Peavey® 6505® II

Tube Guitar Amplier

Operating

Manual

FCC/ICES Compliancy Statement

This device complies with Part 15 of the FCC rules and Industry Canada license exempt RSS Standard(s). Operation is -

subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must

accept any interference received, that may cause undesired operation.

Le présent appareil est conforme aux CNR d’lndustrie Canada applicables aux appareils radio exempts de

licence. L’exploitation est autorisée aux deux conditions suivantes: (1) I’appareil ne doit pas produire de

brouillage, et (2) I’utilisateur de I’appareil doit accepter tout brouillage radioélectrique subi, même si le

brouillage est susceptible d’en compromettre le fonctionnement.

Warning: Changes or modifications to the equipment not approved by Peavey Electronics Corp. can void the

user’s authority to use the equipment.

Note – This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, , uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is encouraged to try and correct the

interference by one or more of the following measures.

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

•Consult the dealer or an experienced radio/TV technician for help.

Caution

The equipment complies with FCC radiation exposure limits set forth for an uncontrolled

environment.

Peavey® 6505®II

Congratulations on your purchase of the all new 6505® II. Peavey's classic high-gain legacy continues with the 6505® II. Like the

original 6505 head, the 6505 II offers two channels. However, the 6505 II adds separate EQ, Resonance, and Presence controls

to each channel, giving you more control and flexibility. The new footswitch provides foot control of channel selection, effects

loop, and the newly added ability to select the Crunch feature. Now you can instantly obtain that extra gain in the Rhythm

Channel with your foot and never have to take your hand off the guitar. Finally, the Clean Channel has been added, completely

redesigned to sound much cleaner, and has one 12AX7 devoted to just the Clean/Crunch.

The following guide explains these features and how to operate each one in order to obtain your desired sound. We recommend

that you read this manual carefully, paying close attention to any warnings or cautions.

FEATURES:

• Two distinct tube channels with footswitch control

• LED “active” indicators for each channel

• Bright switch for Rhythm channel

• Crunch switch on Rhythm channel with footswitch control

• Separate equalizer sections for each channel

• Separate power amp controls (Resonance and Presence) for each channel

• Separate preamp controls (Pre and Post Gain) for each channel

• Standby power switch

• Bias test points on rear panel

• Effects loop with footswitch control

• 1/4" Preamp output jack

• Speaker impedance selection switch (4, 8, 16 ohm)

• Two parallel 1/4" speaker output jacks

• 120 watts output power ohm output power

• Metal three button footswitch with detachable 25' cable

ENGLISH

VENTILATION: For proper ventilation, allow 24" clearance from the nearest combustible surface.

All vents should have a minimum of 2" of free air space so air can flow thru the unit freely for proper cooling.
