Sida 1/18
www.peavey.com
PVXp™ 12 DSP
Powered Speaker System
Operating
Manual
FCC/ICES Compliancy Statement
This device complies with Part 15 of the FCC rules and Industry Canada license exempt RSS Standard(s). Operation is -
subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, that may cause undesired operation.
Le présent appareil est conforme aux CNR d’lndustrie Canada applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux conditions suivantes: (1) I’appareil ne doit pas produire de
brouillage, et (2) I’utilisateur de I’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.
Warning: Changes or modifications to the equipment not approved by Peavey Electronics Corp. can void the
user’s authority to use the equipment.
Note – This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, , uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try and correct the
interference by one or more of the following measures.
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution
The equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
Introduction
ank you for purchasing the powered Peavey PVXp™ 12 DSP powered speaker system. e PVXp™ 12 DSP
features a reliable bi-amped power section that provides a total of 830 Watts of peak available dynamic power.
With that much available power, speaker protection is critical. Advanced digital signal compression prevents
audible overload, protecting the speakers from harmful distortion at high output levels. is powered enclosure
also includes heavy duty speaker drivers; it features a 12” woofer with a 2-3/8” voice coil and a 50 oz. magnet,
this is coupled with the RX14 compression driver that includes a 1.4” titanium diaphragm on a 100-degree hor-
izontal x 50 degree vertical pattern asymmetrical horn.
e PVXp™ 12 DSP provides a balanced input via a combination jack that accepts a balanced TRS 1/4” input, as
well as a balanced XLR input and summed RCA jacks. ere are two balanced ru outputs, a male XLR and a
1/4” TRS. e LCD display and EQ presets, along with other operating parameters are accessed via a one-knob
selector.
Features
* Two-way bi-amplied analog amp powered speaker system
* 12” heavy-duty woofer with a 2-3/8” voice coil & 50 oz. magnet
* RX™ 14 compression driver, with 1.4 inch titanium diaphragm
* 630 watts peak dynamic woofer power, 200 watts peak dynamic tweeter power
* DSP processing is 64 bit double-precision
* DSP I/O is at 48 kHz and 24 bits, with low-jitter, professional grade components
* Fan cooled for maximum reliability
* Patented Quadratic roat Waveguide™ technology, 100 by 50 degree coverage
* Asymmetrical horn aims the sound down 10 degrees, at the audience, not over their heads.
* Input is via a combo female XLR and 1/4” TRS phone jack with balanced input
* A Mic/Line switch provides for two dierent gain settings
* ru output is via a male XLR jack and 1/4” TRS phone jack
* Multiple Factory Preset EQ settings
* Rugged plastic injection-molded trapezoidal enclosure
* Full-coverage perforated steel grille, with powder coat nish
* Pole mount molded-in for 1 3/8” diameter poles
* Top, bottom and right side ying point inserts
Description
e PVXp™ 12 DSP is a two-way sound reinforcement system based on a heavy-duty Pro 12” woofer and a
RX14 titanium diaphragm dynamic compression driver mounted on a 100 by 50 degree coverage Quadratic
roat Waveguide™. Its sleek, modern appearance, coupled with excellent performance, oer an outstanding
package. e lightweight-yet-rugged injection-molded plastic enclosure with molded-in stand mount cup
facilitates portable use for live music or P.A. sound. e trapezoidal cabinet has three handles for ease of porta-
bility, and an extra 45-degree angled section on the right side to allow use as a oor monitor. Five sets of ying/
mounting points, two on the top, two on the bottom, and one on the side, with a total of 16 cabinet inserts,
provide for the ultimate in installation exibility. A black, powder-coated, perforated steel grille provides driver
protection and a professional appearance.
ENGLISH
