Sida 1/5
1. USB cable ----------------------------------1
2. er manual --------------- -------------1Us --
Ⅲ. Safety instruc ons
1. Check the device and its acce ories for any damage or anomaly before use. Do not use thess
device if the cover is damaged, or has any other malfuncons.
2. Please fol w the opera on instruc ons.lo
3. Please do not open the device case and modify the internal circuit.
4. Do not store or use this device in high temperature, high humidity, mmable, xplosive and e
strong electromagne c environment.
PCE Americas Inc.
711 Commerce Way
Suite 8
Jupiter
FL-33458
USA
From outside US: +1
Tel: (561) 320-9162
Fax: (561) 320-9176
info@pce-americas.com
www.pce-instruments.com/english
www.pce-instruments.com
PCE Instruments UK Ltd.
Units 12/13
Southpoint Business Park
Ensign way
Hampshire / Southampton
United Kingdom, SO31 4RF
From outside UK: +44
Tel: (0) 2380 98703 0
Fax: (0) 2380 98703 9
info@industrial-needs.com
T eterhermom
PCE-RCM 05
Ⅰ. Overview
Atmospheric par culat a er (PM)e m is microscopic solid or liquid maer suspended in the
Earth’s atmosphere, which can adversely aect hum paran h Pealth. M2.5 c rles a e air pollutants
with a dia of 2 or lessm , containing soot, smoke, metals rate, nit s, sulfates, d wust, ate and re r,
rubbe . r
When we breathe, PM2.5 can g ep int d som ma even g tet de o our lungs an e y et in o bloodstream.
Exposur te o n pare cles can aect the h s eart and lung
PCE-RCM 0 desktop ai quality monito5 is a r r mainly use ford monitoring PM2. oncentra on in 5 c
homes ho lls, ce, s pping ma os, sta ons , etc.
Thi includes manual s informa ab t safety a arnin . Pleas d carefully a foon ou nd w g e rea nd llow
a warnin precll gs and auons before usin the device. g
Ⅱ. Open box inspec on
Open the box and take o he deviceut t , please e che if thck ite rms a e missing or damaged:
Ⅳ
Ⅳ
Ⅳ
ⅣⅣ. Structure
1
LCD screen
2
˚C ˚F/ unit selection button
3
Power ON /OFF button
4
Backlight button
5
USB charge port
6
Ⅴ
Ⅴ
Ⅴ
ⅤⅤ. Symbols
1
Battery icon
7
Temperature unit
2
PM2.5
8
Humidity value
3
PM2.5 value
9
Humidity unit
4
PM2.5 grading emoticons
10
Humidity icon
5
Temperature icon
11
PM2.5 unit
6
Temperature value
Ⅵ
Ⅵ
Ⅵ
ⅥⅥ. Operation instruction
1. Power ON /OFF
Long press button to turn ON/OFF the device
2. ˚C/˚F selection
Short press button to switch the unit between ˚C and ˚F
3. Backlight
Short press button to turn on /off the backlight
Default: backlight is off.
a. When the particle concentration exceeds the standard value (115μg/m 3), the red
backlight turns on
b. When the particle concentration returns to normal value (≤ 115μg/m3), the red
backlight will automatically turns off
Note: The red light stays ON if the concentration exceeds 115μg/m 3. You can short press
button to turn off the backlight.
4. Battery
Enough power
Suggest to charge the battery
Power is running out, please charge the battery
Power off
➢ Notes
⚫ Use USB cable to charge the device.
⚫ It takes around 3 hours to fully charge the device. This device can be used while charging.
⚫ Power supply: 5V/1A.
Ⅶ
Ⅶ
Ⅶ
ⅦⅦ. Performance parameters
1. Technical specifications
Function
Range
Resolution
Accuracy
Remark
PM2.5
0~500 g/m³ μ
1 μg/m³
±( +10dgts) 10μg/m³
@ range 0~100μg/m³
Ambient temperature:
18~28˚C
Ambient humidity:
40%~75%RH
±(10%+30dgts)
@ range 101~400μg/m³
±(10%+50dgts)
@ range 401~500μg/m³
Temperature
- 10~50˚C
0.1˚C
±1˚C
Humidity
0~99%RH
1%RH
±5%RH 30%~80%RH @
±8%RH @<30%RH,>80%RH
Temperature
18~28˚C
