Sida 1/45

www.peavey.com

PVXp™ 15 Bluetooth®

Powered Speaker System

Operating

Manual

FCC/ICES Compliancy Statement

This device complies with Part 15 of the FCC. Operation is subject to the following two conditions: (1) this device may

not cause harmful interference, and (2) this device must accept any interference received, that may cause undesired

operation.

Le présent appareil est conforme aux CNR d’lndustrie Canada applicables aux appareils radio exempts de

licence. L’exploitation est autorisée aux deux conditions suivantes: (1) I’appareil ne doit pas produire de

brouillage, et (2) I’utilisateur de I’appareil doit accepter tout brouillage radioélectrique subi, même si le

brouillage est susceptible d’en compromettre le fonctionnement.

Warning: Changes or modifications to the equipment not approved by Peavey Electronics Corp. can void the

user’s authority to use the equipment.

Note – This equipment has been tested and found to comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a commercial environment. This equipment

generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the

instruction manual, may cause harmful interference to radio communications. Operation of this equipment in

a residential area is likely to cause harmful interference in which case the user will be required to correct the

interference at their expense.

Introduction

ank you for purchasing the powered Peavey® PVX™p 15 Bluetooth® speaker system. e PVX™p 15 Blue-

tooth® features a reliable bi-amped power section that provides a total of 980 Watts of peak dynamic power with

DSP based compression and limiting. Featuring a 15” heavy-duty woofer with a 2 3/8 inch voice coil and 50

ounce magnet, and the RX14™ compression driver with a 1.4 inch titanium diaphragm on a 100 degree horizon-

tal x 50 degree vertical pattern asymmetrical horn. e PVX™p 15 Bluetooth® provides two channels with a bal-

anced input via a combination jack that accepts balanced TRS 1/4 inch input as well as a balanced XLR input.

A switch is provided to change between line level gain and mic level gain. A third channel is for a Bluetooth®

source, or alternatively a 1/8” AUX input jack. Each channel has an adjustable Level control, and a three-band

EQ section. ere is a balanced output, a Male XLR, that can feed the mixed signals from the three channels

out to another component. A front bae LED indicator that can be set to light when power is on, and when the

“so-limiting” DDT circuit is activated, or turned o altogether. e LCD display and EQ presets, along with

other DSP operating parameters are accessed via a one-knob selector.

Features

* Two-way bi-amped sound reinforcement enclosure

* 15” heavy-duty woofer with 2 3/8” voice coil & 50 oz. magnet

* RX14™ compression driver, with 1.4 inch titanium diaphragm

* Reliable fan-cooled power amps with DSP protection

* Total of 980W peak dynamic power

* DSP control for precise crossover, EQ and limiting functions

* DSP I/O is at 48 kHz and 24 bits, internal processing is 56 bit double-precision

* Peavey’s Quadratic roat Waveguide™ technology, 100 by 50 degree coverage

* Asymmetrical horn aims the sound down 10 degrees, at the audience, not over their heads

* Bluetooth® input is via a dedicated input channel

* Analog input is via a combo female XLR and 1/4” TRS phone jack with balanced input

* ree channels in total, two for analog, and one for Bluetooth or AUX input via a 1/8” jack

* Each channel has a level control and a 3-band EQ section to adjust and shape the input signals

* Mix/ru Output is via a male XLR jack

* Durable plastic injection-molded trapezoidal enclosure

* Extra angled section on right side allows oor monitor use

* Full-coverage heavy-duty perforated steel grilles, with powder coat nish

* Pole mount molded-in for 1 3/8” diameter poles

* Top, bottom and right side ying point inserts

Description

e PVX™p 15 Bluetooth® is a two-way sound reinforcement system based on a heavy-duty Pro 15 15” woofer

and a RX14™ titanium diaphragm dynamic compression driver mounted on a 100 by 50 degree coverage Qua-

dratic roat Waveguide™. It’s sleek, modern appearance coupled with excellent performance, oer a superb

overall package.

e lightweight yet rugged injection-molded plastic enclosure with molded-in stand mount cup facilitates

portable use for live music or PA sound. e trapezoidal cabinet has three handles for ease of portability, and

an extra 45-degree angled section on the right side to allow use as a oor monitor. Five sets of ying/mounting

points, two on the top, two on the bottom, and one on the side, with a total of 16 cabinet inserts, provide for the

ENGLISH
