Sida 1/8
1
EN
DAILY REFERENCE
GUIDE
You can download the Safety Instructions and the Use and Care Guide, by visiting our website
docs.whirlpool.eu and following the Instructions on the back of this booklet.
Before using the appliance carefully read Health and Safety guide.
PRODUCT DESCRIPTION
APPLIANCE
1.Upper rack
2. Foldable flaps
3.Upper rack height adjuster
4.Upper spray arm
5.Lower rack
6.Cutlery basket
7.Lower spray arm
8.Filter Assembly
9.Salt reservoir
10.Detergent and Rinse Aid dispensers
11.Rating plate
12.Control panel
0000 000 00000
Service:
1
2
3
4
5
6
7
1011
12
9 8
CONTROL PANEL
1. On-Off/Reset button with indicator light
2.
Program selection button with indicator light
3.
Half Load button with indicator light / Key lock
4.
Eco program indicator light
5. Key lock indicator light
6. Display
7. Program number and remaining time indicator
8.
Tablet (Tab) indicator light
9. Closed water tap indicator light
10. Rinse Aid refill indicator light
11. Salt refill indicator light
12. Tablet (Tab) button with indicator light
13. Delay button with indicator light
14. Start/Pause button with indicator light / Drain out
3
1
2
4 8
13
145 6 7 10
11
129
2
FIRST TIME USE
SALT, RINSE AID AND DETERGENT
ADVICE REGARDING THE FIRST TIME USE
After installation, remove the stoppers from the racks and the retaining
elastic elements from the upper rack.
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and
on the machine’s functional components.
• It is important that the salt reservoir be never empty.
• It is important to set the water hardness.
The salt reservoir is located in the lower part of the dishwasher (see
PROGRAMS DESCRIPTION) and should be filled when the SALT REFILL
indicator light in the control panel is lit.
1.Remove the lower rack and unscrew the
reservoir cap (anticlockwise).
2.Position the funnel
(see figure)
and fill the salt
reservoir right up to its edge (approximately 1 kg);
it is not unusual for a little water to leak out.
3.Remove the funnel and wipe any salt residue
away from the opening.
Make sure the cap is screwed on tightly, so that no detergent can get
into the container during the wash program (this could damage the
water softener beyond repair).
Whenever you need to add salt, we recommend carrying out the
procedure before the washing cycle is started.
SETTING THE WATER HARDNESS
To allow the water softener to work in a perfect way, it is essential that
the water hardness setting is based on the actual water hardness in
your house. This information can be obtained from your local water
supplier.
The factory setting is for average (3) water hardness.
• Switch on the appliance by pressing the ON/OFF button.
• Switch off the appliance by pressing the ON/OFF button.
• Hold down button START/PAUSE for 5 seconds, until you hear a
beep.
• Switch on the appliance by pressing the ON/OFF button.
•
The current selection level number and the salt indicator light both flash.
• Press button P to select the desired hardness level (see WATER
HARDNESS TABLE).
• Switch off the appliance by pressing the ON/OFF button.
Setting is complete!
As soon as this procedure is complete, run a program without loading.
Only use salt that has been specifically designed for dishwashers.
After the salt has been poured into the machine, the SALT REFILL
indicator light switches off.
If the salt container is not filled, the water softener and the heating
element may be damaged as a result .
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse aid dispenser B should
be filled when the RINSE AID REFILL indicator light in the control
panel is lit.
1. Open the dispenser by turning the cap
A
in an anticlockwise
direction.
2. Carefully introduce the rinse aid as far as the maximum (110 ml)
reference notch of the filling space - avoid spilling it. If this happens,
clean the spill immediately with a dry cloth.
3. Screw the cap back on.
NEVER pour the rinse aid directly into the tub.
ADJUSTING THE DOSAGE OF RINSE AID
If you are not completely satisfied with the drying results, you can
adjust the quantity of rinse aid used.
Turn the adjuster C.
The factory setting is for a medium level.
• If you see bluish streaks on the dishes, set a low number (1-2).
• If there are drops of water or limescale marks on the dishes, set a high
number (5-6).
A Rinse aid dispenser
cap.
(Unscrew the cap to fill
the dispenser).
B Rinse aid dispenser
C Rinse aid dosage
adjuster.
(You can set up to a max.
of 6 levels).
FILLING THE DETERGENT DISPENSER
Open the detergent dispenser and measure out the detergent
according to Programs Table.
D Lid opening button
(Press to access the
containers)
E Cover
(Detergent containers).
Remove detergent resi-
dues from the edges of
the containers before
closing the cover until it
clicks.
F Pre-wash detergent
container.
Detergent for pre-wash
(pour in the powder or liquid detergent after consulting the PROGRAMS
TABLE).
G Wash detergent container.
Detergent for wash (pour in the powder, liquid or tablet detergent
after consulting the PROGRAMS TABLE).
The detergent dispenser automatically opens up at the right time
according to the program.
If all-in-one detergents are used, we recommend using the TABLET
button, because it adjusts the program so that the best washing and
drying results are always achieved.
Water Hardness Table
Level °dH
German degrees
°fH
French degrees
1 Soft 0 - 6 0 - 10
2 Medium 7 - 11 11 - 20
3 Average 12 - 17 21 - 30
4 Hard 17 - 34 31 - 60
5 Very hard 35 - 50 61 - 90
A
B
F CGD
E
E
D FG
3
PROGRAMS TABLE
ECO program data is measured under laboratory conditions according to European Standard EN 50242.
*) Not all options can be used simultaneously.
**) The duration of the program shown on the display or in the booklet is an estimate calculated on standard conditions. The actual time may vary
depending on many factors such as temperature and pressure of the incoming water, room temperature, amount of detergent, quantity and type of load,
load balancing, additional selected options and sensor calibration. The sensor calibration can increase program duration up to 20 min.
Standby consumption: Left-on mode consumption: 5 W - Off mode consumption: 0.5 W
Program
Drying
phase
Available options *)
Detergent
container Duration of
wash program
(h:min)**)
Water
consumption
(litres/cycle)
Energy
consumption
(kWh/cycle)
F G
1. Eco 50°C 3:00 10 0,83
2. Intensive 65°C - 2:30 14 1,30
3. Normal 55°C - 2:00 13,5 1,10
4. Delicates 45°C - 1:40 10 0,95
5. Rapid 25’ 50°C - - 0:25 8,5 0,50
6. PreWash - - - - 0:10 4 0,01
PROGRAMS DESCRIPTION
Instructions on wash cycle selection.
ECO
Normally soiled crockery. Standard program, the most efficient in terms
of its combined energy and water consumption.
INTENSIVE
Program recommended for heavily soiled crockery, especially suitable
for pans and saucepans (not to be used for delicate items).
NORMAL
Normally soiled crockery. Everyday cycle, that ensures optimal cleaning
performance in shorter time.
DELICATES
Cycle for delicate items, which are more sensitive to high temperatures,
for example glasses and cups.
RAPID 25’
Program to be used for lightly-soiled dishes with no dried food
residues. (Ideal for 2 place settings).
PRE-WASH
Crockery to be washed later. No detergent to be used with this
program.
Notes:
Optimum performance levels when using the “1 Hour” and “Rapid”
programs can be achieved by observing the maximum amounts of
specified place settings.
To reduce consumption even further, only run the dishwasher
when it is full.
