Sida 1/8

ENQuick Guide

PROGRAMS TABLE

Program Programs description

Drying

phase

Auto Door

Available

options *)

Duration

ofwash

program

(h:min)**)

Water

con-

sumption

(litres/cycle)

Energy

con-

sumption

(kWh/cycle)

Eco 50°- Eco program is suitable to clean normally soiled tableware, that

for this use, it is the most ecient program in terms of its combined energy

and water consumption, and that it is used to assess compliance with the EU

Ecodesign legislation.

3:35 8.7 0.59

2. Auto Intensive 65° - Automatic program for heavily soiled dishes and pans

(not to be used for delicate items). 2:00 - 3:10 14.0 - 17.0 1.50 - 1.85

Auto Mixed - 55° Automatic program for normally soiled pans and dishes.

1:20 - 3:00 7.0 - 14.0 0.70 - 1.10

4. Half Load 55°- Ideal for washing a half load of lightly or normally soiled crockery. 1:20 11.0 1.00

5. Rapid 30’ 45° - Program to be used for half load of lightly-soiled dishes with

no dried food residues. Without drying. - 0:30 9.0 0.50

Extra Hygiene 65° - Normally or heavily soiled crockery, with additional antibac-

terial wash. Can be used to perform maintenance of the dishwasher.

- 1:50 12.0 1.30

Extra - 50° Program that allows to wash very big items loaded in the lower

rack. Please apply detergent directly to tub instead of detergent dispenser.

Upper rack should be removed with this cycle. -- 1:30 11.0 1.20

8. Prewash - Use to refresh crockery planned to be washed later. Nodetergent

to be used with this program. -- 0:10 4.5 0.01

Push&GO 50° - Everyday wash and dry cycle that ensures great cleaning per-

formance in a short time without the need to pre-treat dishes.

1:25 11.5 1.10

1. On-O/Reset button with indicator

light

2. Program selection button

3. Salt rell indicator light

4. Rinse Aid rell indicator light

5. Program number and delay time

indicator

6. Tablet (Tab) indicator light

7. Display

8. Push & Go button

9. Delay button

10. Start/Pause button with

indicator light/ Tablet (Tab)

FILLING THE SALT RESERVOIR

The use of salt prevents the formation of LIMESCALE on the dishes and on

the machine’s functional components.

• It is mandatory that the salt reservoir never be empty.

• It is important to set the water hardness.

The salt reservoir is located in the lower part of the dishwasher and must be

lled when the SALT REFILL indicator light in the control panel is lit.

1. Remove the lower rack and unscrew the reservoir cap

(anticlockwise).

2. Position the funnel and ll the salt reservoir (see gure)

right up to its edge (approximately 1 kg); it is not unu-

sual for a little water to leak out.

3. Only the rst time you do this: ll the salt reservoir

with water.

4. Remove the funnel and wipe any salt residue away from the opening.

Make sure the cap is screwed on tightly, so that no detergent can get into the

container during the wash program (this could damage the water softener be-

yond repair). Whenever you need to add salt, it is mandatory to complete the

procedure before the beginning of the washing cycle to avoid corrosion.

WATER SOFTENING SYSTEM

Water softener automatically reduces water hardness, consequently pre-

venting scale buildup on heater, contributing also to better cleaning e-

ciency. This system regenerates itself with salt, therefore it is required

to rell salt container when empty.

Frequency of regeneration depends on water hardness level setting - regen-

eration takes place once per 6 Eco cycles with water hardness level set to 3.

Regeneration process starts in nal rinse and nishes in drying phase, be-

fore cycle ends.

• Single regeneration consumes: ~3.5L of water;

• Takes up to 5 additional minutes for the cycle;

• Consumes below 0.005kWh of energy.

FILLING THE RINSE AID DISPENSER

Rinse aid makes dish DRYING easier. The rinse

aid dispenser should be lled when the A RINSE

AID REFILL indicator light in the control pan-

el is lit. NEVER pour the rinse aid directly into the

appliance tub.

FILLING THE DETERGENT DISPENSER

To open the detergent dispenser use the opening device . Introduce the C

detergent into the dry dispenser only. Place the amount of detergent for D

pre-washing directly inside the tub.

If all-in-one detergents are used, we recommend using the TABLET button,

because it adjusts the program so that the best washing and drying results

are always achieved.

Usage of detergent not designed for dishwashers may cause malfunc-

tion or damage to the appliance.

1 2 3 4 5 6 7 8 9 10

ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.

Note for Test Laboratories: For information on

comparative EN testing conditions, please send an email to the following address:

dw_test_support@europeanappliances.com

Pre-treatment of the dishes is not needed before any of the programs.

*) Not all options can be used simultaneously.

**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and

pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-

bration. The sensor calibration can increase program duration up to 20 min.

PLEASE SCAN THE

QR CODE ON YOUR

APPLIANCE IN

ORDER TO HAVE

MORE DETAILED

INFORMATION

Before using the appliance carefully read Safety and Installation Instructions.

After installation, please remember to remove all transport protection parts from

the dishwasher.

CONTROL PANEL

FIRST TIME USE More information in the Daily Reference Guide on website.

Quick GuideEN

PUSH&GO - Push&GO button is an easily distinguishable button that

allows you direct access to the Push&GO program, a wash and dry

cycle that ensures great cleaning performance in a short time. You don’t have

to worry which program to choose, Push&GO cycle will do the work for you.

OPTIONS AND FUNCTIONS

OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected

program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.

Please scan on your product in order to have more detailed information. the QR code

DELAY -The start of the program may be delayed for a period of time

between and hours. 1 12

The DELAY function cannot be set once a wash cycle has been started.

TABLET (Tab)- If you use powder or liquid detergent, this option

should be o.

OPERATION INDICATOR - A LED light projected on the oor indicates

that the dishwasher is working. One of the following operating modes

can be selected:

a) Disabled function.

b) When the cycle starts the light goes on for few seconds, stays o during

the cycle and ashes at the end of the cycle.

c) The light stays on during the cycle and ashes at the end of the cycle

(default mode).

Auto Door is a convection drying system which automatically opens

the door during/after drying phase to ensure exceptional drying

performance every day. Door opens at the temperature that is safe to

your kitchen furniture.

LOADING THE RACKS CAPACITY: 10 standard place-settings

CLEANING AND MAINTENANCE More information in the Daily Reference Guide on website.

UPPER RACK

Load delicate and li-

ght dishes: glasses,

cups, saucers, low sa-

lad bowls.

(loading example for

the upper rack)

FOLDABLE

FLAPS WITH

ADJUSTABLE

POSITION

LOWER RACK

For pots, lids, plates, salad

bowls, cutlery etc. Large

plates and lids should ide-

ally be placed at the sides

to avoid interferences

with the spray arm.

The lower rack has tip-up

supports which can be

used in a vertical position

when arranging plates or

(loading example

for the lower rack)

in a horizontal position

(lower) to load pans and

salad bowls easily.

CUTLERY BASKET

The basket is equipped

with top grilles for im-

proved cutlery arrange-

ment. The cutlery basket

should be positioned only

at the front of the lower

rack.

Knives and other uten-

sils with sharp edges must be placed in

the cutlery basket with the points facing

downwards or they must be positioned

horizontally in the tip-up compartments

on the upper rack.

CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS

1 2 3 4

In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds

etc.) please remove them carefully.

NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).

To remove the upper spray arm,

turn the plastic locking ring in

aclockwise direction.

The lower spray arm may be

removed by pulling it upwards.

EXTRA - makes it possible to carry out a heavy-duty wash cycle of

large crockery up to a max height of 53cm. baking pans, oven grids,

dripping pans, hob grids, large saucepans, serving dishes, pizza dishes,

stainless-steel hood lters. Remove the upper rack to load bulky crockery.

Release the two locks (right and left) and pull out the rack.

When the upper rack is tted, the locks must be always

closed.

In order for the water to reach the crockery everywhere,

arrange it as shown in the Figure.

Do not start the dishwasher without the upper rack

using wash cycles other than EXTRA.

To carry out the wash cycle Extra pour the detergent

DIRECTLY INTO THE TUB and not into the dispenser.

ENQuick Guide

PROBLEMS POSSIBLE CAUSES SOLUTIONS

The dishwasher does not

ll the water.

Display shows: H,

6 and On/O LED is

blinking rapidly

No water in the water supply or the tap is closed. Make sure there is water in the water supply or the tap running.

The inlet hose is bent. Make sure the inlet hose is not bent (see INSTALLATION) reprogram the dishwasher and

reboot.

The sieve in the water inlet hose is clogged; it is

necessary to clean it

After having carried out the verication and cleaning, turn o and turn on the dishwasher

and restart a new program.

Dishwasher nishes the

cycle prematurely.

Display shows: 15

and On/

O LED is blinking

rapidly

Drain hose positioned too low or siphoning into

home sewage system.

Check if end of drain hose is placed at correct height (see INSTALLATION).Check for sipho-

ning into home sewage system, install air admittance valve if necessary.

Air in water supply. Check water supply for leaks or other issues letting air inside.

Detergent leaks.

Depends on the liquid detergent used and

can be emphasized in case of delay option is

activated.

Small leaks will not cause machine malfunction and can be avoided by changing liquid

detergent type or using tablets.

In case your dishwasher doesn’t work properly, check if the problem can be solved by going through the following list. For other errors or issues

please contact authorized After-sales Service which contact details can be found in the warranty booklet. Spare parts will be available for a period

of either up to 7 or up to 10 years, according to the specic Regulation requirements.

TROUBLESHOOTING

Policies, standard documentation, ordering of spare parts and additional product information can be found by:

• Using QR code on your product.

• Visiting our website and docs.privileg.eu parts-selfservice.europeanappliances.com

• Alternatively, (See phone number in the warranty booklet). When contacting our After-sales contact our After-sales Service

Service, please state the codes provided on your product‘s identication plate.

The model information can be retrieved using the QR-Code reported in the energy label. The label also includes the model

identier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.

IEC 436

Please scan on your product in order to have more detailed information. the QR code

Produktspecifikationer

Varumärke:	Privileg
Kategori:	Diskmaskin
Modell:	PV2IC10BS7LA0

Behöver du hjälp?

Om du behöver hjälp med Privileg PV2IC10BS7LA0 ställ en fråga nedan och andra användare kommer att svara dig

Ditt namn*

Din e-post*

Skriv din fråga här

Diskmaskin Privileg Manualer

Privileg P0U ECO D551 S Bruksanvisning

15 Januari 2025

Privileg P0B ECO D551 X Bruksanvisning

15 Januari 2025

Privileg PV2UC10BS7A0S Bruksanvisning

15 Januari 2025

Privileg PV2PC10BS7A0 Bruksanvisning

15 Januari 2025

Privileg PV2IC10BS7LA0 Bruksanvisning

15 Januari 2025

Privileg PV2FC10BS7A0S Bruksanvisning

14 Januari 2025

Privileg P0F ECO D551 S Bruksanvisning

14 Januari 2025

Privileg RSBC 3B19 X Bruksanvisning

30 December 2025

Privileg RFO 3C23 A 6.5 X Bruksanvisning

17 December 2024

Privileg RIO 3C23 A E 6.5 X Bruksanvisning

7 September 2024

Diskmaskin Manualer

Nyaste Diskmaskin Manualer

Candy A 9002 Bruksanvisning

16 Januari 2025

Candy CDIN 2D620PB-80E Bruksanvisning

16 Januari 2025

Summit DW183WADA Bruksanvisning

16 Januari 2025

Whirlpool ADG 8557 WHM Bruksanvisning

15 Januari 2025

Zanussi Zanussi ZDI 13010 XA Bruksanvisning

15 Januari 2025

Whirlpool ADP 6837 Bruksanvisning

15 Januari 2025

Whirlpool ADP4305 WH Bruksanvisning

15 Januari 2025

Whirlpool ADP 4540 WH Sea Line Bruksanvisning

15 Januari 2025

Etna AFI 8523 Bruksanvisning

15 Januari 2025

Candy CDF 1E5D3B Bruksanvisning

14 Januari 2025
