HIGH-DEFINITION SOUND
™
O W N E R S M A N U A L O M- 1 2 1
Thank you for choosing award-winning Paradigm®speakers and congratulations.
You are about to hear the difference our sonically accurate Stylus®outdoor speakers
will make in your listening experience. These speakers are the product of countless
hours of comprehensive research and development. They will stand up exceptionally
well to the rigors of Mother Nature and reward you with high-quality sound for many years.
To ensure proper installation please read this manual and follow all instructions. If
you have further questions contact your Authorized Paradigm®Dealer or visit the
Q&A page on our website at www.paradigm.com.
outdoor
Paradigm Electronics Inc. 205 Annagem Blvd., Mississauga, ON L5T 2V1 . MPO Box 2410, Niagara Falls, NY 14302
In Canada:
In Canada:
In Canada:
In Canada:In Canada: In U.S.:
In U.S.:
In U.S.:
In U.S.:In U.S.:
YOUR NEW SPEAKERS
Paradigm®Stylus®speakers are designed for use outdoors where they will provide true high-performance
sound. Advanced, reinforced PolyGlass™mineral-filled enclosures, aluminum grilles, stainless steel and
brass hardware, gold-plated binding posts, and stainless-steel/polymer brackets are weather, water,
and UV-resistant, even under adverse weather conditions.
All models are equipped with brackets for easy wall mounting. Stylus®speakers also have holes
spaced 60 mm apart in the backs of their enclosures to fit a wide variety of mounting brackets
(see dealer).
If wall mounting take extra care in installation—we strongly recommend the use of safety straps as
secondary restraints.
Care of Speakers
A damp, soft cloth or the gentle spray from a garden hose may be used to clean the speakers’ exterior.
• Do not use strong or abrasive cleaners on speakers
• Do not spray directly through the grilles into the drive unit
• Do not use a pressure (power) washer to clean speakers—the powerful force of the spray will
damage the drivers and the finish
• Do not place speakers in direct line with an underground sprinkler
• Do not place speakers in an area where they will be drenched with pool splash—over time
heavy doses of chlorine and other pool chemicals may affect the finish
• Do not allow lawn and garden chemicals to come into contact with speakers
• Where possible, avoid placing speakers in direct sunlight—over time this may cause the
finish to fade
1
TABLE OF CONTENTS
Your New Speakers . . . . . . . . . . . . . . . . . . . . . . . . 1
How To Avoid Speaker Damage . . . . . . . . . . 2
Listening Outdoors . . . . . . . . . . . . . . . . . . . . . . . . . 2
Speaker Placement Guidelines . . . . . . . . . . . 2
About Speaker Cable . . . . . . . . . . . . . . . . . . . . . . 4
Wall-Mounting the Speakers . . . . . . . . . . . . . 5
Connecting the Speakers . . . . . . . . . . . . . . . . . . 6
Troubleshooting Guide . . . . . . . . . . . . . . . . . . . . . 7
Speaker Placement
And Connection (pictorial) . . . . . . . . . . . . . . . . 8
Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . 11
HOW TO AVOID SPEAKER DAMAGE
Use an appropriate amplifier. At high volumes, a very powerful amplifier can overdrive your
speakers and damage them. On the other hand, if your amplifier isn’t powerful enough, it can produce
clipping distortion that can easily damage high-frequency drivers.
(See dealer.)
Don’t be fooled by your amplifier’s volume control. It adjusts listening level—it does not indicate
power output. If your speakers begin to sound harsh or grating, or if you hear the bass breaking up,
turn the volume down immediately or you will damage your speakers! This type of damage constitutes
abuse and is not covered by the warranty!
Tone controls and equalizers can demand even more power from an amplifier, lowering the
point at which it produces clipping distortion. Use them sparingly, if at all, and do not use them when
listening at loud levels.
LISTENING OUTDOORS
Outdoors there are no walls to contain sound. Background noise is louder and the distance listeners
are from the speakers is usually greater. Achieving a reasonable listening level can be more difficult.
The tendency is to turn up the volume, however this may disturb neighbors and when turned up too
high can seriously damage the speakers or your amplifier. Stylus®speakers are designed to address
these unique challenges, making them ideal for use in the majority of outdoor stereo applications.
In certain outdoor situations Stylus®‘SM’ speakers, with their Dual-Directional Soundfield™, offer alternative
options. In small areas not well suited to a stereo pair one ‘SM’ speaker is ideal. In larger, or unusually
shaped areas we recommend using multiple ‘SM’ speakers. Using more speakers ensures that sound
is evenly distributed, allowing for reasonable listening levels at lower volumes. Demand on the
amplifier is reduced and neighbors are not disturbed. Think of it this way: When lighting a large out-
door area, using multiple floodlights on a dimmer set to a low setting is far more effective than using
a single floodlight with the dimmer set to high. For more information on where and how to use ‘SM’
speakers turn to page 3.
SPEAKER PLACEMENT GUIDELINES
The mounting brackets provided with Stylus®speakers allow for a wide variety of placement
options. For example:
• Under a roof soffit, mounted to the exterior wall for strength
• Open area of an exterior wall
• Gazebo or other garden structure designed for sitting
• Deck or railing
Placement
(all models except those with ‘SM’ in their name)
To achieve the best quality of sound, place Stylus®speakers far enough apart to achieve good stereo
separation, but not so far apart that you won’t be able to hear both speakers throughout most of the listening
area. For optimum results, measure the approximate distance from your listening area to your speakers
(Fig. 1, “X”). Then position the speakers about 1/2 to 3/4 of that distance from each other (1/2 to 3/4 of “X”).
2
