Classic 20 MH®& 112 Combo
20W Tube Guitar Amplifiers
Operating
Manual
Peavey® Classic 20 MH® & 112 Combo
Congratulations on the purchase of your new Classic 20 MH tube guitar amplifier from Peavey! Although small, or 112 Combo
this amp has an all- tube preamp and power amp to authentically produce the much loved tones of the iconic larger models on
which it is based-- albeit at lower power levels. The major advantage is the sheer (or lack of) size and weight.
Revered by blues, country and rock players alike, Peavey Classic amps span the tonal landscape from vintage to contemporary
with ease. Peavey proudly introduces the Classic 20 MH, as a part of its ‘micro-head’ series . , along with the all-new 112 Combo
Although all are inherently versatile, each of the models feature very different preamp voicings and gain structures. We are
confident that everyone from a country picker to a metal shredder will find at least one of these will work for them.
There are numerous features, several that are unique to Peavey, that are described more detail the main text. in in
In summary:-
All models have two channels that follow the same gain structure and voicing of the larger amps on which they are based, as
well as a boost function that has been designed for the specific model. The channels shar EQ, lush reverb and an effects loop. e
Channels, boost, effects loop and reverb are all footswitchable.
Other features on the rear panel include: Effects Loop, Microphone Simulated Direct Interface with XLR output and USB (MSDI™)
out, speaker defeat switch and 3 position power attenuator switch.
The Classic 20 MH exhibit a tremendous amount of versatility in a small package; features real tube tone, real and 112 Combo it
tube power! It contains no simulations, emulations or approximations.
Before you begin playing through your amplifier, it is very important to ensur that the product has the proper AC line voltage e
supplied This is shown on the voltage selector switch near the IEC inlet on the rear panel of the unit. Refer to the rear panel .
diagram in this manual to locate the particular feature next to its number.
Please read this guide carefully to ensure your personal safety as well as safety of your amplifier. A careful reading of this the
manual will also ensure you get the best out of your amplifier, by fully understanding its many features.
FEATURES:
• 2x EL84 power tubes and 3x 12AX7/ECC83 preamp tubes
• Two footswitchable channels with three-band EQ
• Footswitchable volume boost on both channels
• Footswitchable reverb
• Footswitchable buffered effects Loop
• Tube Status Indication (T.S.I.) circuit
• Impedance switch for 16 or 8 ohm cabinets
• MSDI™ Output with XLR and ground lift switch
• USB Output
• Speaker defeat switch
• Headphone output
• Attenuator switch for 20 watts, 5 watts or 1 watt output power
•Single Ohms 20 12" ; 16 Sheffield 1230+ (Classic 112 Combo only)
ENGLISH
VENTILATION: For proper ventilation, allow 24" clearance from the nearest combustible surface.
All vents should have a minimum of 2" of free air space so air can flow thru the unit freely for proper cooling.
Front Panel
1
2
3
4
5
6
7
8
9
INPUT
Standard 1/4” jack for connection to the output of your guitar or last pedal if using effects before the amp.
Volume
Controls the volume and gain level of the clean channel.
CHANNEL SWITCH
Allows selection of the two different channels. The“IN”position of the switch selects the ‘LEAD’ channel and
the“OUT”position selects the ‘RHYTHM’ channel.
NOTE: Channel selection may also be achieved by using the included footswitch.
If remote selection is desired, the CHANNEL switch (#3) must be set to the“IN” position.
PRE-GAIN
This controls the input volume level of the lead channel and therefore the amount of gain and overdrive.
POST GAIN
This controls the output level when the lead channel is selected. Used to balance the sound between the
two channels.
BASS, MIDDLE & TREBLE EQ controls
These are passive tone controls that regulate the low (bass), mid and high (treble) frequencies of the tone
of BOTH channels.
REVERB
Determines the overall reverb level. Fully counterclockwise will be completely "dry" with no reverb, low
settings will produce subtle reverb and high settings will produce lush ambience. This feature can also be
controlled via the optional remote footswitch.
Pilot Light
Illuminates when AC power is being supplied to the amp and the POWER SWITCH (#11) is set to “ON”.
OUTPUT TUBE STATUS INDICATION (T.S.I.™) LEDS
These are LEDs that light green or red depending on the status of the output tube they are monitoring.
These are merely the visual part of the wider status indication, fault detection and tube protection circuits.
The LEDs T1 and T2 relate to the EL84 power tubes from left to right (when viewed from the front).
The simple explanation of this circuit is that the LED will be green in normal working mode and red in any
other mode, including: Standby, low bias, low current (tube wearing out) or high current fault condition
that has activated in the tube protection circuit.
The more complete explanation is as follows:-
On Standby, the LEDs should be red. This is due to the tubes not yet being fully on.
9
1 2 3 7 8 10 11
6
4 5
