www.peavey.com
PVi®8/PVi®12
Compact Mixer
Operating
Manual
PVi®8/PVi®12
Compact Mixers
Congratulations on purchasing the Peavey PVi8 or PVi12 compact mixer. e PVi series mixer is a studio-quality mixing console
designed to meet diverse needs while occupying a small space. is is the perfect console for small venue performances or home
recording environments.
Please read this guide carefully to ensure your personal safety as well as the safety of your equipment.
FEATURES (both models):
• 2 XLR inputs with low noise mix preamps (PVi8)
6 XLR inputs with low noise mix preamps (PVi12)
• 2 channels with stereo 1/4" line inputs
• 3-band EQ on all channels
• LED signal presence and clip indicators, channels 1-2 (PVi8) and channels 1-6 (PVi12)
• Pan/balance control per channel
• Control Room outputs (L/R) 1/4" connectors
• Stereo Aux Returns (L/R) 1/4" connectors
• Global +48 Volt phantom power
• Master LED meter bridge
• EFX send bus, with master level control
• Stereo output, 1/4" connectors (L/R)
• Stereo headphone jack, 1/4" (L/R)
• Rugged console design
• Weight: PVi8 : 3.0 lbs. (1.36 kg)
PVi12: 3.6 lbs. (1.63 kg)
• Size: PVi8: 2.5" H x 7.375" W x 10.25" D
(6.35 cm x 18.733 cm x 26.035 cm)
PVi12: 2.5" H x 11.625" W x 10.25" D
(6.35 cm x 29.528 cm x 26.035 cm)
ENGLISH
Front Panel: Lower
1
2
3
4
6
7
12
13
14
15
16
(1) High EQ
is active tone control (shelving type: +/-15dB @ 12kHz) varies the level of the high frequency range.
(2) Mid EQ
is active tone control (peak/dip: +/-15dB @ 400Hz) varies the level of the mid frequency range.
(3) Low EQ
is active tone control (shelving type: +/-15dB @ 80Hz) varies the level of the low frequency range.
CAUTION: Excessive low frequency boost causes greater power consumption and increases the possibility of speaker damage.
(4) FX Send
is adjusts the level of the channel signal added to the eects mix. e eects send signal is taken aer the channel level controls (7)
so that adjustments made to the level control will also aect the send level.
(5) Signal Presence/Clip LED
is LED helps in setting the gain control. Gain (19) should be adjusted so that the green LED ashes in time with the source, and
turns red only on the loudest peaks. If adding EQ results in clipping (red LED), compensate here by reducing the gain control (19). e
red clipping LED lights when roughly 5dB of headroom remains.
(6) Pan/Balance
is knob controls the placement of the signal in the stereo eld. When rotated completely counter- clockwise, the signal is present
only in the le channel; when rotated completely clockwise, it is only in the right channel.
(7) Level
is is the channel output level control. e optimum setting is the 12 o'clock (unity gain) position.
(8) Aux Return Level Control
Controls the level of the Stereo Aux Return jacks (20). If only the le jack is connected, the signal is sent to both the L and R. If both
jacks are connected, they function as a stereo pair.
(9) FX Master Send
is is the master output level control for the FX mix. e output level sent to the FX Send jack is controlled by the Channel Level
Control (7), the channel FX Send control (4), and by this master control. e 12 o'clock position is the recommended setting for this
control.
5
8
9
10
11
