspensions ensure remarkably uniform, instantaneous
power response. Elevated dome position provides better
‘air’ and frequency response that is smooth, pure and clear.
Die-Cast WaveGuide™ Chassis and Phase Alignment
Bridge. A smooth panorama of audiophile-quality sound.
SE 3
SE Center
SE 1
“Paradigm’s SE 1 beats out boutique brand speakers costing eight times as much.”
– CE Pro
Optional Paradigm Perfect Bass Kit™digital room correction system.
Full details on page 26.
Deep Impact
The SE Sub is a continuation of Paradigm’s multi-year R&D effort to achieve
exceptional bass performance from a compact footprint. The sonic benefits
of Paradigm’s digital signal processing, real-wood veneer cabinets and an
unbelievable price point … what’s not to love! Gorgeous aesthetics aside,
not everyone wants a high-performance subwoofer on full display so the
SE Sub easily converts easily from down-firing to front-firing for use in
discreet installations (see far right).
Advanced High-Power Class-D™ Amplifier delivers massive
amounts of high-current power with minimal distortion:
900 watts Dynamic Peak/300 watts RMS Sustained.
lowest frequency
0 db
0 Hz 200 Hz
90+ db
highest frequency
Typical Subwoofer Response
Paradigm’s (DSP) Digital Signal Processing
Paradigm’s Proprietary Digital Signal Processing (DSP) Design
boasts sophisticated algorithms which “shape” frequency response,
ensuring accurate, consistent and musical bass performance without
audible distortion, even when the SE Sub is playing at its loudest
levels (see graph left).
Control Facilities:
• Auto On/Off
• Subwoofer Level
• Subwoofer Cut-Off Frequency
(continuously variable 35 Hz – 150 Hz);
Bypass Option
• Sub/Sat Phase Alignment
(Continuously variable 0° –180°)
• USB Port/PBK Interface
Input Facilities:
• Line-level Input
Rosenut Black Gloss
SE Sub
15
Down or Forward-Firing Driver boasts Advanced CAP™
Carbon/Aramid-Fiber Polypropylene Cone. Advanced
cone material combines exceptional stiffness and low mass
with excellent internal damping for tremendous freedom
from unwanted resonances.
Advanced Long-Travel Suspension including Nomex®
Spider and Oversize Magnet Structure promote extended
cone excursion while also maintaining superb control over
cone movement. 1-3/8-inch (33 mm) 4-layer voice coil.
High-Pressure Die-Cast Aluminum Chassis with AVS™
Airflow Ventilation System Cooling. Large built-in ribs
increase the heat dissipation surface providing forced air
cooling during large musical transients and chassis convection
cooling at other times. Rigid aluminum controls flexing and
ringing and since aluminum is non magnetic, also eliminates
stray magnetic loss.

Produktspecifikationer

Varumärke: Paradigm
Kategori: Inte kategoriserad
Modell: SE Center
