www.peavey.com
RBN™ 112
Powered Speaker System
Operating
Manual
FCC/ICESCompliancyStatement
This Standard(s).  device complies with Part 15 of  the RSS  FCC rules and  Industry Canada license‐ exempt  Operation is
subject following harmful interference, andtothe twoconditions:(1)thisdevicemaynotcause  (2)thisdevicemust
accept any interference may operation.  received, that   cause undesired
Le conforme deprésent est appareil  aux CNR Canada d’lndustrie   applicables aux appareils radio exempts 
licence. est autoriséeL’exploitation   aux deux conditions suivantes: (1) I’appareil ne dedoit  pas produire
brouillage, (2) I’utilisateur I’appareil brouillage leet  de doitacceptertout radioélectriquesubi,mêmesi 
brouillage susceptible fonctionnement.est d’encompromettrele 
Warning:    Changes or modifications to the equipment not approved by Peavey Electronics Corp. can void the
user’s  authority to use the  equipment.
Note –  This equipment has been tested and found to comply   with the limits for a Class B digital device,
pursuant to Rules. limits to provide reasonable protection against Part15oftheFCC These aredesigned 
harmful in ainterference  residentialinstallation. generates, uses, and radiate radioThisequipment  can  
frequency energy and, if installed and in accordance with instructions, harmful  not  used  the maycause 
interference to radio However, is  communications. there no  guarantee that interference will not occur in a
particularinstallation.If   this equipment does cause harmful interference to radio or  television reception,
which determined turning equipment and is to andcanbe by the off on,theuser encouraged try correctthe
interference followingbyoneormoreofthe measures.
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Caution
The equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
Introduction
ank you for purchasing the Peavey® RBN™112 powered speaker system. e RBN™112 features a bi-amped
power section that provides 1000 watts of peak power for the woofer and 500 watts of peak power for the rib-
bon driver tweeter, both with DDT™ compression. Featuring a 12” Neo dual voice coil Scorpion® woofer and
the RD™2.6 true ribbon driver, the RBN™112 provides two independent mixed input channels, each with Gain
control and a mic/line gain switch, and each channel features a combo jack with 1/4” TRS & female XLR and a
balanced input with volume control. A DSP based crossover and processor provides extreme exibility to the
user faced with common location acoustics conditions.
Features
* Bi-amplied powered speaker system
* 1000 watts peak available woofer power, 500 watts peak available tweeter power
* Both power amps have DDT compression
* 12” Neodymium Dual Voice Coil Scorpion® woofer
* Peavey RD™ 2.6 ribbon driver tweeter on a low-coloration waveguide
* Peak SPL up to 130 dB with music!
* DSP based crossover, limiting and EQ
* EQ presets available via rotary encoder pushbutton select
* 9-band EQ and other system settings accessed via rotary encoder pushbutton select
* Dynamic bass boost function
* Up to 150 mS of architectural delay
* Fan cooled for maximum reliability
* Two independent mixed input channels, with Gain control and mic/line gain switch
* Each channel features a combo jack with 1/4” TRS & female XLR balanced input
* Input 2 has a 3.5 mm (1/8”) stereo media input jack
* Output connectors are male XLR
* One full handle on the right side, full handle on top rear
* Full length perforated steel grille with cloth backing
* Rugged polypropylene molded enclosure
* Pole mount built-in
* Reduced weight – Only 39 pounds!
* Flying point insert groups on top and bottom mate with VM™ 70 mounting bracket
Description
e Peavey® RBN™112 is a powered, bi-amplied, two-way speaker system engineered to provide very high
levels of performance in a compact powered loudspeaker. is two-way powered system is comprised of a 1000
W peak switching power amplier driving a 12” Neodymium magnet based dual voice coil Scorpion® woofer.
e RD™2.6 true ribbon tweeter is driven by a 500 W peak switching power amplier, and is coupled to a low
coloration waveguide with a coverage pattern of 110° horizontal by 30° vertical.
e RBN™112 is capable of up to 130 dB peak SPL. e enclosure utilizes tough high-performance plastic in an
injection-molded modied-trapezoidal form, with a full-length coated perforated steel grille to oer an attrac-
tive yet durable powered speaker system. e cabinet and grille are black.
ENGLISH
